Summary of Contents for Toyota 2009 Land Cruiser
- Page 2 Owner’s Manual and supplementary manuals so you will have a better understanding of your vehicle’s capabilities and limitations. Your dealership and the entire staff of Toyota Motor Sales, U.S.A., Inc. wish you many years of satisfied driving in your new Land Cruiser.
-
Page 3: Table Of Contents
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES Visit your Toyota dealer for information on customizing this feature. Programmable by customer. Refer to the Owner’s Manual for instructions and more information. HomeLink ® is a registered trademark of Johnson Controls, Inc. Engine maintenance... -
Page 4: Overview
Power rearview mirror control Instrument panel light control Tilt and telescopic steering control Roll Sensing of Curtain shield Airbag OFF switch Toyota park assist switch 115V AC Power outlet main switch Headlight cleaner If equipped Vehicles with navigation system: for details, refer to the “Navigation System Owner’s Manual.”... -
Page 5: Instrument Cluster
Low speed four-wheel drive indicator Center differential lock indicator Cruise control indicator Anti-lock Brake System warning If indicator does not turn off within a few seconds of starting engine, there may be a malfunction. Have vehicle inspected by your Toyota dealer. -
Page 6: Keyless Entry 1
OVERVIEW Keyless entry Locking operation Unlocking operation Push ONCE: Driver door NOTE: If a door is not opened within 60 seconds of unlocking, all doors will relock for safety. Panic button Smart Key system Start function Carrying Push NOTE: Gear shift lever must be in Park and brake pedal depressed. Power (without starting engine) Without depressing the brake pedal, pressing the “ENGINE START STOP”... -
Page 7: Light Control-Instrument Panel
OVERVIEW Fuel tank door release and cap Turn Pull Store NOTE: Tighten until one click is heard. If the cap is not tightened enough, Check Engine “ indicator may illuminate. Hood release Pull Pull up latch and raise hood Light control-Instrument panel Brightness control Engine maintenance... -
Page 8: Auto Lock Functions 1
Automatic Transmission Park* Reverse Neutral Drive “S” mode * The “ENGINE START STOP” switch must be in IGNITION ON mode and the brake pedal depressed to shift from Park. “S” (Sequential) mode Shift the shift lever to “S” position from “D” position. Floor shift type: : Upshift (push and release) : Downshift (pull and release) -
Page 9: Seat Adjustments-Front
FEATURES/OPERATIONS Seat adjustments-Front Seat position, cushion angle and height Seatback angle Lumbar support (driver side only) Seat adjustments-Rear Second row Third row Seatback angle Seat position Refer to the Owner’s Manual for more details. Seats-Head restraints Front Angle Height Lock release button Seats-Tumbling second row seats (1) Stow the seat belt buckles and lower the head restraints. - Page 10 FEATURES/OPERATIONS Seats-Tumbling third row seats Pull Push Seat hook cover Returning seats (1) Stow the seat belt buckles. (2) Stow the center head restraint. (3) Hook the seat belt to the seat belt hangers. (4) Fold down the outer head restraints. (5) Fold the seats.
-
Page 11: Back Door
FEATURES/OPERATIONS Windshield wipers & washers Front Adjust interval* Single wipe Interval wipe Slow Fast * Intermittent windshield wiper interval adjustment Rotate to increase/decrease wipe frequency. Rear Windows-Power Driver side Window lock switch Down Automatic operation Push the switch completely down or pull it completely up and release to fully open or close. -
Page 12: Air Conditioning/Heating
FEATURES/OPERATIONS Air Conditioning/Heating Front Air Conditioning Temperature selector (driver side/rear left passenger side*) Climate control OFF “4ZONE” button Indicator ON: Separate temperature settings for driver, front passenger and rear passengers. Indicator OFF: Synchronize temperature settings for driver and all passengers. Fan speed (front/rear*) Micro dust and pollen removal mode ON/OFF Windshield wiper de-icer... -
Page 13: Rear Seat Entertainment System
FEATURES/OPERATIONS Audio Preset buttons - functions in other modes indicated above number Eject CD Station/CD track scan Push to turn ON/OFF Mode Seek station/ Push to skip CD track select up/down CD and radio category type CD PLAYER To scan tracks on a disc Push and hold “SCAN.” Push again to hold selection. - Page 14 FEATURES/OPERATIONS Cruise control Turning system ON/OFF Functions Increase speed Cancel Decrease speed The set speed may also be cancelled by depressing the brake pedal. The set speed may be resumed once vehicle speed exceeds 25 mph. Crawl control Medium mode Low mode SPEED Speed selection switch...
-
Page 15: Clock
FEATURES/OPERATIONS Multi-information display Push “DISP” to change information in the following: (1) Current gas mileage (2) Average gas mileage after refueling (3) Miles left on remaining fuel (4) Average vehicle speed (5) Running distance from engine start (6) Tire inflation pressure (if equipped) Clock Refer to the Owner’s Manual for details on adjusting time. -
Page 16: Tilt And Telescopic Steering Wheel
FEATURES/OPERATIONS Tilt and telescopic steering wheel Away Toward from the driver driver Down Note: Do not attempt to adjust while the vehicle is in motion. Parking brake Release (2) Push Pull (3) Lower Cup holders Front Front Control switch Rear (1) Pull slightly Cool box (if equipped) Indicator... -
Page 17: Seat Belts-Shoulder Belt Anchor
If the tire pressure indicator flashes for more than 60 seconds and then remains on, take the vehicle to your local Toyota dealer. Note: The warning light may come on due to temperature changes or changes in tire pressure from natural air leakage. If the system has not been initialized recently, setting the tire pressures to factory specifications should turn off the light. -
Page 18: Spare Tire & Tools
Doors-Child safety locks Rear door Moving the lever to “LOCK” will allow the door to be opened only from the outside. Spare tire & tools Tool location Jack Removing the spare tire (1) Remove the cover. (2) Insert the jack handle extension into the lowering screw. (3) Lower the spare tire completely to the ground. - Page 19 MN 00505-QRG09-LC Printed in the USA 7/08...
