Table of Contents

Advertisement

Quick Links

See also: Quick Reference Manual

TABLE OF CONTENTS

1
2
3
4
When trouble
5
arises
6
specifications
For U.S.
7
owners
Index
L/C200_U (OM60D97U)
Adjusting and operating features such as door locks,
mirrors, and steering column.
Driving, stopping and safe-driving information.
Air conditioning and audio systems, as well as other in-
terior features for a comfortable driving experience.
Cleaning and protecting your vehicle, performing do-it-
yourself maintenance, and maintenance information.
What to do if the vehicle needs to be towed, gets a flat
tire, or is involved in an accident.
Detailed vehicle information.
Reporting safety defects for U.S. owners.
Alphabetical listing of information contained in this
manual.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2009 land cruiser and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Toyota 2009 land cruiser

Summary of Contents for Toyota 2009 land cruiser

  • Page 1: Table Of Contents

    TABLE OF CONTENTS Adjusting and operating features such as door locks, Before driving mirrors, and steering column. When driving Driving, stopping and safe-driving information. Interior Air conditioning and audio systems, as well as other in- features terior features for a comfortable driving experience. Maintenance Cleaning and protecting your vehicle, performing do-it- and care...

  • Page 2: For Your Information

    Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehi- cle. This vehicle should not be modified with non-genuine Toyota prod- ucts.
  • Page 3 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle. Perchlorate Material Special handling may apply, See www.dtsc.ca.gov/hazardouswaste/perchlorate.
  • Page 4 CAUTION General precautions while driving Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that will hurt or kill you, your occupants or others.
  • Page 5 This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
  • Page 6 L/C200_U (OM60D97U)
  • Page 7 1-1. Key information Keys The following keys are provided with the vehicle. Electronic keys • Operating the smart key system (→P. 26) • Operating wireless remote control function (→P. 40) Mechanical keys Key number plate L/C200_U (OM60D97U)
  • Page 8 Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made at your Toyota dealer using the key number plate. (→P. 492)
  • Page 9 1-2. Opening, closing and locking the doors Smart key system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) ITY12C002 Locks and unlocks the doors (→P. 27) Locks and unlocks the doors (→P.
  • Page 10 1-2. Opening, closing and locking the doors Locking and unlocking the doors Side door handle Press the lock button to lock the doors. Pressing and holding the button closes the windows and moon roof. ITY12C008 Grip the handle to unlock the doors.
  • Page 11 1-2. Opening, closing and locking the doors Press the unlock button to unlock the doors. The door cannot be unlocked for 3 seconds after the door is locked. Lock the back door again when you leave the vehicle. The back door will not lock automatically after it has been opened and then closed.
  • Page 12 1-2. Opening, closing and locking the doors Effective range (areas within which the electronic key is detected) When locking or unlock- ing the doors The system can be oper- ated when the electronic key is within about 2.3 ft. (0.7 m) of an outside door handle.
  • Page 13 1-2. Opening, closing and locking the doors Operation signals A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) Door lock buzzer If a door is not fully closed, a buzzer sounds continuously if an attempt to lock the door is made.
  • Page 14 1-2. Opening, closing and locking the doors Switching the door unlock function If it is possible to set which doors the entry function unlocks. STEP Turn the “ENGINE START STOP” switch OFF. STEP When the indicator on the key surface is turned off, press and hold for approximately 5 seconds while pressing the key.
  • Page 15 1-2. Opening, closing and locking the doors Battery-saving function In the following circumstances, the entry function is disabled in order to pre- vent the vehicle and electronic key batteries from discharging. When the entry function has not been used for 2 weeks or more When the electronic key has been left within approximately 3 ft.
  • Page 16 1-2. Opening, closing and locking the doors Note for the smart key system Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases. • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
  • Page 17 1-2. Opening, closing and locking the doors Alarms and warning indicators A combination of exterior and interior alarms as well as warnings displayed on the multi-information display are used to prevent theft of the vehicle and unforeseeable accidents resulting from erroneous operation. Perform the appropriate correction procedure described in the following table.
  • Page 18 1-2. Opening, closing and locking the doors Alarm Situation Correction procedure When the “ENGINE START STOP” switch is in IGNITION ON or ACCES- Shift the shift lever to Interior alarm SORY mode, an attempt “P” and turn the sounds continu- was made to open the “ENGINE START ously...
  • Page 19 Locking and unlocking the doors: Use the mechanical key. (→P. 494) Starting the engine (→P. 152) When the electronic key battery is fully depleted →P. 423 Customization that can be configured at Toyota dealer Settings (e.g. smart key system) can be changed. (Customizable features →P. 533) L/C200_U (OM60D97U)
  • Page 20 1-2. Opening, closing and locking the doors Certification for the smart key system FCC ID:NI4TMLF-5 NOTE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 21 1-2. Opening, closing and locking the doors L/C200_U (OM60D97U)
  • Page 22 (→P. 28) The radio waves may affect the operation of such devices. If necessary, the smart entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of emitting the radio waves. Then, consult your doctor to see if you should disable the smart entry function.
  • Page 23 1-2. Opening, closing and locking the doors Wireless remote control The wireless remote control can be used to lock and unlock the vehi- cle. Locks all doors Unlocks all doors Pressing the button unlocks the driver’s door. Pressing the button again within 3 seconds unlocks the other doors.
  • Page 24 Starting the engine (→P. 151) When the electronic key battery is fully depleted →P. 423 Conditions affecting operation →P. 30 Customization that can be configured at Toyota dealer Settings (e.g. 2-step unlocking function) can be changed. (Customizable features →P. 533) L/C200_U (OM60D97U)
  • Page 25 1-2. Opening, closing and locking the doors Certification for wireless remote control FCC ID:HYQ14AAB FCC ID:HYQ13BZS NOTE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 26 1-2. Opening, closing and locking the doors Side doors The vehicle can be locked and unlocked using the smart key system, wireless remote control or door lock switch. Entry function →P. 26 Wireless remote control →P. 40 Door lock switch Locks all doors Unlocks all doors Inside lock button...
  • Page 27 1-2. Opening, closing and locking the doors Locking the driver’s doors from the outside without a key Move the inside lock button to the lock position. STEP Close the door. STEP The door cannot be locked if the “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode, or the electronic key is left inside the vehicle.
  • Page 28 1-2. Opening, closing and locking the doors Automatic door locking and unlocking systems The following functions can be set or canceled: Function Operation Shift position linked Shifting the shift lever out of “P” locks all door locking function doors. Shift position linked Shifting the shift lever to “P”...
  • Page 29 Using the mechanical key The doors can also be locked and unlocked with the mechanical key. (→P. 494) Customization that can be configured at Toyota dealer Settings (e.g. unlocking function using a key) can be changed. (Customiz- able features →P. 533)
  • Page 30 1-2. Opening, closing and locking the doors CAUTION To prevent an accident Observe the following precautions while driving the vehicle. Failing to do so may result in a door opening and an occupant falling out, resulting in death or serious injury. Always use a seat belt.
  • Page 31 1-2. Opening, closing and locking the doors Back door The back door can be opened using the back door opener. Unlock the back door STEP Raise the back door ITY12C035 Pull the handle STEP ITY12C018 The back door can be locked and unlocked using the entry function, wireless remote control or door lock switch.
  • Page 32 1-2. Opening, closing and locking the doors Rear step bumper The rear step bumper is for rear end protection and easier step- up loading. When closing the back door Make sure that the lower side of the back door is closed before closing the upper side of the back door.
  • Page 33 1-2. Opening, closing and locking the doors CAUTION While driving Observe the following precautions. Failing to do so may result in death or serious injury. Keep the back door closed. This not only keeps personal belongings from being thrown out, but also prevents exhaust gases from entering the vehicle.
  • Page 34 1-3. Adjustable components (seats, mirrors, steering wheel) Front seats Seat position fore/aft control switch Seatback angle control switch Seat cushion (front) angle control switch Vertical height control switch Lumbar support control switch (driver’s side only) Active head restraint When a front seatback receives strong impact, head...
  • Page 35 1-3. Adjustable components (seats, mirrors, steering wheel) Active head restraint Even small forces applied to the seatback may cause the head restraint to move. This does not indicate a problem. CAUTION Seat adjustment Be careful that the seat does not hit passengers or luggage. Do not recline the seat more than necessary when the vehicle is in motion to reduce the risk of sliding under the lap belt.
  • Page 36 1-3. Adjustable components (seats, mirrors, steering wheel) Rear seats Second seat Seatback angle adjustment lever Seat position adjustment lever Third seat ITY13C008 L/C200_U (OM60D97U)
  • Page 37 1-3. Adjustable components (seats, mirrors, steering wheel) Tumbling the second seats and third seat entry For easy access to the third seat, perform in “Tumbling sec- STEP ond seats”. (→P. 55) Before tumbling the second seats Stow the seat belt buckles and STEP lower the head restraints to the lowest position.
  • Page 38 1-3. Adjustable components (seats, mirrors, steering wheel) Tumbling the second seats Fold down the seatback while STEP pulling seatback angle adjustment lever, and swing the whole seat up and forward. Hook the holding strap to the STEP assist grip and secure the seat by pulling its free end.
  • Page 39 1-3. Adjustable components (seats, mirrors, steering wheel) Remove the seat hook covers STEP from the back of the seat cush- ion, and install them on the seat hooks. When returning the second seat to its original position, remove the seat hook covers from the floor and install them in the back of the ITY13C025 seat cushion.
  • Page 40 1-3. Adjustable components (seats, mirrors, steering wheel) Folding up the third seats Before folding up the third seats Stow the seat belts buckles. STEP ITY13C018 Stow the center head restraint in the seatback. (→P. 68) STEP Pass the outer seat belts through STEP the seat belt hangers and secure the seat belt plates.
  • Page 41 1-3. Adjustable components (seats, mirrors, steering wheel) Folding up the third seats Fold down the head restraints STEP while pulling the head restraint angle lever. ITY13C022 Push the seatback angle levers STEP and fold the third seats. Pull the seat leg lock release STEP levers.
  • Page 42 1-3. Adjustable components (seats, mirrors, steering wheel) Secure the seats by the strikers. STEP Remove the seat hook covers STEP from the back of the seat cush- ion, and install them on the seat hooks. ITY13C030 Returning the third seats Remove the seat hook covers STEP from the floor and install them...
  • Page 43 1-3. Adjustable components (seats, mirrors, steering wheel) Secure the seats by the strikers. STEP Pull the handle and raise the STEP seatbacks. Fix the handle securely in its orig- inal position after use. Raise the head restraints. STEP L/C200_U (OM60D97U)
  • Page 44 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION Seat adjustment Do not recline the seat more than necessary when the vehicle is in motion, to reduce the risk of sliding under the lap belt. If the seat is too reclined, during an accident the lap belt may slide past the hips and apply restraint forces directly to the abdomen or your neck may contact the shoulder belt, increasing the risk of death or serious injury.
  • Page 45 1-3. Adjustable components (seats, mirrors, steering wheel) Driving position memory system Your preferred driving position (the position of the driver’s seat, steering wheel and outside rear view mirrors) can be entered into the computer’s memory and recalled with the touch of a button. It is also possible to set this function to activate automatically when the doors are unlocked.
  • Page 46 1-3. Adjustable components (seats, mirrors, steering wheel) Recalling the memorized position Check that the shift lever is set in “P”. Turn the “ENGINE START STOP” switch to IGNITION ON STEP mode. Press button “1”, “2” or “3” to STEP recall the desired position. SE T ITY13C038 Linking driving position memory with door unlock operation...
  • Page 47 1-3. Adjustable components (seats, mirrors, steering wheel) Open one of the doors. STEP If a door is not opened within 30 seconds after is pressed, the doors will be locked again and the alarm will automatically be set. In case that the alarm is triggered, immediately stop the alarm. (→P.
  • Page 48 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION Seat adjustment caution Take care during seat adjustment that the seat does not strike the rear pas- senger or squeeze your body against the steering wheel. L/C200_U (OM60D97U)
  • Page 49 1-3. Adjustable components (seats, mirrors, steering wheel) Head restraints Front seats Vertical adjustment Press hold lock release button when lowering the head restraint. Lock release button Angle adjustment ITY13C105 Second seats Vertical adjustment Press hold lock release button when lowering the head restraint.
  • Page 50 1-3. Adjustable components (seats, mirrors, steering wheel) Third outboard seats To fold Pull the head restraint angle lever to fold the head restraint. ITY13C040 Adjusting the height of the head restraints Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears.
  • Page 51 1-3. Adjustable components (seats, mirrors, steering wheel) Removing the head restraints Front seats, second seats and third center seat Pull the head restraint up while pressing the lock release button. ITO13C143 Third outboard seats Push a flathead screwdriver into the slot. STEP The slot is located on the left side of the left head restraint anchor.
  • Page 52 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION Head restraint precautions Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury. Use the head restraints designed for each respective seat. Adjust the head restraints to the correct position at all times. After adjusting the head restraints, push down on them and make sure they are locked in position.
  • Page 53 1-3. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. Correct use of the seat belts l Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
  • Page 54 1-3. Adjustable components (seats, mirrors, steering wheel) Adjusting the height of the belt (front, second outboard seat) Down Move the height adjuster up and down as needed until you hear a click. ITY13C055 Third center seat belt The third center seat belt is a 3-point type restraint with 2 buckles. Both seat belt buckles must be correctly located and securely latched for proper operation.
  • Page 55 1-3. Adjustable components (seats, mirrors, steering wheel) Release method The belt can be completely released when not required, such as when removing the third seat. To release the hooked tab, insert STEP the mechanical key into the hole on the buckle with the light gray buckle release button.
  • Page 56 1-3. Adjustable components (seats, mirrors, steering wheel) Seat belt pretensioners (front, second outboard seats) The pretensioner helps the seat belt to quickly restrain the occu- pant by retracting the seat belt when the vehicle is subjected to certain types of severe frontal collision.
  • Page 57 1-3. Adjustable components (seats, mirrors, steering wheel) Pregnant women Obtain medical advice and wear the seat belt in the proper way. (→P. 70) Women who are pregnant should position the lap belt as low as possible over the hips in the same manner as other occu- pants.
  • Page 58 Seat belt extender If your seat belts cannot be fastened securely because they are not long enough, personalized seat belt extender is available from your Toyota dealer free of charge. ITY13C060 L/C200_U (OM60D97U)
  • Page 59 If the pretensioner has activated, the seat belt becomes locked: it cannot be further extended, nor will it return to the stowed position. The seat belt cannot be used again and must be replaced at your Toyota dealer. L/C200_U (OM60D97U)
  • Page 60 Do not attempt to install, remove, modify, disassemble or dispose of a seat belt. Have any necessary repairs carried out by your Toyota dealer. Inap- propriate handling of the pretensioner may cause it to activate or operate improperly and may cause death or serious injury.
  • Page 61 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION Using a seat belt extender Do not wear the seat belt extender, if you can fasten the seat belt without the extender. Do not use the seat belt extender when installing a child restraint system, because the belt will not securely hold the child restraint system, increas- ing the risk of death or serious injury in the event of a collision.
  • Page 62 1-3. Adjustable components (seats, mirrors, steering wheel) Steering wheel The steering wheel can be adjusted to a comfortable position while the “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode. Down Toward the driver Away from the driver Auto tilt away and auto return When “ENGINE...
  • Page 63 1-3. Adjustable components (seats, mirrors, steering wheel) One-touch adjustment of the steering position A desired steering position can be entered to memory and recalled automat- ically by the driving position memory. (→P. 62) CAUTION While driving Do not adjust the steering wheel. Doing so may cause the driver to mishandle the vehicle and an accident, resulting in death or serious injury.
  • Page 64 1-3. Adjustable components (seats, mirrors, steering wheel) Inside rear view mirror In auto mode, sensors are used to detect the headlights of vehicles behind and automatically reduces the reflected light. Turns auto mode on/off The indicator comes on when auto mode is turned on. The mirror will revert to the auto mode each time the “ENGINE...
  • Page 65 1-3. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted using the switch when the “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode. Select a mirror to adjust STEP Left Right Adjust the mirror STEP Right...
  • Page 66 1-3. Adjustable components (seats, mirrors, steering wheel) When the mirrors are fogged up Turn on the outside rear view mirror defoggers to defog the mirrors. (→P. 268) Auto anti-glare function When the anti-glare inside rear view mirror is set to auto mode, the outside rear view mirrors will activate in conjunction with the anti-glare inside rear view mirror to reduce reflected light.
  • Page 67 1-3. Adjustable components (seats, mirrors, steering wheel) NOTICE If ice should jam the mirror Do not operate the control or scrape the mirror face. Use a spray de-icer to free the mirror. L/C200_U (OM60D97U)
  • Page 68 1-4. Opening and closing the windows and moon roof Power windows The power windows can be opened and closed using the following switches. Closing One-touch closing Opening One-touch opening :Pressing the switch in the opposite direction will stop window travel partway. Lock switch Press the switch down to lock passenger window switches.
  • Page 69 If an object becomes caught between the window and the window frame, window travel is stopped and the window is opened slightly. Customization that can be configured at Toyota dealer Settings (e.g. linked door lock operation) can be changed. (Customizable features →P.
  • Page 70 1-4. Opening and closing the windows and moon roof CAUTION Closing the windows Observe the following precautions. Failing to do so may result in death or serious injury. Check to make sure that all passengers do not have any part of their body in a position where it could be caught when a window is being operated.
  • Page 71 1-4. Opening and closing the windows and moon roof Moon roof Use the overhead switches to open, close, and tilt the moon roof up and down. Opening and closing Open Stops just before it is opened fully. Press the switch again to fully open.
  • Page 72 1-4. Opening and closing the windows and moon roof The moon roof can be operated when The “ENGINE START STOP” switch is in IGNITION ON mode. Linked door lock moon roof operation The moon roof can be opened and closed using the mechanical key. (→P.
  • Page 73 “ENGINE START STOP” switch is turned OFF and the driver’s door is opened with the moon roof open. Customization that can be configured at Toyota dealer Settings (e.g. linked door lock operation) can be changed. (Customizable features →P.
  • Page 74 1-5. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap. Before refueling the vehicle Turn the “ENGINE START STOP” switch OFF and ensure that all the doors and windows are closed. Opening the fuel tank cap Pull the lever.
  • Page 75 1-5. Refueling Closing the fuel tank cap When replacing the fuel tank cap, turn it until a clicking sound is heard. After releasing your hand, the cap will turn slightly to the opposite direction. Fuel types Use unleaded gasoline. (87 Octane Rating [Research Octane Number 91] or higher) Fuel tank capacity Approximately 24.6 gal.
  • Page 76 When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Failure to do so may cause a fire or other incident which may result in death or serious injury.
  • Page 77 1-5. Refueling NOTICE Refueling Do not spill fuel during refueling. Failing to do so may damage the vehicle, such as causing the exhaust sys- tems to operate abnormally or damaging fuel system components or the vehicle’s painted surface. L/C200_U (OM60D97U)
  • Page 78 1-6. Theft deterrent system Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if the key has not been previously registered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. The indicator light flashes after the “ENGINE START STOP”...
  • Page 79 1-6. Theft deterrent system System maintenance The vehicle has a maintenance-free type of engine immobilizer system. Conditions that may cause the system to malfunction If the key is in contact with a metallic object. If the key is in close proximity to or touching a key to the security system (key with a built-in transponder chip) of another vehicle.
  • Page 80 1-6. Theft deterrent system Alarm The system sounds the alarm and flashes lights when forcible entry is detected. Triggering of the alarm The alarm is triggered in the following situations. l A locked door is unlocked or opened in any way other than using the smart key system, the wireless remote control or using the mechanical key.
  • Page 81 1-6. Theft deterrent system Deactivating or stopping the alarm Do one of the following to deactivate or stop the alarm. l Unlock the doors using the smart key system or the wireless remote control. l Start the engine. (The alarm will be deactivated or stopped after a few seconds.) Items to check before locking the vehicle To prevent unexpected triggering of the alarm and vehicle theft, make sure...
  • Page 82 1-6. Theft deterrent system Theft prevention labels These labels are attached to the vehicle to reduce vehicle theft by facilitating the tracing and recovery of parts from sto- len vehicles. Do not remove under penalty of law. ITY16C012 L/C200_U (OM60D97U)
  • Page 83 1-7. Safety information Correct driving posture Drive with a good posture as follows: Sit upright and well back in the seat. (→P. 51) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
  • Page 84 1-7. Safety information CAUTION While driving Do not adjust the position of the driver’s seat. Doing so could cause the driver to lose control of the vehicle. Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.
  • Page 85 1-7. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. Front airbags Driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas-...
  • Page 86 1-7. Safety information Side and curtain shield airbags Side airbags Can help protect the torso of the front and second outboard seat occupants. Curtain shield airbags Can help protect primarily the head of front seat occupants, sec- ond and third outboard seat occupants. L/C200_U (OM60D97U)
  • Page 87 1-7. Safety information Airbag system components Occupant detection sensor Side airbag (second outboard seat) Knee airbag Driver airbag Curtain shield airbag Driver’s seat position sensor Front passenger airbag Driver’s seat belt buckle Front passenger occupant switch classification indicator light Floor sensor Side and curtain shield airbag sensor Roll sensing of curtain shield...
  • Page 88 1-7. Safety information Your vehicle is equipped with ADVANCED AIRBAGS designed based on US motor vehicle safety standards (FMVSS208). The airbag sys- tem controls airbag deployment power for the driver and front pas- senger. The driver airbag system consists of the driver seat’s position sensor etc.
  • Page 89 1-7. Safety information Operating conditions (front airbags) The SRS front airbags will deploy if the severity of the frontal impact is above the designed threshold level, comparable to an approximate 15 mph (25 km/h) collision when the vehicle impacts straight into a fixed bar- rier that does not move or deform.
  • Page 90 1-7. Safety information Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front, side and curtain shield airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration.
  • Page 91 1-7. Safety information Types of collisions that may not deploy the SRS airbag (side and curtain shield airbags) The SRS side airbag and curtain shield airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a colli- sion to the side of the vehicle body other than the passenger compartment.
  • Page 92 1-7. Safety information When to contact your Toyota dealer In the following cases, contact your Toyota dealer as soon as possible. Do not disconnect the battery cables before contacting your Toyota dealer. Any of the SRS airbags have been inflated.
  • Page 93 1-7. Safety information CAUTION SRS airbag precautions Observe the following precautions regarding the airbags. Failure to do so may cause death or serious injury. The driver and all passengers in the vehicle must wear their seat belts properly. The SRS airbags are supplemental devices to be used with the seat belts. The SRS driver airbag deploys with considerable force, and can cause death or serious injury especially if the driver is very close to the airbag.
  • Page 94 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are the safest for infants and children.
  • Page 95 1-7. Safety information CAUTION SRS airbag precautions Do not sit on the edge of the seat or lean against the dashboard. ITY17C021 Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger. Do not drive the vehicle while the driver or passenger have items resting on their knees.
  • Page 96 1-7. Safety information CAUTION SRS airbag precautions Do not attach anything to or lean any- thing against areas such as the dash- board or steering wheel pad or lower portion of the instrument panel. These items can become projectiles when SRS driver, front passenger and knee airbags deploy.
  • Page 97 Wash off any residue as soon as possible to prevent skin irritation. If the areas where the SRS airbags are stored, such as the steering wheel pad and front, center and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer. L/C200_U (OM60D97U)
  • Page 98 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbag may malfunction or deploy (inflate) accidentally, causing death or serious injury.
  • Page 99 1-7. Safety information Deactivating the curtain shield airbags in a vehicle rollover On/off (Pressing longer) The “RSCA OFF” (roll sensing of curtain shield airbags off) indicator light turns on. (Only when the “ENGINE START STOP” switch OFF.) This switch only should be used In a situation where the inflation is not desired (such as during extreme off road driving).
  • Page 100 1-7. Safety information Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classifica- tion system. This system detects the conditions of the front passen- ger seat and activates or deactivates the devices for front passenger. SRS warning light AIR BAG OFF indicator light AIR BAG ON indicator light...
  • Page 101 1-7. Safety information Condition and operation in the front passenger occupant classi- fication system Adult AIR BAG ON and AIR BAG OFF indicator lights Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Flashing Front passenger airbag and knee airbag Side airbag in the front passenger seat Devices Activated...
  • Page 102 1-7. Safety information Unoccupied AIR BAG ON and AIR BAG OFF Not illumi- indicator lights nated Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Front passenger airbag and knee airbag Deactivated Side airbag in the front passenger seat Devices Curtain shield airbag Activated...
  • Page 103 1-7. Safety information System malfunction AIR BAG ON and AIR BAG OFF indicator lights Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Front passenger airbag and knee airbag Deactivated Side airbag in the front passenger seat Devices Curtain shield airbag on the front passenger side...
  • Page 104 1-7. Safety information CAUTION Front passenger occupant classification system precautions Observe the following precautions regarding front passenger occupant clas- sification system. Failure to do so may cause death or serious injury. Wear the seat belt properly. Make sure the front passenger’s seat belt tab has not been left inserted into the buckle before someone sits in the front passenger seat.
  • Page 105 Do not kick the front passenger seat or subject it to severe impact. Other- wise, the SRS warning light may come on to indicate a malfunction in the detection system. In this case, contact your Toyota dealer immediately. Do not use a seat accessory, such as a cushion or seat cover, that covers the seat cushion surface.
  • Page 106 1-7. Safety information Child restraint systems A child restraint system for a small child or baby must itself be prop- erly restrained on the seat with the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. now require the use of child restraint systems.
  • Page 107 1-7. Safety information Forward facing—Convertible seat Booster seat When installing the child restraint system on the front passenger seat When you have to use a child restraint system on the front passenger seat, adjust the following: The seatback to the most upright posi- tion The seat cushion to the fully rearward and highest position...
  • Page 108 In an accident, the child can be crushed against the windshield, or between you and the vehicle’s interior. Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
  • Page 109 1-7. Safety information CAUTION Child restraint precautions Do not use the seat belt extender when installing a child restraint system on the front or rear passenger seat. If installing a child restraint system with the seat belt extender connected to the seat belt, the seat belt will not securely hold the child restraint system, which could cause death or seri- ous injury to the child or other passengers in the event of collision.
  • Page 110 1-7. Safety information Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure the child restraints using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Chil- dren) system.
  • Page 111 1-7. Safety information Installation with LATCH system Fold the seatback forward and STEP then adjust it as upright as possi- ble. Take off the covers between the STEP seat cushion and seatback, then confirm position LATCH anchors below the sym- bol in the seatback.
  • Page 112 1-7. Safety information Type A Latch the hooks of the STEP lower straps onto the LATCH anchors. If the child restraint has a STEP top tether strap, the top tether strap should be latched onto the top tether strap anchor. ITY17C124 Type B Latch the buckles onto...
  • Page 113 1-7. Safety information Installing child restraints using a seat belt (child restraint lock function belt) Rear-facing ⎯ Infant seat/convertible seat Fold the seatback while pulling STEP the seatback angle lever. Return the seatback and secure it at the first lock position. (→P.
  • Page 114 1-7. Safety information Fully extend the shoulder belt STEP and then allow it to retract slightly in order to activate the ALR lock mode. Lock mode allows the seat belt to retract only. While pushing the infant seat/ STEP convertible seat down into the seat, allow the shoulder belt to retract until the infant seat/con- vertible seat is securely in place.
  • Page 115 1-7. Safety information Forward-facing ⎯ Convertible seat Fold the seatback while pulling STEP the seatback angle lever. Return the seatback and secure it at the first lock position. (→P. 53) Place the convertible seat on the STEP seat facing the front of the vehi- cle.
  • Page 116 1-7. Safety information Fully extend the shoulder strap STEP and then allow it to retract slightly into the ALR lock mode. Lock mode allows the seat belt to retract only. While pushing the convertible STEP seat into the seat, allow the shoulder belt to retract until the convertible seat is securely in place.
  • Page 117 1-7. Safety information Booster seat Fold the seatback while pulling STEP the seatback angle lever. Return the seatback and secure it at the first lock position. (→P. 53) Place the booster seat on the STEP seat facing the front of the vehi- cle.
  • Page 118 1-7. Safety information Removing a child restraint installed with a seat belt Press the buckle release button and fully retract the seat belt. Child restraint systems with a top tether strap Secure the child restraint using a seat belt or lower anchors, STEP and do the following.
  • Page 119 1-7. Safety information Open the anchor bracket cover, latch the hook onto the STEP anchor bracket and tighten the top tether strap. Make sure the top tether strap is securely latched. Outside Center Outside only: Adjust the head STEP restraint to the downmost posi- tion.
  • Page 120 1-7. Safety information Laws and regulations pertaining to anchorages The LATCH system conforms to FMVSS225. Child restraint systems conforming to FMVSS213 specifications can be used. This vehicle is designed to conform to the SAE J1819. CAUTION When installing a booster seat Do not fully extend the shoulder belt to prevent the belt from going to ALR lock mode: (→P.
  • Page 121 1-7. Safety information CAUTION When installing a child restraint system Follow the directions given in the child restraint system installation manual and fix the child restraint system securely in place. If the child restraint system is not correctly fixed in place, the child or other passengers may be seriously injured or even killed in the event of sudden braking or an accident.
  • Page 122 1-7. Safety information CAUTION When installing a child restraint system Ensure that the belt and tab are securely locked and the seat belt is not twisted. Push and pull the child restraint system from side to side and forward to be sure it is secure.
  • Page 123 1-7. Safety information L/C200_U (OM60D97U)
  • Page 124 2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing. Starting the engine (→P. 152) Driving With the brake pedal depressed, shift the shift lever to “D”. STEP (→P. 155) STEP Release the parking brake. (→P.
  • Page 125 This type of brake system needs bedding-down of the brake shoes periodi- cally or whenever the parking brake shoes and/or drums are replaced. Have your Toyota dealer perform the bedding-down. Operating your vehicle in a foreign country Comply with the relevant vehicle registration laws and confirm the availability of the correct fuel.
  • Page 126 Large amounts of exhaust in the vehi- cle can cause driver drowsiness and an accident, resulting in death or a serious health hazard. Have the vehicle inspected by your Toyota dealer immediately. L/C200_U (OM60D97U)
  • Page 127 2-1. Driving procedures CAUTION Do not under any circumstances shift the shift lever to “P” or “R” while the vehicle is moving. Doing so can cause significant damage to the transmission and may result in a loss of vehicle control. Do not shift the shift lever to “N”...
  • Page 128 2-1. Driving procedures CAUTION When driving on slippery road surfaces Sudden braking, acceleration and steering may cause tire slippage and reduce your ability to control the vehicle, resulting in an accident. Sudden changes in engine speed, such as engine braking caused by up- shifting or down-shifting, may cause the vehicle to skid, resulting in an accident.
  • Page 129 The exhaust should be checked occasionally. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in death or a serious health hazard.
  • Page 130 2-1. Driving procedures CAUTION When taking a nap in the vehicle Always turn the engine off. Otherwise, you may accidentally move the shift lever or depress the accelerator pedal, which could cause an accident or fire due to engine overheating. Additionally, if the vehicle is parked in a poorly ventilated area, exhaust gases may collect and enter the vehicle, leading to death or a serious health hazard.
  • Page 131 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have your Toyota dealer check and replace the brake pads as soon as pos- sible. The rotor damage can result if the pads are not replaced when needed.
  • Page 132 Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following. Brake function Changes in quantity and quality of oil and fluid used for the engine, trans- mission, transfer, differentials, etc.
  • Page 133 2-1. Driving procedures Engine (ignition) switch Modes can be switched by pressing the “ENGINE START STOP” switch when carrying the electronic key on your person. (The engine can be started in any mode by operating the switch at the same time as depressing the brake pedal.) Changing “ENGINE START STOP”...
  • Page 134 2-1. Driving procedures Starting the engine Check that the parking brake is set. STEP Check that the shift lever is set in “P”. STEP Sit in the driver’s seat and firmly depress the brake pedal. STEP The “ENGINE START STOP” switch indicator turns green. Press the “ENGINE START STEP STOP”...
  • Page 135 When the “ENGINE START STOP” switch indicator flashes in amber The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. Auto power off function If the vehicle is left in ACCESSORY mode for more than an hour with the shift lever in “P”, the “ENGINE START STOP”...
  • Page 136 2-1. Driving procedures CAUTION When starting the engine Always start the engine while sitting in the driver’s seat. Do not depress the accelerator pedal while starting the engine under any circumstances. Doing so may cause an accident resulting in death or serious injury. Stopping the engine in an emergency If you want to stop the engine in an emergency while driving the vehicle, push and hold the “ENGINE START STOP”...
  • Page 137 2-1. Driving procedures Automatic transmission Select a shift position appropriate for the driving conditions. Shifting the shift lever While the “ENGINE START STOP” switch is in IGNITION ON mode, depress the brake pedal and move the shift lever. L/C200_U (OM60D97U)
  • Page 138 2-1. Driving procedures Shift position uses Shift position Function Parking the vehicle or starting the engine Reversing Neutral Normal driving “S” mode driving : To improve fuel consumption and reduce noises, set the shift lever in the “D” position for normal driving. : By selecting shift ranges using “S”...
  • Page 139 2-1. Driving procedures Selecting a driving mode The following patterns can be selected to suit current driving and operating conditions. Power mode For powerful acceleration and driving mountainous regions. Normal mode Second start mode For starting on slippery road surfaces, such as on snow. Press “2nd”...
  • Page 140 2-1. Driving procedures Changing shift ranges in “S” mode Shift the shift lever to the “S” position and operate the shift lever. Upshifting Downshifting ITY21C009 The initial shift range in “S” mode is automatically set to “5” or “4” according to the vehicle’s speed. However, the initial shift range may be set to “3”...
  • Page 141 2-1. Driving procedures Shift ranges and their functions Shift range Function Automatically selecting gears between 1 and 6 according to vehicle speed and driving conditions. Automatically selecting gears between 1 and 5 according to vehicle speed and driving conditions. Automatically selecting gears between 1 and 4 according to vehicle speed and driving conditions.
  • Page 142 If the “S” indicator does not come on even after shifting the shift lever to “S” This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Toyota dealer immediately. (In this situation, the vehicle will operate as if the shift lever is in “D”.) AI-SHIFT The AI-SHIFT automatically shifts the gear to the optimal position according to the driver performance and driving conditions.
  • Page 143 2-1. Driving procedures Turn signal lever Right turn Left turn Move and hold the lever partway to signal a lane change The right hand signal will flash until you release the lever. Move and hold the lever partway to signal a lane change The left hand signal will flash until you release the lever.

  • Page 144: Before Driving

    2-1. Driving procedures Parking brake Sets the parking brake Fully set the parking brake while depressing the brake pedal. Releases the parking brake Slightly raise the lever and lower it completely while press- ing the button. NOTICE Before driving Fully release the parking brake. Driving the vehicle with the parking brake set will lead to brake components overheating, which may affect braking performance and increase brake wear.
  • Page 145 2-1. Driving procedures Horn To sound the horn, press on or close to the mark. ITO21C031 L/C200_U (OM60D97U)
  • Page 146 2-2. Instrument cluster Gauges and meters The following gauges, meters and display illuminate when the “ENGINE START STOP” switch is in IGNITION ON mode. Tachometer Displays the engine speed in revolutions per minute. Engine coolant temperature gauge Displays the engine coolant temperature. Fuel gauge Displays the quantity of fuel remaining in the tank.
  • Page 147 2-2. Instrument cluster Odometer and trip meter Odometer: Displays the total distance the vehicle has been driven. Trip meter: Displays the distance the vehicle has been driven since the meter was last reset. Trip meters A and B can be used to record and display different distances independently.
  • Page 148 While driving When the voltmeter indicates more than 19 V or less than 9 V, the battery may be malfunctioning. Have your vehicle checked at your Toyota dealer. When the engine oil pressure gauge does not work properly, immediately stop the engine and contact your Toyota dealer.
  • Page 149 2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster and cen- ter panel inform the driver of the status of the vehicle’s various sys- tems. Instrument cluster Center panel (vehicles with navigation system) Center panel (vehicles without navigation system) L/C200_U (OM60D97U)
  • Page 150 2-2. Instrument cluster Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Roll sensing of curtain Turn signal indicator shield airbags off indica- (→P. 161) tor (→P. 116) Headlight high beam “PWR” mode indicator indicator (→P.
  • Page 151 Have the vehicle inspected by your Toyota dealer immediately if this occurs. L/C200_U (OM60D97U)
  • Page 152 The Multi-information display presents the driver with a variety of driving-related data. l Trip information (→P. 171) Displays driving range, fuel consumption and other cruis- ing-related information. l Toyota park assist system display (→P. 192) Automatically displayed when using Toyota park assist sys- tem. l Crawl Control display (→P.
  • Page 153 2-2. Instrument cluster Switch the display Display items can be switched by pressing the “DISP” button. Trip information Current fuel consumption Displays the current rate of fuel consumption. Average fuel consumption Displays the average fuel consumption since the vehicle was last refueled.
  • Page 154 2-2. Instrument cluster Driving range Displays the estimated maximum distance that can be driven with the quantity of fuel remaining. l This distance is computed based on your average fuel consumption. As a result, the actual distance that can be driven may differ from that dis- played.
  • Page 155 2-2. Instrument cluster System check display After switching the “ENGINE START STOP” switch to IGNITION ON mode, “LAND CRUISER” is displayed while system operation is checked. When the system check is complete, the normal screen will return. Tire inflation pressure Tire inflation pressure changes with temperature.
  • Page 156 2-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Type A The side marker, park- ing, tail, license plate and instrument panel lights turn on. The headlights and all lights listed above turn The headlights and all lights listed above turn on and off automati-...
  • Page 157 2-3. Operating the lights and wipers Type B The side marker, park- ing, tail, license plate and instrument panel lights turn on. The headlights and all lights listed above turn The headlights and all lights listed above turn on and off automati- cally.
  • Page 158 To turn the lights on again, turn the “ENGINE START STOP” switch to IGNI- TION ON mode, or turn the light switch off once and then back to the position. Customization that can be configured at Toyota dealer Settings (e.g. light sensor sensitivity) can be changed. (Customizable features →P. 533)
  • Page 159 2-3. Operating the lights and wipers Fog light switch The fog lights improve visibility in difficult driving conditions, such as in rain or fog. The fog lights can be used when the headlights are on low beam. Type A ITO23C053 L/C200_U (OM60D97U)
  • Page 160 2-3. Operating the lights and wipers Type B ITO23C066 L/C200_U (OM60D97U)
  • Page 161 2-3. Operating the lights and wipers Windshield wipers and washer (Type A) Wiper intervals can be adjusted for intermittent operation (when “INT” is selected). Intermittent windshield wiper operation Low speed windshield wiper operation High speed windshield wiper operation Temporary operation ITO23C054 Decreases the intermittent windshield wiper frequency...
  • Page 162 Windshield wiper features The rear window and outside rear view mirror defoggers automatically turn on when you operate the wipers. Customization that can be configured at Toyota dealer Settings (e.g. drip prevention function) can be changed. (Customizable features →P. 533)
  • Page 163 2-3. Operating the lights and wipers NOTICE When the windshield is dry Do not use the wipers, as they may damage the windshield. When there is no washer fluid spray from the nozzle Damage to the washer fluid pump may be caused if the lever is pulled toward you and held continually.
  • Page 164 2-3. Operating the lights and wipers Windshield wipers and washer (Type B) Wiper intervals can be adjusted for intermittent operation (when is selected). Intermittent windshield wiper operation Low speed windshield wiper operation High speed windshield wiper operation Temporary operation ITO23C071 Increases the intermittent windshield wiper frequency Decreases the intermittent...
  • Page 165 Windshield wiper features The rear window and outside rear view mirror defoggers automatically turn on when you operate the wipers. Customization that can be configured at Toyota dealer Settings (e.g. drip prevention function) can be changed. (Customizable features →P. 533)
  • Page 166 2-3. Operating the lights and wipers NOTICE When the windshield is dry Do not use the wipers, as they may damage the windshield. When there is no washer fluid spray from the nozzle Damage to the washer fluid pump may be caused if the lever is pulled toward you and held continually.
  • Page 167 2-3. Operating the lights and wipers Rear window wiper and washer Type A Intermittent window wiper operation Normal window wiper oper- ation Washer operation Washer operation ITO23C057 L/C200_U (OM60D97U)
  • Page 168 2-3. Operating the lights and wipers Type B Intermittent window wiper operation Normal window wiper oper- ation Washer operation Washer operation ITO23C088 The rear window wiper and washer can be operated when The “ENGINE START STOP” switch is in IGNITION ON mode. NOTICE When the rear window is dry Do not use the wipers, as they may damage the rear window.
  • Page 169 2-3. Operating the lights and wipers Headlight cleaner switch (if equipped) Washer fluid can be sprayed on the headlights. Press the switch to clean the headlights. ITY23C039 The headlight cleaner can be operated when The “ENGINE START STOP” switch is in IGNITION ON mode and the head- light switch is turned on.
  • Page 170 2-4. Using other driving systems Cruise control Use the cruise control to maintain a set speed without using the accelerator. Indicator Cruise control switch ITO24C067 Set the vehicle speed STEP Press the “ON-OFF” switch to operate the cruise control. Press the switch once more to deactivate the cruise control.
  • Page 171 2-4. Using other driving systems Adjusting the speed setting Increase speed Decrease speed Hold the lever until the desired speed setting is obtained. Fine adjustment of the set speed (approximately 1.0 mph [1.6 km/h]) can be made by lightly pushing the lever up or down and releasing it.
  • Page 172 Turn the “ON-OFF” button off once, and then reactivate the system. If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Contact your Toyota dealer, and have your Toyota inspected. L/C200_U (OM60D97U)
  • Page 173 2-4. Using other driving systems CAUTION To avoid operating the cruise control by mistake Keep the “ON-OFF” button off when not in use. Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in control of the vehicle being lost and could cause seri- ous or fatal accident.
  • Page 174 2-4. Using other driving systems Toyota park assist system (if equipped) Toyota park assist system uses sensors in the corners and rear of the vehicle to detect the distance between the vehicle and any obsta- cles, and informs the driver of this distance using the multi-informa- tion display, the touch screen, and warning beeps.
  • Page 175 2-4. Using other driving systems Multi-information display Front corner sensor detec- tion Rear corner sensor detec- tion Back sensor detection ITY24C017 Touch screen (with navigation system) When the vehicle is moving forward The graphic is automatically displayed when an obstacle is detected.
  • Page 176 2-4. Using other driving systems Sensor detection display, obstacle distance Corner sensors Multi- Touch screen Approximate information distance to obstacle Insert display display Front: 2.0 ft. (60 cm) to 1.6 ft. (47.5 cm) Rear: 2.0 ft. (60 cm) to (continuous) (continuous) (blinking) 1.1 ft.
  • Page 177 2-4. Using other driving systems Back sensors Approximate distance Multi-information Touch screen to obstacle display (insert display) 5.0 ft. (150 cm) to 2.0 ft. (60 cm) (continuous) (blinking slowly) 2.0 ft. (60 cm) to 1.4 ft. (45 cm) (continuous) (blinking) 1.4 ft.
  • Page 178 2-4. Using other driving systems Beeps and obstacle distance A beep sounds when the corner sensors and back sensors are oper- ating. l The beep sounds faster as the vehicle approaches an obstacle. When the vehicle comes within the following distance of the obsta- cle, the beep sounds continuously.
  • Page 179 2-4. Using other driving systems Obstacle detection range About 1.8 ft. (60 cm) About 5.0 ft. (150 cm) The detection area of the sensors is shown to the left. If obstacles move too close to the sensors, they will not be detected. The range of the sensors may change depending on the shape of the object etc.
  • Page 180 When an obstacle is detected while the rear view monitor is in use, the warning indicator will appear in the top right of the screen even has been selected. The Toyota park assist system can be operated when Front corner sensors: • The “ENGINE START STOP” switch is in IGNITION ON mode.
  • Page 181 • If towing eyelet is installed on your vehicle. • The bumper or sensor receives a strong impact. • A non-genuine Toyota suspension (lowered suspension etc.) is installed. In addition to the examples above, there are instances in which, because of their shapes, signs and other objects may be judged by the sensor to be closer than they are.
  • Page 182 (2) This device must accept any interference received, including interfer- ence that may cause undesired operation. CAUTION When using the Toyota park assist system Observe the following precautions. Failing to do so may result in the vehicle being unable to be driven safely and possibly cause an accident.
  • Page 183 2-4. Using other driving systems Four-wheel drive system Use the four-wheel drive control switch and center differential lock/ unlock switch to select the following transfer and center differential modes. Four-wheel drive control switch “H4” (high speed position) Normal driving on all types of roads.
  • Page 184 2-4. Using other driving systems Shifting between “H4”and “L4” Shifting from “H4” to “L4” Stop the vehicle completely. STEP STEP Shift the shift lever to “N”. Push and turn the four-wheel drive control switch fully clock- STEP wise. Maintain this condition until the low speed four-wheel drive indica- tor light turns on.
  • Page 185 2-4. Using other driving systems Neutral position Shifting to the neutral position cuts drive power to the wheels. Shifting from “H4” to the neutral position Stop the vehicle completely. STEP Make sure the vehicle is stopped in a safe place while carrying out the following procedure.
  • Page 186 2-4. Using other driving systems Shift the four-wheel drive control switch to “L4”, then shift to STEP “H4” again. When shifting the four-wheel drive control switch, push the switch down while turning it. The low speed four-wheel drive indicator light will flash slowly (turns on and off every 2 seconds).
  • Page 187 2-4. Using other driving systems The four-wheel drive control switch can be operated when The “ENGINE START STOP” switch is in IGNITION ON mode. The shift lever is in the “N” position. The vehicle is stopped completely. The low speed four-wheel drive indicator light The indicator light blinks while shifting between “H4”...
  • Page 188 In this case, you may not be able to shift between “H4” and “L4”, and the center differential lock may not be operable. Have the vehicle inspected by your Toyota dealer immediately. L/C200_U (OM60D97U)
  • Page 189 2-4. Using other driving systems CAUTION While driving Never move the four-wheel drive control switch if the wheels have lost trac- tion. Doing so may cause an accident resulting in death or serious injury. NOTICE To prevent damage to the center differential For normal driving on dry and hard surface roads, unlock the center differ- ential.
  • Page 190 2-4. Using other driving systems Crawl Control Allows travel on extremely rough off-road surfaces at a fixed low speed without pressing the accelerator or brake pedal. Minimizes loss of traction or vehicle slip when driving on slippery road sur- faces, allowing for stable driving. Crawl Control switch On/off The Crawl Control indicator is...
  • Page 191 2-4. Using other driving systems When the system is turned off If the system is turned off when Crawl Control is operating, a buzzer will sound for 3 seconds, the slip indicator turns off, and the Crawl Control indicator flashes until the system has turned off completely. When turning off Crawl Control while traveling, stop the vehicle before the Crawl Control indicator turns off, or drive extremely care- fully.
  • Page 192 2-4. Using other driving systems Automatic system cancelation In the following situations, the system is canceled automatically, and the Crawl Control indicator will turn off: When the shift lever is moved to “P”. When the four-wheel drive control switch is in “H4”. In the following situations, it is possible to descend a slope at a fixed low speed, however when traveling the system is canceled automatically, and the crawl indicator will turn off.
  • Page 193 2-4. Using other driving systems CAUTION When using Crawl Control Do not rely overmuch on the Crawl Control. This function does not extend the vehicle’s performance limitations. Always thoroughly check the road con- ditions, and drive safely. Conditions under which the system may not operate correctly When driving on the following surfaces, the system may not be able to main- tain a fixed low speed, which may result in an accident: Extremely steep inclines.
  • Page 194 2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. Multi Terrain ABS (Anti-lock Brake System) Helps to prevent wheel lock when the brakes are applied suddenly, or if the brakes are applied while driving on a slippery road surface, or in off-...
  • Page 195 2-4. Using other driving systems When the VSC/Active TRAC/hill-start assist control systems are operating If the vehicle is in danger of slip- ping, rolling backwards when starting on an incline, or if the rear wheels spin, the slip indica- tor light flashes to indicate that the VSC/Active TRAC/hill-start assist control...
  • Page 196 2-4. Using other driving systems To disable Active TRAC and/or VSC system If the vehicle gets stuck in fresh snow or mud, Active TRAC and VSC system may reduce power from the engine to the wheels. You may need to turn the system off to enable you to rock the vehicle in order to free it.
  • Page 197 2-4. Using other driving systems Turning off VSC Push the center differential lock/ unlock switch to turn off VSC system. The center differential lock indica- tor light will come on and “VSC OFF” will be shown on the multi- information display. Push the switch again to turn the system back on.
  • Page 198 2-4. Using other driving systems Sounds and vibrations caused by the Multi Terrain ABS, brake assist, Active TRAC, VSC and hill-start assist control A sound may be heard from the engine compartment when the engine is started or just after the vehicle begins to move. This sound does not indi- cate that a malfunction has occurred in any of these systems.

  • Page 199: When Driving

    2-4. Using other driving systems CAUTION Any of the following conditions may result in an accident which could cause death or serious injury: The Multi Terrain ABS does not operate effectively when The limits of tire gripping performance have been exceeded. The vehicle hydroplanes while driving at high speed on the wet or slick road.
  • Page 200 In the following situations, there is the possibility that a system malfunction has occurred, and drive comfort and the vehicle’s ability to travel on poor road surfaces may be reduced. Take the vehicle to your Toyota dealer imme- diately. When turning a corner, the vehicle’s body seems to roll further than nor- mal.
  • Page 201 2-4. Using other driving systems Pre-Collision System (if equipped) The system detects emergency braking from the speed and force with which the driver presses the brake pedal, and quickly tightens the seat belt to improve the effectiveness of the seat belt pretension- ers (→P.
  • Page 202 2-5. Driving information Off-road precautions This vehicle belongs to the utility vehicle class, which has higher ground clearance and narrower tread in relation to the height of its center of gravity to make it capable of performing in a wide variety of off-road applications.
  • Page 203 2-5. Driving information CAUTION Off-road vehicle precautions Always observe the following precautions to help minimize the risk of serious personal injury or damage to your vehicle: In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt. Therefore, the driver and all passengers should fasten their seat belts whenever the vehicle is moving.
  • Page 204 2-5. Driving information Off-road driving When driving your vehicle off-road, please observe the following pre- cautions to ensure your driving enjoyment and to help prevent the closure of areas to off-road vehicles. l Drive your vehicle only in areas where off-road vehicles are permit- ted to travel.
  • Page 205 2-5. Driving information CAUTION Off-road driving precautions Always observe the following precautions to help minimize the risk of serious personal injury or damage to your vehicle: Drive carefully when off the road. Do not take unnecessary risks by driving in dangerous places. Do not grip the steering wheel spokes when driving off-road.
  • Page 206 2-5. Driving information NOTICE To prevent the water damage Take all necessary safety measures to ensure that water damage to the engine or other components does not occur. Water entering the engine air intake will cause severe engine damage. Water entering the automatic transmission will cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ulti- mately damage.
  • Page 207 2-5. Driving information Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load. l Stow cargo and luggage in the luggage compartment when- ever possible. Be sure all items are secured in place. l Be careful to keep the vehicle level.
  • Page 208 2-5. Driving information Adjusting the position of cross rails Turn the knobs counterclockwise STEP to release the cross rails. ITY25C040 Slide the cross rails to the appro- STEP priate position for loading lug- gage turn knobs clockwise to tighten the cross rails securely.
  • Page 209 2-5. Driving information Capacity and distribution Cargo capacity depends on the total weight of the occupants. (Cargo capacity) = (Total load capacity) — (Total weight of occupants) Steps for Determining Correct Load Limit— (1) Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs.”...
  • Page 210 2-5. Driving information Example on your vehicle Cargo capacity Total load capacity When 2 people with the combined weight of 366 lb. (166 kg) are riding in your vehicle, which has a total load capacity of 1235 lb. (560 kg), the available amount of cargo and luggage load capacity will be as follows: 1235 lb.
  • Page 211 2-5. Driving information CAUTION Things that must not be carried in the luggage compartment The following things may cause a fire if loaded in the luggage compart- ment. Receptacles containing gasoline Aerosol cans Storage precautions Do not stack anything in the luggage compartment higher than the seatbacks.
  • Page 212 Roof luggage carrier precautions To use the roof rails as a roof luggage carrier, you must fit the roof rails with two or more genuine Toyota cross rails or their equivalent. When you load cargo on the roof luggage carrier, observe the following: Place the cargo so that its weight is distributed evenly between the front and rear axles.
  • Page 213 2-5. Driving information CAUTION Cross rail adjustment Make sure the cross rails are locked securely by pushing forward and rearward them. Failure to do so may cause an accident or severe injury in the event of emergency braking or a collision. NOTICE Cross rail adjustment Do not remove the cross rail stoppers, or the moon roof may be damage...
  • Page 214 2-5. Driving information Vehicle load limits Vehicle load limits include total load capacity, seating capacity, towing capacity and cargo capacity. Total load capacity: 1235 lb. (560 kg) Total load capacity means the combined weight of occupants, cargo and luggage. Seating capacity: 8 occupants (Front 2, Rear 6) Seating capacity means the maximum number of occupants whose estimated average weight is 150 lb.
  • Page 215 2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. Pre-winter preparations l Use fluids that are appropriate to the prevailing outside tem- peratures.
  • Page 216 2-5. Driving information Before driving the vehicle Perform the following according to the driving conditions. l Do not try to forcibly open a window or move a wiper that is frozen. Pour warm water over the frozen area to melt the ice. Wipe away the water immediately to prevent it from freezing.
  • Page 217 2-5. Driving information Selection tire chains Use the correct tire chain size when mounting the snow chains. Chain size is regulated for each tire size. Side chain (0.20 in. [5 mm] in diameter) Cross chain (0.25 in. [6.3 mm] in diameter) ITY25C045 Regulations on the use of tire chains l Regulations regarding the use of tire chains vary according to loca-...
  • Page 218 2-5. Driving information CAUTION Driving with snow tires Observe the following precautions to reduce the risk of accidents. Failing to do so may result in a loss of vehicle control and cause death or serious injury. Use tires of the size specified for your vehicle. Maintain the recommended level of tire inflation pressure.
  • Page 219 2-5. Driving information NOTICE Repairing or replacing snow tires Request repairs of and obtain replacement snow tires from Toyota deal- ers or legitimate tire retailers. This is because the removal and attachment of snow tires affects the operation of the tire pressure warning valves and transmitters.
  • Page 220 The vehicle stability and braking performance are affected by trailer stability, brake setting and performance, and the hitch. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Contact your Toyota dealer for further information about additional requirements such as a towing kits, etc.
  • Page 221 2-5. Driving information Weight limits Confirm that the gross trailer weight, gross combined weight, gross vehicle weight, gross axle weight and trailer tongue load are all within the limits. l The gross trailer weight must never exceed 8500 lb. (3856 kg). l The gross combined weight must never exceed 14550 lb.
  • Page 222 2-5. Driving information Towing related term Towing related term Meaning The maximum allowable gross vehicle weight. The gross vehicle weight is the total weight of the vehicle. When towing GVWR (Gross Vehicle Weight a trailer, it is the sum of the vehicle Rating) weight (including the occupants, cargo and any optional equipment installed on...
  • Page 223 2-5. Driving information Trailer tongue load l A recommended tongue load varies in accordance with the types of trailers or towing as described below. l In order to ensure the recommended values shown below, the trailer must be loaded by referring to the following instructions. The trailer cargo load should be distributed so that the tongue load is 9 to 11 %.
  • Page 224 2-5. Driving information Removing hitch cover Remove the clip. STEP Grasp the lower edge of the hitch STEP cover and raise the cover. When reattaching cover, reverse the steps listed. ITY25C047 L/C200_U (OM60D97U)
  • Page 225 2-5. Driving information Selecting trailer ball Use the correct trailer ball for your application. Trailer ball load rating Matches or exceeds the gross trailer weight rating of the trailer. Ball diameter Matches the size of the trailer coupler. Most couplers stamped with the required trailer ball size.
  • Page 226 2-5. Driving information Trailer towing tips Your vehicle will handle differently when towing a trailer. The 3 main causes of vehicle-trailer accidents are driver error, excessive speed and improper trailer loading. Keep the following in mind when towing. l Before starting out, check the trailer lights and the vehicle-trailer connections.
  • Page 227 2-5. Driving information l Note that when making a turn, the trailer wheels will be closer than the vehicle wheels to the inside of the turn. Compensate by making a larger than normal turning radius. l Crosswinds and rough roads will adversely affect handling of your vehicle and trailer, causing sway.
  • Page 228 2-5. Driving information l Always place wheel blocks under both the vehicle and the trailer wheels when parking. Apply the parking brake firmly, and put the transmission in “P”. Avoid parking on a slope, but if unavoidable, do so only after performing the following: Apply the brakes and keep them applied.
  • Page 229 Break-in schedule Toyota recommends that you do not use a new vehicle or a vehicle with any new power train components (engine, transmission, differential, wheel bear- ings, etc.) to tow a trailer for the first 500 miles (800 km) of driving.
  • Page 230 2-5. Driving information CAUTION Trailer towing precautions Follow all the instructions described in this section. Failure to do so could cause an accident resulting in death or serious injury. Exceeding the towing capacity, GVWR, GCWR and GAWR can cause an accident resulting in death or serious personal injuries.
  • Page 231 NOTICE When installing a trailer hitch Use only the position recommended by your Toyota dealer. Do not install the trailer hitch on the bumper; this may cause body damage. Do not use axle-mounted hitches, as they can cause damage to the axle housing, wheel bearings, wheels or tires.
  • Page 232 2-5. Driving information Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE To avoid serious damage to your vehicle Do not tow your vehicle with four wheels on the ground. L/C200_U (OM60D97U)
  • Page 233 2-5. Driving information L/C200_U (OM60D97U)
  • Page 234 3-1. Using the air conditioning system and defogger Front air conditioning system Airflow and outlets are automatically adjusted according to the tem- perature setting. With navigation system Owners of models equipped with a navigation system should refer to the “Navigation System Owner’s Manual”. Without navigation system Driver’s side temperature control Passenger’s side temperature control...
  • Page 235 3-1. Using the air conditioning system and defogger Using the automatic mode Press STEP The air conditioning system will begin to operate. Air outlets and fan speed are automatically adjusted according to the temperature set- ting. Press “∧” to increase the temperature and “∨” to decrease the STEP temperature on The temperature for the driver’s and front passenger’s seats can be...
  • Page 236 3-1. Using the air conditioning system and defogger Adjusting the settings Adjusting the temperature setting Press “∧” to increase the temperature and “∨” to decrease the tem- perature on The air conditioning system switches between individual and simul- taneous modes each time is pressed.
  • Page 237 3-1. Using the air conditioning system and defogger Changing the air outlets Press For driver’s seat For front passenger’s seat The air outlets switch each time the button is pressed. Different air outlets for the driver’s and front passenger’s seats can be chosen.
  • Page 238 3-1. Using the air conditioning system and defogger Air flows to the feet. ITY31C013 Air flows to the feet and the windshield defogger operates. ITY31C014 Switching between outside air and recirculated air modes Vehicles with windshield wiper de-icer Press The mode switches between outside air mode (indicator off) and recirculated air mode (indicator on) each time the button is pressed.
  • Page 239 3-1. Using the air conditioning system and defogger Changing the rear seat settings from the front seat Adjusting the temperature setting Press STEP Press “∧” to increase the temperature and “∨” to decrease the STEP temperature on (for left-hand rear seat) and (for right-hand rear seat).
  • Page 240 3-1. Using the air conditioning system and defogger Changing the air outlets STEP Press Press STEP The air outlets switch each time the button is pressed. (→P. 257) Defogging the windshield Press The air conditioning system con- trol operates automatically. Recirculated air mode will auto- matically switch to outside air mode.
  • Page 241 3-1. Using the air conditioning system and defogger Adjusting the position and opening and closing the air outlets Front center outlets Direct air flow to the left or right, up or down. Turn the knob to open or close the vent. ITY31C030 Front side outlets Direct air flow to the left or...
  • Page 242 3-1. Using the air conditioning system and defogger Using the automatic mode Fan speed is adjusted automatically in accordance with the temperature set- ting and ambient conditions. As a result, the following may occur. The system may switch automatically to recirculated air mode when the coolest temperature setting is selected in summer.
  • Page 243 3-1. Using the air conditioning system and defogger CAUTION To prevent the windshield from fogging up Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, blocking your vision.
  • Page 244 3-1. Using the air conditioning system and defogger Rear air conditioning system Airflow and outlets are automatically adjusted according to the tem- perature setting. Fan speed display Airflow display Left side temperature setting display Right side temperature setting display Right side temperature control Left side temperature control Changes the air...
  • Page 245 3-1. Using the air conditioning system and defogger Adjusting the settings Adjusting the temperature setting Press “∧” to increase the temperature and “∨” to decrease the tem- perature on The temperature for the right-hand and left-hand rear seats can be set separately.
  • Page 246 3-1. Using the air conditioning system and defogger Air flows to the upper body. ITY31C020 Air flows to the upper body and feet. ITY31C021 Air flows to the feet. ITY31C022 L/C200_U (OM60D97U)
  • Page 247 3-1. Using the air conditioning system and defogger Adjusting the position and opening and closing the air outlets Rear center outlets Direct air flow to the left or right, up or down. Turn the knob to open or close the vent. Roof side outlets Direct air flow to the left or right, up or down.
  • Page 248 3-1. Using the air conditioning system and defogger Rear window and outside rear view mirror defoggers These features are used to defog the rear window, and to remove raindrops, dew and frost from the outside rear view mirrors. With navigation system On/off The defoggers will automati- cally turn off after 15 to 225...
  • Page 249 3-1. Using the air conditioning system and defogger Windshield wiper de-icer This feature is used to prevent ice from building up on the wind- shield and wiper blades. With navigation system On/off The windshield wiper de-icer will automatically turn off after approximately minutes.
  • Page 250 3-2. Using the audio system Audio system type With navigation system Owners of models equipped with a navigation system should refer to the “Navigation System Owner’s Manual”. Without navigation system CD player with changer and AM/FM radio. Title Page Using the radio P.
  • Page 251 3-2. Using the audio system Using cellular phones Interference may be heard through the audio system’s speakers if a cellular phone is being used inside or close to the vehicle while the audio system is operating. CAUTION For vehicles sold in the U.S.A. Part 15 of the FCC Rules FCC Warning: Any unauthorized changes or modifications to this equipment will void the...

  • Page 252: Using The Radio

    3-2. Using the audio system Using the radio Press to choose either an AM or FM band. Scanning for receivable stations Station selector LOAD SCAN DISC ADS FLD FILE ST MSG TRAF 1 2 3 4 5 6 RAND FORDER SCAN TEXT ·...
  • Page 253 3-2. Using the audio system Setting station presets Search for desired stations by turning or pressing “∧” or STEP “∨” on Press and hold the button (from ) the sta- STEP tion is to be set to, and you hear a beep. Scanning radio stations Scanning the preset radio stations Press and hold...
  • Page 254 3-2. Using the audio system RDS (Radio Data System) This feature allows your radio to receive station identification informa- tion and program information (classical, jazz, etc.) from radio stations which broadcast this information. Receiving RDS broadcasts Press “∧” or “∨” on the during FM reception.
  • Page 255 3-2. Using the audio system Displaying radio text messages Press If MSG is shown on the display, a text message will be displayed. If the text continues past the end of the display, is displayed. Press and hold until you hear a beep. Traffic announcement Press “TRAF SEEK”...
  • Page 256 3-2. Using the audio system Certifications for the radio tuner This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 257: Using The Cd Player

    3-2. Using the audio system Using the CD player Insert a CD or press with a CD inserted. Search playback Repeat play CD slot CD insert CD eject Random playback LOAD SCAN DISC ADS FLD FILE ST MSG TRAF 1 2 3 4 5 6 RAND FORDER SCAN...
  • Page 258 3-2. Using the audio system Loading a CDs Loading a single CD Press STEP “WAIT” appears on the display. Insert a CD when the indicator on the slot turns from amber to STEP green. The display changes from “WAIT” to “LOAD”. Loading multiple CDs Press and hold until you hear a beep.
  • Page 259 3-2. Using the audio system Ejecting CDs Ejecting a CD To select the CD to be ejected, press “∧” or “∨” on STEP The number of the CD selected is shown on the display. Press and remove the CD. STEP Ejecting all CDs Press and hold until you hear a beep, then remove the...
  • Page 260 3-2. Using the audio system Fast forwarding and rewinding tracks Press and hold “∧” or “∨” on Scanning a CD Press STEP “SCAN” appears on the display. The first 10 seconds of each track will be played. Press once again when the desired track is STEP reached.
  • Page 261 3-2. Using the audio system Repeating a track or a disc Repeating a track Press (RPT). Repeating a disc Press and hold (RPT) until you hear a beep. Switching the display Press Each time the button is pressed, the display changes in the order of Track no./Elapsed time →...
  • Page 262 3-2. Using the audio system Canceling random, repeat and scan playback Press (RAND), (RPT) or again. Error messages “ERROR”: This indicates a trouble either in the CD or inside the player. The CD may be dirty, damaged or inserted up-side down. Discs that can be used Discs with the marks shown below can be used.
  • Page 263 3-2. Using the audio system NOTICE CDs and adapters that cannot be used Do not use the following types of CDs, 3 in. (8 cm) CD adapters or Dual Disc. Doing so may damage the player and/or the CD insert/eject function. CDs that have a diameter that is not 4.7 in.
  • Page 264 3-2. Using the audio system NOTICE Player precautions Failure to follow the precautions below may result in damage to the CDs or the player itself. Do not insert anything other than CDs into the CD slot. Do not apply oil to the player. Store CDs away from direct sunlight.

  • Page 265: Playing Back Mp3 And Wma Discs

    3-2. Using the audio system Playing back MP3 and WMA discs Insert an MP3 or WMA disc or press with a disc inserted. Folder selection Search playback Repeat play CD slot CD eject CD insert Random playback LOAD SCAN DISC ADS FLD FILE ST MSG...
  • Page 266 3-2. Using the audio system Selecting and scanning a folder Selecting folders one at a time Press (∨) or (∧) to select the desired folder. To return to the first folder, press and hold (∨) until you hear a beep. Selecting the desired folder by cueing the first file of each folder Press and hold...
  • Page 267 3-2. Using the audio system Random playback To play files from a particular folder in random order Press (RAND). To play all of the files on a disc in random order Press and hold (RAND) until you hear a beep. Repeating a file or a folder Repeating a file Press...
  • Page 268 3-2. Using the audio system Display Up to 12 characters can be displayed at a time. If there are 13 characters or more, pressing and holding for 1 second or more will display the remaining characters. A maximum of 24 characters can be displayed. is pressed for 1 second or more again or has not been pressed for 6 seconds or more, the display will return to the first 12 characters.
  • Page 269 3-2. Using the audio system Lens cleaners Do not use lens cleaners. Doing so may damage the CD player. MP3 and WMA files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression.
  • Page 270 3-2. Using the audio system Compatible media Media that can be used for MP3 and WMA playback are CD-Rs and CD- RWs. Playback in some instances may not be possible, depending on the status of the CD-R or CD-RW. Playback may not be possible or the audio may jump if the disc is scratched or marked with fingerprints.
  • Page 271 3-2. Using the audio system ID3 and WMA tags ID3 tags can be added to MP3 files, making it possible to record the track title and artist name, etc. The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3 ID3 tags. (The number of characters is based on ID3 Ver.
  • Page 272 3-2. Using the audio system NOTICE CDs and adapters that cannot be used (→P. 283) Player precautions (→P. 284) L/C200_U (OM60D97U)

  • Page 273: Optimal Use Of The Audio System

    3-2. Using the audio system Optimal use of the audio system Displays the current mode Changes the following set- tings TUNE·FILE TUNE·FILE • Sound quality and vol- ume balance PUSH PUSH The sound quality and bal- AUDIO CONTROL AUDIO CONTROL ance setting changed to produce the...
  • Page 274 3-2. Using the audio system Adjusting sound quality Turning adjusts the level. Sound quality Mode Turn to the Turn to the Level mode displayed left right Low-pitched -5 to 5 tones Mid-pitched -5 to 5 High tones High pitched -5 to 5 tones Front/rear Shifts to...

  • Page 275: Using The Aux Adapter

    3-2. Using the audio system Using the AUX adapter This adapter can be used to connect a portable audio device and lis- ten to it using the vehicle’s speakers. Connect the portable audio STEP device. ITY32C015 Press STEP Operating portable audio devices connected to the audio system The volume can be adjusted using the vehicle’s audio controls.

  • Page 276: Using The Steering Switches

    3-2. Using the audio system Using the steering switches Some audio features can be controlled using the switches on the steering wheel. Volume Radio: Select radio stations CD: Select tracks, files, discs and folders MODE Power on, select audio source ITY32C014 Turning on the power Press...
  • Page 277 3-2. Using the audio system Adjusting the volume Press “+” on to increase the volume and “-” to decrease the volume. Hold down the button to continue increasing or decreasing the volume. Selecting a radio station Press to select the radio mode. STEP Press “∧”...
  • Page 278 3-3. Using the rear seat entertainment system Rear seat entertainment system features (if equipped) The rear seat entertainment system is designed for the rear passen- gers to enjoy audio and DVD video separately from the front audio system. PHONE VIDEO MONO PHONE ITY36C001 Front audio system...
  • Page 279 3-3. Using the rear seat entertainment system Rear seat entertainment system controller To use the buttons under the cover, slide the cover down. Opening and closing the display Opening and closing the display l Open Press l Close Press If the display is closed with an image shown, the image will auto- matically turn off.
  • Page 280 3-3. Using the rear seat entertainment system Tilting the display The display angles change as follows each time pressed. → → → → The display angle is memorized and will be recalled when the “ENGINE START STOP” switch is turned to ACCESSORY or IGNI- TION ON mode again.
  • Page 281 3-3. Using the rear seat entertainment system Changing the source Press to display the audio source selection screen. Select an audio source. Changing the speaker output To play the rear audio over the speakers in the vehicle, turn L/C200_U (OM60D97U)
  • Page 282 Remove the depleted batteries and install new batteries. Headphones With some headphones generally available in the market, it may be difficult to catch signals properly. Toyota recommends the use of Toyota genuine wireless headphones. Contact your Toyota dealer for further details. L/C200_U (OM60D97U)
  • Page 283 3-3. Using the rear seat entertainment system Volume Adjust the volume when you connect the headphones to the jack. Loud sounds may have a significant impact on the human body. Conversational speech on some DVDs is recorded at a low volume to emphasize the impact of sound effects.
  • Page 284 3-3. Using the rear seat entertainment system NOTICE Cleaning the display Wipe the display with a dry soft cloth. If the screen is wiped with a rough cloth, the surface of the screen may be scratched. To prevent damage to the remote control Keep the remote control away from direct sunlight, high temperature and high humidity.
  • Page 285 3-3. Using the rear seat entertainment system Using the radio Select radio mode on the source screen to display the control screen. Selecting a preset station Press ∧ or ∨ on until the desired station band appears on the screen. Tuning the station Press ∧...
  • Page 286 3-3. Using the rear seat entertainment system Using the DVD changer Turning on DVD changer mode Selecting a disc Selecting a disc Press ∧ or ∨ on until the desired slot number appears on the screen. l Audio CD, CD text →P. 307 l MP3/WMA disc →P.
  • Page 287 3-3. Using the rear seat entertainment system Playing an audio CD/CD text Selecting a track Press ∧ or ∨ on until the desired track number appears on the screen. Fast forwarding or reversing a track Press and hold ∧ or ∨ on L/C200_U (OM60D97U)
  • Page 288 3-3. Using the rear seat entertainment system Playing WMA/MP3 discs Selecting a file Press ∧ or ∨ on until the desired file number appears on the screen. Selecting a folder Press ∧ or ∨ on until the desired folder number appears on the screen.
  • Page 289 3-3. Using the rear seat entertainment system Playing DVD video/audio Controller Turning on the DVD mode Selecting a chapter/track Reversing a disc Turning on the title selection screen Changing the subtitle lan- guage Turning on the control icon screen Changing the audio lan- guage Stopping a disc Turning on the menu disc...
  • Page 290 3-3. Using the rear seat entertainment system Control icon screen Press if no icons are shown while watching a DVD video, and the following screen appears. DVD video mode Page 1 Hide control icons Go to page 2 Return to top menu screen Return to menu screen...
  • Page 291 3-3. Using the rear seat entertainment system DVD audio mode Page 1 Hide control icons Return to top menu Go to page 2 screen Change the audio format Fast forward Reverse Playback Stop Pause Initial DVD setup Select menu number Page 2 Return to page 1 Return to previous...
  • Page 292 3-3. Using the rear seat entertainment system Turning on or off the control icons Press to turn on the control icons. Press once again or select to turn off the control icon. Turning on the title selection screen Press or select to turn on the title selection screen.
  • Page 293 3-3. Using the rear seat entertainment system Returning to the previous screen Select to return to the previous screen. For the operation of the menu screen, see the separate manual for the DVD disc. Searching for a desired screen Searching by title (DVD video mode) Select on the control icon screen.
  • Page 294 3-3. Using the rear seat entertainment system Playing a bonus group (DVD audio mode only, if the DVD has bonus options) Select on the control icon screen. STEP Input the desired bonus group STEP number on the group search screen and select : deletes the number : returns to the previous screen...
  • Page 295 3-3. Using the rear seat entertainment system Changing the subtitle language Press or select on the control icon screen. STEP Select STEP Each time you press , the next available language selected. : hides the control icons : returns to the previous screen Changing the audio language (DVD video only) Press...
  • Page 296 3-3. Using the rear seat entertainment system Changing the audio format (DVD audio only) Press or select on the control icon screen. STEP Select STEP Each time you press , the next available audio format is selected. : returns to the previous screen Changing the angle (If the angle option is available) Select...
  • Page 297 3-3. Using the rear seat entertainment system Initial DVD setup Displaying “Setup Menu” screen Select on the control icon screen. STEP After you change the initial set- STEP tings, select : restores default set- tings Setting audio language Select on the “Setup Menu” screen. STEP Select the desired language.
  • Page 298 3-3. Using the rear seat entertainment system Setting angle mark “ON” or “OFF” If the DVD has angle options, you can turn the angle mark on or off. Select on the “Setup Menu” screen. Each time you press , the multi angle mark on the screen turns on or off alternately.
  • Page 299 3-3. Using the rear seat entertainment system Input the 4-digit language code and then select : deletes the last input digit : returns to the previous screen L/C200_U (OM60D97U)
  • Page 300 3-3. Using the rear seat entertainment system l Language codes Code Language Code Language Code Language 0514 English 0207 Bulgarian 0712 Galician 0618 French 0208 Bihari 0714 Guarani 0405 German 0209 Bislama 0721 Gujarati 0920 Italian 0214 Bengali 0801 Hausa 0519 Spanish 0215...
  • Page 301 3-3. Using the rear seat entertainment system Code Language Code Language Code Language 1119 Kashmiri 1415 Norwegian 1914 Shona 1121 Kurdish 1503 Occitan 1915 Somali (Afan) 1125 Kirghiz 1513 1917 Albanian Oromo 1201 Latin 1518 Oriya 1918 Serbian 1214 Lingala 1601 Panjabi 1919...
  • Page 302 3-3. Using the rear seat entertainment system Code Language Code Language Code Language Vietnam- 2023 2209 2515 Yoruba 2111 Ukrainian 2215 Volapük 2621 Zulu 2118 Urdu 2315 Wolof 2126 Uzbek 2408 Xhosa Error messages If “Region Code Error” is displayed, check if the region code printed on the DVD matches the player’s region code.
  • Page 303 3-3. Using the rear seat entertainment system Playing a video CD Controller Selecting a track Reversing a disc Turning on the control icon screen Stopping a disc Fast forwarding a disc Playing/pausing a disc Selecting an icon Inputting the selected icon L/C200_U (OM60D97U)
  • Page 304 3-3. Using the rear seat entertainment system Control icon screen Press if no icons are shown while watching a video CD, and the following screen appears. Page 1 Go to page 2 Hide control icons Select menu number Return to Change registered screen sound-multiplex...
  • Page 305 3-3. Using the rear seat entertainment system Fast forwarding/reversing the video CD Perform either of the following: l Select on the screen by pressing and holding l Press and hold ∧ or ∨ on Slow playback Select and then select .
  • Page 306 3-3. Using the rear seat entertainment system Selecting a desired screen Selecting a menu number Select on the control icon screen. STEP Input the desired menu number STEP on the screen and select Searching manually on the screen, or press ∧ or ∨ on Select until the desired screen appears.
  • Page 307 3-3. Using the rear seat entertainment system DVD player and DVD video disc information Error messages Correction Message Cause Procedures There is no disc in the No Disc Insert a disc CD or DVD changer • The disc X is dirty or damaged •...
  • Page 308 3-3. Using the rear seat entertainment system DVD video discs l The DVD player conforms to NTSC color TV formats. l Region code: Some DVD video discs have a region code indi- cating the region in which you can use the DVD video disc. If the DVD video disc is not labeled as “ALL”...
  • Page 309 3-3. Using the rear seat entertainment system Symbols shown on DVD video discs Symbol Meaning Indicates NTSC format. Indicates the number of audio tracks. Indicates the number of language subtitles. Indicates the number of angles. Indicates the screen display ratios available. Wide screen: 16:9 Standard: 4:3 Indicates the disc’s region code.
  • Page 310 3-3. Using the rear seat entertainment system Discs that can be used Discs with the marks shown below can be used. Playback may not be possible depending on recording format or disc fea- tures, or due to scratches, dirt or deterioration. DVD video disc information DVD video discs Digital Versatile Disc that holds video.
  • Page 311 3-3. Using the rear seat entertainment system Viewer restrictions This feature limits what can be viewed in conformity with the level of restrictions of the country. The level of restrictions varies depending on the DVD video disc. Some DVD video discs cannot be played at all, or violent scenes are skipped or replaced with other scenes.
  • Page 312 3-3. Using the rear seat entertainment system Sound Dolby Digital Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic”, and the double-D symbol are trademarks of Dolby Laboratories. Confidential unpublished works. ©1992-1997 Dolby Laboratories. All rights reserved. This product incorporates copyright protection technology that is pro- tected by method claims of certain U.
  • Page 313 3-3. Using the rear seat entertainment system NOTICE Discs and adapters that cannot be used →P. 283 Player precautions Failure to follow the precautions below may result in damage to the discs or the player itself. Do not insert anything other than discs into the disc slot. Do not apply oil to the player.
  • Page 314 3-3. Using the rear seat entertainment system Using the video mode Press to select the video mode. Before switching to the video mode, connect the audio-video equipment to the A/V input adapter. Using the adapter Open the cover. The A/V input adapter is com- posed of 3 input adapters.
  • Page 315 3-3. Using the rear seat entertainment system Changing to PAL format Press If the video does not appear, turn will be displayed when the audio-video equipment is connected to the A/V input adapter. A/V input adapter The rear seat entertainment system plays videos and sound when audio- video equipment is connected to the A/V input adapter.
  • Page 316 3-3. Using the rear seat entertainment system Changing other settings Setting the display mode Pressing changes the dis- play modes sequentially as fol- lows: Normal→Wide 1 →Wide 2 Adjusting the screen Press Select the brightness, contrast, tone or color, and make adjust- ments.
  • Page 317 3-3. Using the rear seat entertainment system Automatic closing of the rear display Press is on, the display will automatically close when the “ENGINE START STOP” switch is turned to OFF mode. The display will automatically open when the “ENGINE START STOP”...
  • Page 318 3-4. Using the interior lights Interior lights list Your Toyota is equipped with the illuminated entry system to assist in entering the vehicle. Owing to the function of the system, the lights shown in the following illustration automatically turn on/off...

  • Page 319: Interior Lights

    “DOOR” posi- tion, the lights will go off automatically after 20 minutes. Customization that can be configured at Toyota dealer Settings (e.g. The time elapsed before lights turn off) can be changed.
  • Page 320 3-4. Using the interior lights Personal lights Personal lights Front On/off Rear (type A) On/off Rear (type B) On/off ITY33C014 L/C200_U (OM60D97U)
  • Page 321 3-5. Using the storage features List of storage features ITY34C001 Card holders Overhead console Glove box Bottle holders Door pockets Auxiliary box Console box/cool box Cup holders L/C200_U (OM60D97U)
  • Page 322 3-5. Using the storage features Glove box Glove box Open (push button) Lock with the mechanical key Unlock with the mechanical ITY34C003 Glove box light The glove box light turns on when the tail lights are on. CAUTION While driving Keep the glove box closed.
  • Page 323 3-5. Using the storage features Console box Console box Your vehicle is equipped with either a lower console box or cool box. For vehicles with the cool box, refer to P. 349. Upper console box Press the tab to open. ITY34C005 Lower console box (if equipped) Lift the lever to open.
  • Page 324 3-5. Using the storage features Console box and overhead console CAUTION While driving Keep the console box closed. Injuries may result in the event of an accident or sudden braking. Overhead console Press the button. The overhead console is useful temporarily storing small...
  • Page 325 3-5. Using the storage features Cup holders Cup holders Front (type A) Press down and release the lid. You can adjust or remove the separator inside. ITY34C011 Front (type B) Open the lower console box lid. ITY34C013 Rear STEP Pull the armrest down. (→P. 362) Press the button.
  • Page 326 3-5. Using the storage features Cup holders and bottle holders CAUTION Items unsuitable for the cup holder Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
  • Page 327 3-5. Using the storage features Bottle holders For second seats ITY34C024 For third seats NOTICE Items that should not be stowed in the bottle holders Put the cap on before stowing a bottle. Do not place open bottles in the bot- tle holders, or glasses and paper cups containing liquid.

  • Page 328: Auxiliary Box

    3-5. Using the storage features Card holders and auxiliary box Card holders Sun visor Instrument panel Auxiliary box ITY34C023 L/C200_U (OM60D97U)

  • Page 329: Interior Features

    3-6. Other interior features Cool box (if equipped) While the engine is running, the cool box, which is cooled by the air conditioning, can be used. Lift the lever to open. STEP ITY34C029 On/off STEP COOL When on, the indicator light comes on.
  • Page 330 3-6. Other interior features CAUTION While driving Keep the cool box closed. Injuries may result in the event of an accident or sudden braking. NOTICE To prevent battery discharge Do not leave the cool box on longer than necessary when the engine is stopped.
  • Page 331 3-6. Other interior features Sun visors Main sun visor Forward position: Flip down. Side position: Flip down, unhook, and swing to the side. Side extender: Place in side position, then slide backwards. Sub-sun visor Flip down with the main sun visor in position L/C200_U (OM60D97U)
  • Page 332 3-6. Other interior features Vanity mirror Slide the cover. The light turns on when the cover is opened. L/C200_U (OM60D97U)
  • Page 333 3-6. Other interior features Clock With navigation system Refer to “Navigation System Owner’s Manual”. Without navigation system Adjust hours. Adjust minutes. Round the nearest hour. :e.g. 1:00 to 1:29→1:00 1:30 to 1:59→2:00 ITY35C003 The clock is displayed when The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode.
  • Page 334 Operating conditions The “ENGINE START STOP” switch is in IGNITION ON mode. When --- is displayed The system may be malfunctioning. Take your vehicle to your Toyota dealer. Display In the following situations, the correct outside temperature may not be dis- played, or the display may take longer than normal to change.
  • Page 335 3-6. Other interior features Ashtrays Front Press in and release the lid to open. Press down on the lock spring plate to remove. Push the lid to close. Rear Pull the ashtray lid to open. Pull the ashtray upwards to remove.
  • Page 336 3-6. Other interior features CAUTION When not in use Keep the ashtray closed. Injuries may result in the event of an accident or sudden braking. To prevent fire Fully extinguish matches and cigarettes before putting them in the ashtray, then make sure the ashtray is fully closed. Do not place paper or any other type of flammable object in the ashtray.
  • Page 337 3-6. Other interior features Cigarette lighter Push the cigarette lighter in. The cigarette lighter will pop up when ready for use. The cigarette lighter can be used when The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode. CAUTION To avoid burns or fires Do not touch the metal parts of the cigarette lighter.
  • Page 338 3-6. Other interior features Power outlets The power outlets can be used for a following component. Instrument panel (12V): Accessories that run on less than 10A. Luggage compartment (115V AC): Accessories that use less than 100W. Instrument panel (12V) Luggage compartment (115V AC) To use the power outlet, push the switch.
  • Page 339 3-6. Other interior features The power outlets can be used when 12V: The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode. 115V: The “ENGINE START STOP” switch is in IGNITION ON mode. NOTICE To avoid damaging the power outlets Close the power outlet lid when not in use.
  • Page 340 3-6. Other interior features Seat heaters For front seats For driver’s seat Pops the switch out. For front passenger’s seat Pops the switch out. The indicator light comes on. Adjusts the seat tempera- ture The further you turn the knob clockwise, the warmer the seat becomes.
  • Page 341 3-6. Other interior features The seat heaters can be used when The “ENGINE START STOP” switch is in IGNITION ON mode. CAUTION Burns Use caution when seating the following persons in a seat with the seat heater on to avoid the possibility of burns: •...
  • Page 342 3-6. Other interior features Armrest Pull the armrest down for use. ITY35C052 NOTICE To prevent damage to the armrest Do not place too much strain on the armrest. L/C200_U (OM60D97U)
  • Page 343 3-6. Other interior features Floor mats Securely place a mat that matches the size of the space on the car- pet. Secure the floor mat using the hooks provided. ITY35C020 CAUTION When inserting the floor mat Observe the following precautions. Failure to do so may result in the floor mat slipping and interfering with the movement of the pedals during driving, resulting in an accident.
  • Page 344 3-6. Other interior features Luggage compartment features Cargo hooks Cargo hooks are provided for securing loose items. ITY35C022 Cargo net hooks To hang the cargo net, use the cargo net hooks and rear tie- down hooks. The cargo net itself is not included as an original equip- ment.
  • Page 345 3-6. Other interior features Warning reflector holder Hold the warning reflector with a band. The warning reflector itself is not included as an original equipment. ITY35C025 First-aid kit holder Hold the first-aid kit with a band. The first-aid kit itself is not included as an original equip- ment.
  • Page 346 3-6. Other interior features Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, secu- rity systems, and other devices. ® The garage door opener (HomeLink Universal Transceiver) is manufac- ®...
  • Page 347 3-6. Other interior features ® Programming HomeLink Point the remote control trans- STEP mitter for the device 1 to 3 in. (25 ® to 75 mm) from the HomeLink buttons. ® Keep the HomeLink indicator light in view while programming. ITY35C030 Press and hold one of the STEP...
  • Page 348 3-6. Other interior features ® Test the HomeLink operation STEP by pressing the newly pro- grammed button. ® If a HomeLink button has been programmed for a garage door, check to see if the garage door opens and closes. If the garage door does not operate, see if your ITY35C032 remote control transmitter is of...
  • Page 349 3-6. Other interior features Programming a rolling code system If your device is rolling code equipped, follow the steps under the ® heading “Programming HomeLink ” before proceeding with the steps listed below. STEP Locate the training button on the ceiling mounted garage door opener motor.
  • Page 350 ® the remaining HomeLink buttons. Programming other devices To program other devices such as home security systems, home door locks or lighting, contact your authorized Toyota dealer for assistance. Reprogramming a button ® The individual HomeLink buttons cannot be erased but can be reprogrammed.
  • Page 351 3-6. Other interior features ® Operating HomeLink ® ® Press the appropriate HomeLink button. The HomeLink indicator light should come on. ® The HomeLink compatible transceiver in your vehicle continues to send a signal for up to 20 seconds as long as the button is pressed. ®...
  • Page 352 3-6. Other interior features Before programming Install a new battery in the remote control transmitter. The battery side of the remote control transmitter must be pointed away ® from the HomeLink button. Certification for the garage door opener This device complies with Part 15 of the FCC Rules and with RSS-210 of the IC Rules.

  • Page 353: 4-1. Maintenance And Care

    4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition. l Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
  • Page 354 4-1. Maintenance and care To prevent paint deterioration and corrosion on the body Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads • If you see coal tar or tree sap on the paint surface •...
  • Page 355 4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
  • Page 356 4-1. Maintenance and care Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
  • Page 357 4-1. Maintenance and care NOTICE Cleaning detergents Do not use the following types of detergent, as they may discolor the vehicle interior or cause streaks or damage to painted surfaces. Non-seat portions: Organic substances such as benzene or gasoline, alkaline or acidic solutions, dye, or bleach. Seats: Acidic solutions, such as thinner, benzene, or alcohol.
  • Page 358 It is recommended that genuine Toyota parts be used for repair to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
  • Page 359 4-2. Maintenance Allow inspection and repairs to be performed by a Toyota dealer Toyota technicians are well-trained specialists and are kept up to date with the latest service information. They are well informed about the operations of all systems on your vehicle.
  • Page 360 “Owner’s Warranty Informa- tion Booklet” or “Owner’s Manual Supplement”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment Items...
  • Page 361 4-2. Maintenance Vehicle interior Items Check points • Moves smoothly (without uneven Accelerator pedal pedal effort or catching)? • Can the vehicle be hold securely Automatic transmission “Park” on an incline with the shift lever in mechanism “P”? • Moves smoothly? •...
  • Page 362 4-2. Maintenance Vehicle exterior Items Check points Doors • Operate smoothly? Engine hood • The lock system works properly? • Is there any leakage after park- Fluid leaks ing? • Inflation pressure is correct? • Tire surfaces not worn or dam- aged? Tire •...
  • Page 363 The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/ M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test:...
  • Page 364 Brake fluid level (→P. 398) • Rag or paper towel • Funnel (used only for adding brake fluid) • “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid Engine coolant level (→P.
  • Page 365 4-3. Do-it-yourself maintenance Items Parts and tools • Automatic transmission fluid ® DEXRON II or III Power steering fluid (→P. 400) • Rag or paper towel • Funnel (used only for adding power steering fluid) ⎯ Radiator and condenser (→P. 397) •...
  • Page 366 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury. When working on the engine compartment Keep hands, clothing, and tools away from the moving fan and engine drive belt.
  • Page 367 4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood release lever. STEP The hood will pop up slightly. Lift the hood catch and lift the STEP hood. CAUTION Pre-driving check Check that the hood is fully closed and locked.
  • Page 368 4-3. Do-it-yourself maintenance Engine compartment ITY43C004 Power steering fluid reser- Brake fluid reservoir voir (→P. 400) (→P. 398) Engine oil level dipstick Fuse box (→P. 426) (→P. 391) Washer fluid tank Engine coolant reservoir (→P. 404) (→P. 396) Battery (→P. 401) Cooling fan Condenser (→P.
  • Page 369 4-3. Do-it-yourself maintenance Engine compartment cover Removing the engine compartment cover Installing the clips Push up center portion Insert Press L/C200_U (OM60D97U)
  • Page 370 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. Checking the engine oil STEP Park the vehicle on level ground. After turning off the engine, wait more than five minutes for the oil to drain back into the bottom of the engine.
  • Page 371 4-3. Do-it-yourself maintenance Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. ITY43C011 Make sure to check the oil type and prepare the items needed before adding oil.
  • Page 372 4-3. Do-it-yourself maintenance Recommended viscosity SAE 5W-20 or 0W-20 engine oil may be used. However, SAE 0W-20 is the best choice for good fuel economy and good starting in cold weather. Outside temperature How to read oil container labels The ILSAC (International Lubricant Standardization and Approval Committee) Certification Mark is added to some oil containers to help you select the oil you should use.
  • Page 373 4-3. Do-it-yourself maintenance Engine oil consumption The amount of engine oil consumed depends on the oil viscosity, the quality of the oil and the way the vehicle is driven. More oil is consumed under driving conditions such as high speeds and frequent acceleration and deceleration.
  • Page 374 Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal. Do not leave used engine oil within the reach of children.
  • Page 375 If the coolant level drops within a short time after replenishing Visually check the radiator, hoses, reservoir cap, radiator cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer pressure test the cap and check for leaks in the cooling system. Coolant selection Only use “Toyota Super Long Life Coolant”...
  • Page 376 Check the radiator and condenser and clear any foreign objects. If either of the above parts are extremely dirty or you are not sure of their condition, have your vehicle checked by your Toyota dealer. CAUTION When the engine is hot Do not touch the radiator or condenser as they may be hot and you may be burned.
  • Page 377 4-3. Do-it-yourself maintenance Brake fluid Checking fluid level The brake fluid level should be between the “MAX” and “MIN” lines on the tank. ITY43C069 Make sure to check the fluid type and prepare the necessary items. Adding fluid Fluid type FMVSS No.116 DOT 3 or SAE J1703 brake fluid Items Clean funnel...
  • Page 378 4-3. Do-it-yourself maintenance Brake fluid can absorb moisture from the air Excess moisture in the fluid can cause a dangerous loss of braking effi- ciency. Use only newly opened brake fluid. CAUTION When filling the reservoir Take care because brake fluid can harm your hands or eyes and damage painted surfaces.
  • Page 379 4-3. Do-it-yourself maintenance Power steering fluid Fluid level The fluid level should be within the appropriate range. Full (when hot) Add fluid (when hot) Full (when cold) Add fluid (when cold) ITY43C070 Hot:Vehicle has been driven around 50 mph (80 km/h) for 20 min- utes, or slightly longer in frigid temperatures.
  • Page 380 4-3. Do-it-yourself maintenance CAUTION When checking the reservoir Take care, as the reservoir may be hot. NOTICE When adding fluid Avoid overfilling, or the power steering may be damaged. After replacing the reservoir cap Check the steering box case, vane pump and hose connections for leaks or damage.
  • Page 381 Check the battery condition using the indicator color. Good condition Type A Type B Charging is necessary. Green Blue Have the vehicle inspected by your Toyota dealer. Not working properly, have the Dark White battery checked your Toyota dealer. Clear or light yellow...
  • Page 382 4-3. Do-it-yourself maintenance CAUTION Chemicals in the battery A battery contains poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near bat- tery: Do not cause sparks by touching the battery terminals with tools.
  • Page 383 4-3. Do-it-yourself maintenance NOTICE When recharging the battery Never recharge the battery while the engine is running. Also, be sure all accessories are turned off. Washer fluid If any washer does not work or the warning message appears on the multi-information display, the washer tank may be empty.
  • Page 384 The tire pressure warning system Your Toyota is equipped with a tire pressure warning system that uses tire pressure warning valves and transmitters to detect low tire inflation pressure before serious problems arise. (→P. 465) L/C200_U (OM60D97U)
  • Page 385 Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer. (→P. 406, 408) Initializing the tire pressure warning system...
  • Page 386 4-3. Do-it-yourself maintenance How to initialize the tire pressure warning system Park the vehicle in safe place and turn the “ENGINE START STEP STOP” switch to OFF mode. While the vehicle is moving, initialization is not performed. Adjust the tire inflation pressure to the specified cold tire infla- STEP tion pressure level.
  • Page 387 A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. Replacing tires and wheels If the ID code of the tire pressure warning valve and transmitter is not registered, the tire pressure warning system will not work properly.
  • Page 388 4-3. Do-it-yourself maintenance Maximum load of tire Check that the maximum load of the replaced tire is greater than 1/2 of the Gross Axle Weight Ratings (GAWR) of either the front axle or the rear axle, whichever is greater. As for the maximum load of the tire, see the load limit at maximum cold tire inflation pressure mentioned on the sidewall of the tire, and as for the →...
  • Page 389 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. When operating the tire pressure warning reset switch, the warning light does not flash 3 times and the setting message does not appear on the multi-information display.
  • Page 390 4-3. Do-it-yourself maintenance Tire pressure warning system certification This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 391 Do not mix tires of different makes, models, tread patterns or tread- wear. Do not use tire sizes other than those recommended by Toyota. Do not mix radial, bias-belted, or bias-ply tires. Do not mix summer, all season and winter tires.
  • Page 392 4-3. Do-it-yourself maintenance NOTICE Driving on rough roads Take particular care when driving on roads with loose surfaces or pot- holes. These conditions may cause losses in tire inflation pressure, reducing the cushioning ability of the tires. In addition driving on rough roads may cause damage to the tires themselves, as well as the vehicle’s wheels and body.
  • Page 393 4-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure The recommended cold tire inflation pressure and tire size is dis- played on the tire and loading information label. (→P. 516) L/C200_U (OM60D97U)
  • Page 394 4-3. Do-it-yourself maintenance Inspection and adjustment procedure Tire valve Tire pressure gauge STEP Remove the tire valve cap. Press the tip of the tire pressure gauge onto the tire valve. STEP Read the pressure using the graduations of the gauge. STEP If the tire inflation pressure is not within the recommended STEP...
  • Page 395 Reduced driving comfort and tire life Reduced safety Damage to the drive train If a tire needs frequent refilling, have it checked by your Toyota dealer. Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: Check only when the tires are cold.
  • Page 396 4-3. Do-it-yourself maintenance CAUTION Proper inflation is critical to save tire performance Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury. Excessive wear Uneven wear Poor handling Possibility of blowouts resulting from overheated tires Poor sealing of the tire bead Wheel deformation and/or tire separation A greater possibility of tire damage from road hazards...
  • Page 397 Used wheels l Bent wheels that have been straightened Aluminum wheel precautions l Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. l When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
  • Page 398 4-3. Do-it-yourself maintenance When replacing wheels The wheels of your Toyota are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advanced warning in the event of a loss in tire inflation pressure. Whenever wheels are replaced, the tire pressure warning valves and transmitters must be installed.
  • Page 399 4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be cleaned or changed regularly to maintain air conditioning efficiency. Removal method Turn the “ENGINE START STOP” switch IGNITION ON STEP mode and switch to recirculated air mode, then turn the “ENGINE START STOP”...
  • Page 400 2 minutes at 72 psi (500 kpa, 5.0 kgf/cm bar). If it is not available, have the filter cleaned by your Toyota dealer. Replacement method Remove the air conditioning filter and replace it with a new one.
  • Page 401 4-3. Do-it-yourself maintenance Checking interval Inspect, clean and replace the air conditioning filter according to the mainte- nance schedule. In dusty areas or areas with heavy traffic flow, more fre- quent cleaning or early replacement may be required. (For scheduled maintenance information, read the “Scheduled Maintenance Guide”, “Owner’s Manual Supplement”.) If air flow from the vents decreases dramatically...
  • Page 402 4-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is discharged. You will need the following items: l Flathead screwdriver (To prevent damage to the key, cover the tip of the screwdriver with rag.) l Small Phillips-head screwdriver l Lithium battery CR1632 Replacing the battery...
  • Page 403 The smart key system and wireless remote control will not function prop- erly. The operational range is reduced. Use a CR1632 lithium battery Batteries can be purchased at your Toyota dealer, jewelers, or camera stores. Replace only with the same or equivalent type recommended by a Toyota dealer.
  • Page 404 4-3. Do-it-yourself maintenance CAUTION Removed battery and other parts Keep away from children. These parts are small and if swallowed by a child they can cause choking. NOTICE For normal operation after replacing the battery Observe the following precautions to prevent accidents. Always work with dry hands.
  • Page 405 4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. Turn the “ENGINE START STOP” switch off. STEP Open the fuse box cover. STEP Engine compartment Push the tab in and lift the lid...
  • Page 406 4-3. Do-it-yourself maintenance Passenger’s side instrument panel Remove the cover. ITY43C033 Remove the lid. ITY43C034 After a system failure, see “Fuse layout and amperage rat- STEP ings” (→P. 430) for details about which fuse to check. Remove the fuse with the pull- STEP out tool.
  • Page 407 4-3. Do-it-yourself maintenance Check if the fuse has blown. STEP Type A and B Normal fuse Type A Blown fuse Replace it with one of an appropriate amperage rating. The amperage rating can be found on the fuse box lid. ITY42C012 Type B ITY42C013...
  • Page 408 4-3. Do-it-yourself maintenance Type C and D Normal fuse Type C Blown fuse Contact your Toyota dealer. ITY42C014 Type D ITY42C015 L/C200_U (OM60D97U)
  • Page 409 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings Engine compartment Fuse Ampere Circuit 15 A A/F heater 10 A HORN Horn 25 A EFI MAIN EFI, A/F heater 30 A IG2 MAIN Injector, ignition, meter 50 A RR A/C No circuit 25 A SEAT-A/C LH No circuit...
  • Page 410 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Stoplights, high mounted stop- light, brake controller, towing 15 A STOP converter, ABS, VSC, main body ECU, EFI 30 A TOW BRK Brake controler 50 A RR AUTO A/C Rear blower control 50 A PTC-1 PTC heater 50 A...
  • Page 411 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Driving position memory sys- ECU-B2 No circuit 7.5 A Rear seat entertainment 30 A TOWING Towing 25 A DOOR NO.2 Main body ECU 20 A STR LOCK Steering lock system Meter, front turn signal lights, 15 A TURN-HAZ rear turn signal lights, towing...
  • Page 412 4-3. Do-it-yourself maintenance Fuse Ampere Circuit 15 A HEAD RL Headlight low beam (right) AFM, EVP VSV, 02 SSR, KEY 7.5 A EFI NO.2 OFF PMP, AI DRIVER, AI EX VSV, ACIS VSV 7.5 A RR A/C NO.2 No circuit DEF NO.2 Outside rear view mirror heater L/C200_U (OM60D97U)
  • Page 413 4-3. Do-it-yourself maintenance Driver’s side instrument panel Fuse Ampere Circuit 15 A Cigarette lighter BK/UP LP 10 A Back-up lights, trailer Stereo component amplifier assembly, multi-display assembly, gateway ECU, radio 7.5 A receiver assembly, main body ECU, mirror ECU, rear seat entertainment, smart key sys- tem, clock Four-wheel drive system, ash-...
  • Page 414 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Air conditioning system, heater, overhead module, ABS, VSC, steering sensor, ECU-IG NO.2 10 A yaw rate & G sensor, main body ECU, stoplights, moon roof, clock, EC mirror WINCH No circuit Cool box, condenser fan, cooler compressor, MG CL, A/C IG 10 A...
  • Page 415 4-3. Do-it-yourself maintenance Fuse Ampere Circuit RR DOOR RH 20 A Power windows Mirror ECU, outside rear view 15 A mirror heater RR DOOR LH 20 A Power windows FR DOOR LH 20 A Power windows FR DOOR RH 20 A Power windows RR FOG 7.5 A...
  • Page 416 4-3. Do-it-yourself maintenance Passenger’s side instrument panel ITN42C018 Fuse Ampere Circuit RSF LH 30 A No circuit B/DR CLSR RH 30 A No circuit B/DR CLSR LH 30 A No circuit RSF RH 30 A No circuit DOOR DL 15 A No circuit AHC-B 20 A...
  • Page 417 Never use a fuse of a higher amperage rating than indicated, or use any other object in place of a fuse. Always use a genuine Toyota fuse or equivalent. Never replace a fuse with a wire, even as a temporary fix.
  • Page 418 You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
  • Page 419 4-3. Do-it-yourself maintenance Rear bulb locations Rear turn signal Back-up light light License plate lights ITY43C075 Replacing light bulbs Headlight low beam Turn the bulb base counterclock- STEP wise. ITY43C038 L/C200_U (OM60D97U)
  • Page 420 4-3. Do-it-yourself maintenance Unplug connector while STEP depressing the lock release. ITY43C039 Headlight high beam Turn the bulb base counterclock- STEP wise. ITY43C040 Unplug connector while STEP depressing the lock release. ITY43C041 L/C200_U (OM60D97U)
  • Page 421 4-3. Do-it-yourself maintenance Front fog light Remove the fender liner bolts, STEP loose the fender liner nut and remove the fender liner. Fender liner nut Fender liner bolts Turn the bulb base counterclock- STEP wise. ITY43C042 Unplug the connector while pull- STEP ing the lock release.
  • Page 422 4-3. Do-it-yourself maintenance Parking light Turn the bulb base counterclock- STEP wise. ITY43C048 Remove the light bulb. STEP ITY43C049 L/C200_U (OM60D97U)
  • Page 423 4-3. Do-it-yourself maintenance Front turn signal light For the left side only: Remove STEP the securing bolt and move the washer fluid filler opening. ITY43C012 Turn the bulb base counterclock- STEP wise. ITY43C044 Remove the light bulb. STEP ITY43C045 L/C200_U (OM60D97U)
  • Page 424 4-3. Do-it-yourself maintenance Front side marker light For the left side only: Remove STEP the securing bolt and move the washer fluid filler opening. ITY43C012 Turn the bulb base counterclock- STEP wise. ITY43C050 Remove the light bulb. STEP ITY43C051 L/C200_U (OM60D97U)
  • Page 425 4-3. Do-it-yourself maintenance Back-up light Open the back door and remove STEP the nuts and lamp assembly. ITY43C052 Turn the bulb bases counter- STEP clockwise. ITY43C053 Remove the light bulb. STEP ITY43C054 L/C200_U (OM60D97U)
  • Page 426 4-3. Do-it-yourself maintenance Rear turn signal light Open the back door and remove STEP the bolts and lamp assembly. ITY43C058 Turn the bulb bases counter- STEP clockwise. ITY43C059 Remove the light bulb. STEP ITY43C060 L/C200_U (OM60D97U)
  • Page 427 4-3. Do-it-yourself maintenance License plate light Open the back door and remove STEP the license plate light unit. Turn the bulb base counterclock- STEP wise. ITY43C067 Remove the light bulb. STEP ITY43C068 L/C200_U (OM60D97U)
  • Page 428 LED light bulbs The stop/tail, tail, rear side marker lights and high mounted stoplight consist of a number of LEDs. If any LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced. If two or more LEDs in a stop light burn out, your vehicle may not conform to local laws (SAE).
  • Page 429 4-3. Do-it-yourself maintenance CAUTION Replacing light bulbs Turn off the headlights. Do not attempt to replace the bulb immediately after turning off the headlights. The bulbs become very hot and may cause burns. Do not touch the glass portion of the light bulb with bare hands. Hold the bulb by the plastic or metal portion.
  • Page 430 5-1. Essential information Emergency flashers Use the emergency flashers if vehicle malfunctions or is involved in an accident. Press the switch to flash all the turn signal lights. To turn them off, press the switch once again. ITO51C056 NOTICE To prevent battery discharge Do not leave the emergency flashers on longer than necessary when the engine is not running.
  • Page 431 If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or a flat bed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
  • Page 432 5-1. Essential information Emergency towing procedure STEP The engine must be in ACCESSORY mode (engine off) or IGNI- TION ON mode (engine running). STEP Put the four-wheel drive control switch in “H4”. (The center differen- tial is unlocked.) STEP Put the shift lever in “N”. STEP Release the parking brake.
  • Page 433 5-1. Essential information Towing with a sling-type truck NOTICE To prevent body damage Do not tow with a sling type truck, either from the front or rear. L/C200_U (OM60D97U)
  • Page 434 5-1. Essential information Towing with a wheel lift-type truck From front Use a towing dolly under the rear wheels. From rear Use a towing dolly under the front wheels. NOTICE To prevent causing serious damage to the transmission Never tow this vehicle wheels on the ground. To prevent damaging the vehicle Do not tow the vehicle with the “ENGINE START STOP”...
  • Page 435 5-1. Essential information Using a flat bed truck If your Toyota is transported by a flat bed truck, it should be tied down at the locations shown in the illustration. When attaching the hooks to the rear of the vehi- cle, make sure to attach them to the inside of the vehicle.
  • Page 436 5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms l Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
  • Page 437 5-1. Essential information Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or an air- bag inflates upon collision, the fuel pump shut off system stops sup- plying fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
  • Page 438 5-1. Essential information Event data recorder Your vehicle has computers that monitor and control certain aspects of your vehicle. These computers assist in driving and maintaining optimal vehicle performance. Besides storing data useful for troubleshooting, there is a system to record data in a crash or a near car crash event.
  • Page 439 5-1. Essential information Disclosure of the data Toyota will not disclose the data recorded in an EDR to a third party except when: l An agreement from the vehicle’s owner (or the leasing company for a leased vehicle) is obtained...
  • Page 440 Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous. The following warning indicates a possible problem in the brake sys- tem. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Brake system warning light (warning buzzer) •...
  • Page 441 Charging system warning light Indicates a malfunction in the vehicle’s charging system. Have the vehicle inspected by your Toyota dealer immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident.
  • Page 442 5-2. Steps to take in an emergency Warning light Warning light/Details ABS warning light Malfunction in: • The ABS; or • The brake assist system. Pre-collision system warning light (if equipped) Malfunction in the pre-collision system. Have the malfunction repaired immediately. After taking the specified steps to correct the suspected problem, check that the warning light turns off.
  • Page 443 Low tire inflation pressure. pressure. When the light comes on after blinking for 1 minute: Have the system checked Malfunction in the tire by your Toyota dealer. pressure warning system. Unengaged “Park” warn- ing light Shift four-wheel drive con- The transmission “Park”...
  • Page 444 5-2. Steps to take in an emergency Warning light Warning light/Details Correction procedure Low fuel level warning light Indicates that remaining Refuel the vehicle. fuel is about 4.0 gal. (15.0 L, 3.3 Imp. gal.) or less. Master warning light A buzzer sounds and the Take appropriate action in warning light comes on accordance with the mes-...
  • Page 445 In this case, you may not be able to transfer between “H4” and “L4” modes, and the center differential lock may not be able to be locked or unlocked. Have the vehicle inspected by your Toyota dealer imme- diately.
  • Page 446 5-2. Steps to take in an emergency SRS warning light This warning light system monitors the following: The airbag sensor assembly Front airbag sensors The curtain shield airbag sensors The side and curtain shield airbag sensors The seat belt buckle switches The driver’s seat position sensor The inflators The interconnecting wiring and power sources...
  • Page 447 If there is a lot of snow or ice on the vehicle, in particular around the wheels or wheel housings. If non-genuine Toyota wheels are used. (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.)
  • Page 448 If the tire pressure warning light comes on after blinking 1 minute fre- quently when the “ENGINE START STOP” switch is turned to IGNITION ON mode, have it checked by Toyota dealer. CAUTION If the tire pressure warning light comes on Be sure to observe the following precautions.
  • Page 449 5-2. Steps to take in an emergency CAUTION Maintenance of the tires Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label).
  • Page 450 5-2. Steps to take in an emergency CAUTION Your vehicle has also been equipped with a TPMS (tire pressure warning system) malfunction indicator to indicate when the system is not operat- ing properly. The TPMS (tire pressure warning system) malfunction indi- cator is combined with the low tire pressure telltale (tire pressure warning light).
  • Page 451 Multi-information display If any of the warning messages is shown again after its correction procedure has been performed, contact your Toyota dealer. Messages and warnings The warning lights and warning buzzers operate as follows depend- ing on the content of the message. If a message indicates the need for inspection by a dealer, have the vehicle inspected immediately by your Toyota dealer.
  • Page 452 5-2. Steps to take in an emergency System Warning warning Warning buzzer light Indicates an important situation, such as when a system related to ⎯ Comes on Sounds driving is malfunctioning or that danger may result if the correction procedure is not performed. Indicates an important situation, Comes such as when the system shown...
  • Page 453 (→P. 406) If the message remains on, the system may have malfunctioned. Have the vehicle inspected by your Toyota dealer as soon as possible. Warning messages in the cruise control mode In the following instances, there is a possibility that the approach warning will not illuminate even when vehicle-to-vehicle distance is closing.
  • Page 454 5-2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare provided. Before jacking up the vehicle l Stop the vehicle on a hard, flat surface. l Set the parking brake. l Shift the shift lever to “P”.
  • Page 455 5-2. Steps to take in an emergency Taking out the jack Remove the cover. STEP Loosen STEP Tighten Loosen and remove the jack. L/C200_U (OM60D97U)
  • Page 456 5-2. Steps to take in an emergency Taking out the tool box Remove the cover. STEP Take out the tool box. STEP L/C200_U (OM60D97U)
  • Page 457 5-2. Steps to take in an emergency Assemble the jack handle (in the tool box) Assemble the jack handle exten- sion as shown. Be sure to tighten each bolt securely. Taking out the spare tire Remove the cover. STEP Insert the jack handle extension STEP into the lowering screw.
  • Page 458 5-2. Steps to take in an emergency Lower the spare tire completely STEP to the ground. ITY51C031 Pull out the spare tire and STEP remove the holding bracket. ITY52C032 L/C200_U (OM60D97U)
  • Page 459 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. STEP Flat tire Wheel chock position Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire In front of the front right-hand side Left-hand side tire Rear...
  • Page 460 5-2. Steps to take in an emergency Slightly loosen the wheel nuts STEP (one turn). Position the jack at the jack STEP points as shown. Front - Under the chassis frame side rail Rear - Under the rear axle hous- L/C200_U (OM60D97U)
  • Page 461 5-2. Steps to take in an emergency Assemble the jack handle exten- STEP sion as shown. Be sure to tighten each bolt securely. Raise the vehicle until the tire is STEP slightly raised off the ground. Remove all the wheel nuts and STEP the tire.
  • Page 462 5-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- STEP ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, and the tire may come off the vehicle.
  • Page 463 5-2. Steps to take in an emergency Firmly tighten each nut two or STEP three times in the order shown in the illustration. Tightening torque: 97 ft•lbf (131 N•m, 13.4 kgf•m) Reinstall the wheel ornament. STEP Stowing the flat/spare tire, jack and tools Lay down the tire with the outer STEP side facing up, and install the...
  • Page 464 5-2. Steps to take in an emergency After completing the tire change The tire pressure warning system must be reset. (→P. 406) CAUTION Using the tire jack Improper use of the tire jack may lead to death or injuries due to the vehicle suddenly falling off the jack.
  • Page 465 5-2. Steps to take in an emergency CAUTION Replacing a flat tire Observe the following precautions to reduce the risk of death or serious injury. Lower the spare tire completely to the ground before removing it from under the vehicle. Do not try to remove the wheel ornament by hand.
  • Page 466 When replacing the tires When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled cor- rectly.
  • Page 467 5-2. Steps to take in an emergency If the engine will not start If the engine still does not start after following the correct starting procedure (→P. 151) or releasing the steering lock (→P. 153), confirm the following points. The engine will not start when the starter motor operates normally.
  • Page 468 One or both of the battery terminals may be disconnected. l The battery may be discharged. (→P. 497) l There may be a malfunction in the steering lock system. Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function When the engine does not start, the following steps can be used as an interim measure to start the engine if the “ENGINE START STOP”...
  • Page 469 (a system to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.
  • Page 470 5-2. Steps to take in an emergency If you lose your keys New genuine Toyota keys can be made by your Toyota dealer using one of the other keys and the key number stamped on your key num- ber plate.
  • Page 471 If the back door opener does not operate, there may be a problem with the back door opener system. Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the back door can be opened from the inside.
  • Page 472 5-2. Steps to take in an emergency If the electronic key does not operate properly If communication between the electronic key and vehicle is inter- rupted (→P. 26) or the electronic key cannot be used because the battery is depleted, the smart key system and wireless remote con- trol cannot be used.
  • Page 473 5-2. Steps to take in an emergency Changing “ENGINE START STOP” switch modes and starting the engine Shift the shift lever to “P” and apply the brakes. STEP Touch the Toyota emblem side of STEP electronic “ENGINE START STOP” switch. An alarm will sound to indicate...
  • Page 474 5-2. Steps to take in an emergency Stopping the engine Shift the shift lever to “P” and press the “ENGINE START STOP” switch as you normally do when stopping the engine. Replacing the key battery As this above procedure is a temporary measure, it is recommended that the electronic key battery be replaced immediately when the battery depletes.
  • Page 475 You can call your Toyota dealer or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12 volt battery, you can jump start your Toyota following the steps below.
  • Page 476 STEP cables in the exact reverse order in which they were con- nected. Once the engine starts, have the vehicle checked at your Toyota dealer as soon as possible. Starting the engine when the battery is discharged The engine cannot be started by push-starting.
  • Page 477 5-2. Steps to take in an emergency CAUTION Avoiding battery fires or explosions Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the battery. Make sure the jumper cable is connected to the correct terminal and that it is not unintentionally in contact with any part other than the intended termi- nal.
  • Page 478 5-2. Steps to take in an emergency NOTICE When handling jumper cables Be careful that the jumper cables do not become tangled in the cooling fan or any of the belts when connecting or disconnecting them. L/C200_U (OM60D97U)
  • Page 479 If the fan is operating: Wait until the engine coolant temperature gauge begins to fall and then stop the engine. If the fan is not operating: Stop the engine immediately and call your local Toyota dealer. After the engine has cooled STEP...
  • Page 480 Water can be used in an emer- gency measure if coolant is unavailable. (→P. 512) TY51C047 Have the vehicle checked at your nearest Toyota dealer as soon as possible. Overheating In the following situations, your vehicle may be overheating. The engine coolant temperature gauge enters the red zone or a loss of power is experienced.
  • Page 481 5-2. Steps to take in an emergency NOTICE When adding engine coolant Wait until the engine has cooled down before adding engine coolant. When adding coolant, do so slowly. Adding cool coolant to a hot engine too quickly can cause damage to the engine. L/C200_U (OM60D97U)
  • Page 482 5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. Stop the engine. Set the parking brake and shift the shift STEP lever in “P”.
  • Page 483 5-2. Steps to take in an emergency NOTICE To avoid damaging the transmission and other components Avoid spinning the wheels and do not rev the engine. If the vehicle remains stuck after trying these procedures, the vehicle may require towing to be freed. L/C200_U (OM60D97U)
  • Page 484 5-2. Steps to take in an emergency L/C200_U (OM60D97U)
  • Page 485 6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weights Overall length 194.9 in. (4950 mm) Overall width 77.6 in. (1970 mm) Overall height 74.0 in. (1880 mm) Wheelbase 112.2 in. (2850 mm) Front 64.6 in. (1640 mm) Tread Rear 64.4 in.
  • Page 486 Vehicle identification number The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
  • Page 487 6-1. Specifications Engine Model 3UR-FE Type 8-cylinder V type, 4-cycle, gasoline 3.70 × 4.02 in. (94.0 × 102.0 mm) Bore and stroke Displacement 345.6 cu.in. (5663 cm Valve clearance Automatic adjustment (engine cold) Drive belt tension Automatic adjustment Fuel Fuel type Unleaded gasoline only Octane rating 87 (Research octane number 91) or higher...
  • Page 488 7.4 qt. (7.0 L, 6.2 lmp.qt.) Without filter 7.0 qt. (6.6 L, 5.8 lmp.qt.) Oil grade ILSAC multigrade engine oil Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the above grade and vis- cosity. Recommended oil viscosity...

  • Page 489: Ignition System

    Cooling system Capacity 16.3 qt. (15.4 L, 13.6 lmp.qt.) Use either of the following: • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based non- Coolant type silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technol- Do not use plain water alone.
  • Page 490 Toyota Genuine Differential gear oil LT viscosity 75W-85 GL-5 or equivalent “Toyota Genuine Differential Oil” is filled in your Toyota vehicle at factory fill. Use Toyota approved “Toyota Genuine Differential Gear Oil” or an equivalent of matching quality to satisfy the above specification. Please contact your Toyota dealer for further details.

  • Page 491: Automatic Transmission

    Toyota Genuine ATF WS NOTICE Automatic transmission fluid type Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the transmission of your vehicle.
  • Page 492 6-1. Specifications Chassis lubrication Propeller shafts Spider Lithium base chassis grease, NLGI No.2 Slide yoke Molybdenum-disulfide lithium base chas- sis grease, NLGI No.2 or lithium base chassis grease, NLGI No.2 Steering Free play Less than 1.18 in. (30 mm) ® Automatic transmission fluid DEXRON Power steering fluid type or III...
  • Page 493 6-1. Specifications Tires and wheels Tire size P285/60R18 114V Normal driving Front tires: 33 psi (230 kPa, 2.3 kgf/cm or bar) Rear tires: 33 psi (230 kPa, 2.3 kgf/cm or bar) Spare tire: Tire inflation pressure 33 psi (230 kPa, 2.3 kgf/cm or bar) (Recommended cold tire Trailer towing...
  • Page 494 6-1. Specifications Light bulbs Light Bulbs Bulb No. Type Headlights Low beam 9006 High beam 9005 ⎯ Front turn signal lights ⎯ Parking lights Exterior ⎯ Front side marker lights ⎯ Front fog lights Rear turn signal lights 7440 Back-up lights License plate lights ⎯...
  • Page 495 At minimum, the gasoline you use should meet the specifications of ASTM D4814 in the U.S.A. Fuel tank opening for unleaded gasoline To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. If your engine knocks Consult your Toyota dealer.
  • Page 496 Toyota allows the use of oxygenate blended gasoline where the oxygen- ate content is up to 10% ethanol or 15% MTBE. If you use gasohol in your Toyota, be sure that it has an octane rating no lower than 87.
  • Page 497 Toyota does not recommend gasoline containing MMT Some gasoline contains octane enhancing additive called MMT (Methylcy clopentadienyl Manganese Tricarbonyl). Toyota DOES NOT recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected.
  • Page 498 6-1. Specifications Tire information Typical tire symbols ITY61C010 Tire size (→P. 523) Summer tire or all season tire (→P. 409) An all season tire has “M+S” on the sidewall. A tire not marked “M+S” is a summer tire. Uniform tire quality grading For details, see “Uniform Tire Quality Grading”...
  • Page 499 6-1. Specifications Maximum cold tire inflation pressure (→P. 526) This means the pressure to which a tire may be inflated. TUBELESS or TUBE TYPE A tubeless tire does not have a tube and air is directly filled in the tire. A tube type tire has a tube inside the tire and the tube main- tains the air pressure.
  • Page 500 6-1. Specifications Tire size Typical tire size information The illustration indicates typical tire size. Tire use P285/60R18 114V (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio ITY61C011 (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 or 3 digits)
  • Page 501 U.S.A. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. DOT quality grades All passenger vehicle tires must conform to Federal Safety Requirements in addition to these grades.
  • Page 502 6-1. Specifications Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a speci- fied government test course. For example, a tire graded 150 would wear one and a half (1 - 1/2) times as well on the government course as a tire graded 100.
  • Page 503 6-1. Specifications Warning: The temperature grades for this tire are established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either sepa- rately or in combination, can cause heat buildup and possible tire fail- ure.
  • Page 504 6-1. Specifications Tire related term Meaning 150 lb. (68 kg) times the number of occupants Normal occupant specified in the second column of Table 1 that weight follows Distribution of occupants in a vehicle as speci- Occupant distribution fied in the third column of Table 1 below The combined weight of installed regular pro- duction options weighing over 5 lb.
  • Page 505 6-1. Specifications Tire related term Meaning The load on an individual tire that is determined by distributing to each axle its share of curb Vehicle normal load weight, accessory weight, and normal occu- on the tire pant weight (distributed in accordance with Table 1 below), and dividing it by two The surface area of the rim not covered by the...
  • Page 506 6-1. Specifications Tire related term Meaning A tire designed to operate at higher loads and Extra load tire at higher inflation pressures than the corre- sponding standard tire Groove The space between two adjacent tread ribs The layer(s) forming the inside surface of a Innerliner tubeless tire that contains the inflating medium within the tire...
  • Page 507 6-1. Specifications Tire related term Meaning The linear distance between the exteriors of the sidewalls of an inflated tire, including eleva- Overall width tions due to labeling, decorations, or protective bands or ribs A tire intended for use on passenger cars, mul- tipurpose passenger vehicles, and trucks, that Passenger car tire have a gross vehicle weight rating (GVWR) of...
  • Page 508 6-1. Specifications Tire related term Meaning A tire that attains a traction index equal to or greater than 110, compared to the ASTM E- 1136 Standard Reference Test Tire, when using the snow traction test as described in ASTM F-1805-00, Standard Test Method for Snow tire Single Wheel Driving Traction in a Straight Line on Snow-and Ice-Covered Surfaces, and which...

  • Page 509: Vehicle

    6-1. Specifications Designated seating Occupant distribution in Vehicle normal load, capacity, Number of a normally loaded Number of occupants occupants vehicle 2 through 4 2 in front 2 in front, 1 in second 5 through 10 seat 2 in front, 1 in second 11 through 15 seat, 1 in third seat, 1 in fourth seat...
  • Page 510 Programming these preferences requires specialized equipment and may be performed by an autho- rized Toyota dealership. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer for further details. Customized Item Function...
  • Page 511 6-2. Customization Customized Item Function Default setting setting Driver’s door unlocked in All doors one step, all Unlocking using a key unlocked in one doors step unlocked in two steps Speed-detecting auto- Door lock matic door lock function (→P. 43) Shift the shift lever to position other than “P”...
  • Page 512 6-2. Customization Customized Item Function Default setting setting 7.5 seconds Time period before 15 seconds lights turn off 30 seconds Operation after the “ENGINE START STOP” switch is turned Operation when the Illumination doors are unlocked (→P. 338) Operation when you approach the vehicle with the electronic key on your person (When...
  • Page 513 6-2. Customization Multi-information display (→P. 170) English (U.S.A.), English (UK), French, Available languages German, Spanish, Italian, Japanese, Sim- plified Chinese and Traditional Chinese L/C200_U (OM60D97U)
  • Page 514 6-3. Initialization Items to initialize The following items must be initialized for normal system operation in cases such as after the battery is reconnected, or maintenance is performed on the vehicle. Item When to initialize Reference Engine oil mainte- After changing engine oil P.
  • Page 515 6-3. Initialization L/C200_U (OM60D97U)
  • Page 516 If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
  • Page 517 Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Anti-lock Brake System Automatic Locking Retractor Auxiliary Child Restraint System DISP Display Electronic Controlled Transmission Electronic Control Unit Event Data Recorder Emergency Locking Retractor GAWR Gross Axle Weight Rating GVWR Gross Vehicle Weight Rating Emission inspection and maintenance Intermittent KDSS...
  • Page 518 Abbreviation list ABBREVIATIONS MEANING Tire Identification Number TPMS Tire Pressure Warning System TRAC Traction Control Vehicle Identification Number Vehicle Stability Control L/C200_U (OM60D97U)
  • Page 519 Alphabetical index Alphabetical index Audio input ......295 Air conditioning filter....420 AUX adapter ......295 Automatic air conditioning CD player/changer ....277 system ........254 MP3/WMA disc ..... 285 ABS ...........212 Optimal use......293 Active traction control.....212 Portable music player ... 295 Air conditioning filter....420 Radio........
  • Page 520 Installing CRS with top Display straps ......... 135 Crawl Control display ....208 Child safety Trip information .....171 Airbag precautions ....110 Toyota park assist system Battery precautions ..403, 425 display.........192 Child-protectors ...... 44 Shift position and shift Child restraint system... 123 range........158 How your child should wear Warning messages ....473...
  • Page 521 Alphabetical index Wireless remote control key..40 Engine Doors Compartment ......389 Back door ........48 Engine switch......151 Side door.........43 Hood ........388 Side mirrors......82 How to start the engine ..151 Driver’s seat belt reminder Identification number..... 509 light .........465 If the engine will not start ..
  • Page 522 Alphabetical index Wattage ........ 517 Hill-start assist control ....212 Front passenger’s seat belt Hood..........388 reminder light......465 Hooks Front seats Cargo hook......364 Adjustment ......51 Tie-down hooks.....364 Driving position memory..62 Horn...........163 Front side marker light Replacing light bulbs .... 439 I/M test........384 Wattage ........
  • Page 523 Alphabetical index Keys ........24 Moon roof ........88 Mechanical key .......24 MP3 disc ........285 Wireless remote control key..40 Multi-information display ..170 Language Odometer........164 Multi-information Off-road precautions ....220 display......170, 536 Licence plate lights Engine oil ......391 Replacing light bulbs .....439 Opener Wattage.........517 Fuel filler door ......91...
  • Page 524 Alphabetical index Rear turn signal lights Cleaning ........376 Replacing light bulbs .... 439 Driver’s seat position Wattage ........ 517 memory.........62 Rear window defogger.... 268 Front seat adjustment .....51 Rear window wiper....185 Head restraint......66 Replacing Properly sitting in the seat..100 Fuses........
  • Page 525 Dinghy towing ....... 250 Power window switch ....85 Emergency towing ....453 Rear window wiper and Trailer towing ......238 washer switch .....185 Toyota park assist system..192 Window lock switch ....85 TRAC......... 212 Wipers and washer Traction control ....... 212 switch......179, 182 Trailer towing ......
  • Page 526 Alphabetical index Warning buzzers Wireless remote control key Brake system......462 Replacing the battery ....423 Open door ......464 Wireless remote control key..40 Seat belt reminder ....465 WMA disc........285 Warning lights Anti-lock brake system ..464 Brake system......462 Charging system ....
  • Page 527 What to do if... What to do if... A tire punctures If you have a flat tire P. 476 P. 95 Engine immobilizer system The engine does not start P. 489 If the engine will not start If the battery is discharged P.
  • Page 528 What to do if... STRT CRUISE RSCA A/T P ITYPC053 nWarning lights Brake system warning Driver’s seat belt reminder light light P. 462 P. 465 Front passenger’s seat ABS warning light belt reminder light P. 464 SRS warning light P. 463 P.
  • Page 529 What to do if... L/C200_U (OM60D97U)
  • Page 530 What to do if... L/C200_U (OM60D97U)

  • Page 531: Gas Station Information

    (L, Imp.qt.) drain and refill With filter 7.4 (7.0, 6.2) (Reference) Without filter 7.0 (6.6, 5.8) “Toyota Genuine Motor Oil” or equivalent Engine oil type Oil grade: ILSAC multigrade engine oil P. 511 Recommended oil viscosity: SAE 0W-20, 5W-20 L/C200_U (OM60D97U)

Table of Contents
