SSV IGW/925 How-To

How to change the sim card
Hide thumbs
Table of Contents

Advertisement

Quick Links

IGW/925
How to Change the SIM Card
microHowTo
SSV Embedded Systems
Dünenweg 5
D-30419 Hannover
Phone: +49 (0)511/40 000-0
Fax:
+49 (0)511/40 000-40
Manual Revision: 1.0
E-mail: sales@ssv-embedded.de
Date: 2013-05-03
F
.
-
.
OR FURTHER INFORMATION REGARDING OUR PRODUCTS PLEASE VISIT US AT WWW
SSV
EMBEDDED
DE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IGW/925 and is the answer not in the manual?

Questions and answers

Related Manuals for SSV IGW/925

Summary of Contents for SSV IGW/925

  • Page 1 IGW/925 How to Change the SIM Card microHowTo SSV Embedded Systems Dünenweg 5 D-30419 Hannover Phone: +49 (0)511/40 000-0 Fax: +49 (0)511/40 000-40 Manual Revision: 1.0 E-mail: sales@ssv-embedded.de Date: 2013-05-03 OR FURTHER INFORMATION REGARDING OUR PRODUCTS PLEASE VISIT US AT WWW...

  • Page 2: Table Of Contents

    IGW/925 microHowTo - How to Change the SIM Card CONTENT INTRODUCTION....................... 3 Safety Guidelines ........................3 Conventions ..........................3 CHANGING THE SIM CARD .................... 4 Step 1..............................4 Step 2..............................5 Step 3..............................6 Step 4..............................7 Step 5..............................8 Step 6..............................9 Step 7..............................10 HELPFUL LITERATURE....................12 CONTACT ..........................

  • Page 3: Introduction

    IGW/925 microHowTo - How to Change the SIM Card INTRODUCTION This document describes how to change the SIM card of the socket modem inside the IGW/925. Safety Guidelines Please read the following safety guidelines carefully! In case of property or personal damage by not paying attention to this document and/or by incorrect handling, we do not assume liability.

  • Page 4: Changing The Sim Card

    IGW/925 microHowTo - How to Change the SIM Card CHANGING THE SIM CARD ATTENTION: Please follow the safety guidelines in chapter 1.1 before you start! Step 1 Use a screwdriver to push open the two lockings on top of the case like shown in figure 1.

  • Page 5: Step 2

    IGW/925 microHowTo - How to Change the SIM Card Step 2 Now use the screwdriver to push open the two lockings at the bottom of the case like shown in figure 2. Please be careful and do not push too strong! Figure 2: Pushing open the bottom lockings of the case M a n u a l R e v i s i o n 1 .

  • Page 6: Step 3

    IGW/925 microHowTo - How to Change the SIM Card Step 3 Now pull the two parts of the case apart like shown in figure 3. Figure 3: Pulling the case open M a n u a l R e v i s i o n 1 . 0...

  • Page 7: Step 4

    IGW/925 microHowTo - How to Change the SIM Card Step 4 You now can see the SIM card holder. Unlock the holder by gently pushing its top part like shown in figure 4. Figure 4: Unlocking the SIM card holder...

  • Page 8: Step 5

    IGW/925 microHowTo - How to Change the SIM Card Step 5 Now flip open the holder and insert the new SIM card into the holder in the same orienta- tion like shown in figure 5. Figure 5: Inserting a new SIM card...

  • Page 9: Step 6

    IGW/925 microHowTo - How to Change the SIM Card Step 6 Close the SIM card holder and gently push the top part like shown in figure 6 to lock the holder again. Figure 6: Locking the SIM card holder M a n u a l R e v i s i o n 1 . 0...

  • Page 10: Step 7

    IGW/925 microHowTo - How to Change the SIM Card Step 7 To close the case it is very important to carefully slide the boards into the bearings of the case and push the two parts gently together. Figure 7 shows the top bearings.
  • Page 11 IGW/925 microHowTo - How to Change the SIM Card Figure 8 shows the bottom bearings. Figure 8: Sliding the boards into the bottom bearings Just push the case together until the four lockings snap in. That’s all! M a n u a l R e v i s i o n 1 . 0...

  • Page 12: Helpful Literature

    IGW/925 microHowTo - How to Change the SIM Card HELPFUL LITERATURE • IGW/925 hardware reference manual CONTACT SSV Embedded Systems Dünenweg 5 D-30419 Hannover / Germany Phone: +49 (0)511/40 000-0 Fax: +49 (0)511/40 000-40 E-mail: sales@ssv-embedded.de Internet: www.ssv-comm.de Support: www.ssv-comm.de/forum...
