Page 1: Hardware Reference
Remote Maintenance Gateway RMG/941(L,N) with DNP/9535 Hardware Reference SSV Software Systems GmbH Dünenweg 5 D-30419 Hannover Phone: +49 (0)511/40 000-0 Fax: +49 (0)511/40 000-40 Document Revision: 1.0 Email: sales@ssv-embedded.de Date: 2019-12-10... -
Page 2: Table Of Contents
Remote Maintenance Gateway RMG/941(L,N) – Hardware Reference CONTENT INTRODUCTION ....................... 3 Safety Guidelines ........................3 Conventions ........................... 3 Features and Technical Data ....................4 RMG/941L: Features LTE Module ..................5 RMG/941N: Features NB-IoT Module ................... 5 OVERVIEW ........................6 PINOUTS .......................... 7 Ethernet Interface ........................ -
Page 3: Introduction
Remote Maintenance Gateway RMG/941(L,N) – Hardware Reference INTRODUCTION This document describes the basic hardware components of the Remote Maintenance Gateway RMG/941(L,N). Safety Guidelines Please read the following safety guidelines carefully! In case of property or personal damage by not paying attention to this manual and/or by incorrect handling, we do not assume liability. -
Page 4: Features And Technical Data
Remote Maintenance Gateway RMG/941(L,N) – Hardware Reference Features and Technical Data Processor Manufacturer / Type Atmel ATSAM-A5D35 SoC Clock speed 528 MHz Memory 256 MB SDRAM Flash 4 MB NOR memory Storage media 1x internal microSD card holder Interfaces Ethernet 1x 10/100 Mbps (RJ45) Serial I/Os 1x RS485 serial port (screw terminal) -
Page 5: Rmg/941L: Features Lte Module
Remote Maintenance Gateway RMG/941(L,N) – Hardware Reference RMG/941L: Features LTE Module LTE Module Mobile radio standards GSM/UMTS/HSPA+/LTE Transfer rates 150 Mbps peak download, 50 Mbps peak upload Frequency bands LTE B1/B3/B5/B7/B8/B20 Frequency bands B1/B5/B8 WCDMA Frequency bands GSM850/GSM900/DCS1800/PCS1900 GSM/GPRS Authentication PAP, CHAP, CHAT, none Supported APNs Telekom, Vodafone, 02, E-Plus, user-defined... -
Page 6: Overview
RMG/941(L,N) – Hardware Reference OVERVIEW Figure 1: Overview RMG/941(L,N) D o c u m e n t R e v i s i o n 1 . 0... -
Page 7: Pinouts
Remote Maintenance Gateway RMG/941(L,N) – Hardware Reference PINOUTS Ethernet Interface Pin Name Function 10/100 Mbps LAN, TX+ 10/100 Mbps LAN, TX- 10/100 Mbps LAN, RX+ Bob-Smith Termination Bob-Smith Termination 10/100 Mbps LAN, RX- Bob-Smith Termination Bob-Smith Termination Table 5: Pinout Ethernet interface Function Green (left) 10/100BASE-T link/activity... -
Page 8: Service Port
Remote Maintenance Gateway RMG/941(L,N) – Hardware Reference Service Port Pin Name Function RXD1 COM1 Serial Port: RS232 RXD TXD1 COM1 Serial Port: RS232 TXD Ground COM1 Serial Port: Remote Console Mode CTS1 COM1 Serial Port: RS232 CTS RTS1 COM1 Serial Port: RS232 RTS Table 8: Pinout service port = Cable bridge... -
Page 9: Sim Card
Remote Maintenance Gateway RMG/941(L,N) – Hardware Reference SIM CARD The internal SIM card of the RMG/941L and RMG/941N can be changed through the slot on the backside. To remove the SIM card just push it gently with a screw driver until you hear a soft "click". The SIM card is ejected a few millimeters and can be pulled out easily. -
Page 10: Helpful Literature
Information in this document is provided ‘as is’ without warranty of any kind. Some names within this document can be trademarks of their respective holders. © 2019 SSV SOFTWARE SYSTEMS GmbH. All rights reserved. D o c u m e n t R e v i s i o n 1 . 0...
