Modular Circuits Advanced Expansion Kit
Included Equipment
Item
1
Gratnells Case with foam, tray, and lid
2
Speaker Module
3
Dc Buzzer Module
4
Diode Module
5
Solar Cell Module
6
Mosfet Module
7
Two Terminal Module
8
Bipolar Junction Transistor Module
9
Jumper Clips
10
Transistors:
N-channel MOSFET (2N7000-TA)
P-channel MOSFET (TP2104)
NPN Bipolar Junction Transistor (2N3904-TFR)
PNP Bipolar Junction Transistor (2N4403-AP)
Included with the EM-3555 Modular Circuits AC/DC Advanced Expansion Kit
*
800-772-8700
EM-3556
Recommended Equipment
Qty
The following table lists the equipment required to perform
experiments with the kit. At least one of the options
1
provided for each item is recommended.
1
Item
1
Modular
1
Circuits Set
1
Function
1
Generator
1
1
15
2
2
2
2
Options
EM-3535 Basic Kit
EM-3536 Essential Physics Kit
EM-3533 Wireless AC/DC Module
www.pasco.com
Product Manual
012-16529B
*
Advertisement
Table of Contents
Related Manuals for PASCO EM-3556
Summary of Contents for PASCO EM-3556
- Page 1 Product Manual 012-16529B Modular Circuits Advanced Expansion Kit EM-3556 Included Equipment Recommended Equipment Item The following table lists the equipment required to perform experiments with the kit. At least one of the options Gratnells Case with foam, tray, and lid provided for each item is recommended.
- Page 2 EM-3556 Modular Circuits Advanced Expansion Kit Module Descriptions Diode DC Buzzer The diode module contains a PN junction diode that allows current to flow in only one direction. Current will flow when a negative voltage is applied to the side of the The DC buzzer module produces sound when a DC diode marked with the grey ring.
- Page 3 EM-3556 Modular Circuits Advanced Expansion Kit Two Terminal can be used with the module. Make sure to check the pinouts on the datasheet when using other transistors. MOSFET The two terminal module allows an external power supply or signal generator to be used as a voltage source. The module contains a fuse that will trip when the output current is greater than 2 A.
- Page 4 Trademarks PASCO and PASCO scientific are trademarks or registered trademarks of PASCO scientific, in the United States and/or in other countries. All other brands, products, or service names are or may be trademarks or service marks of, and are used to identify, products or services of, their respective owners.
