Configuration and Setting guide ONE Compact

Recommendation: Turn on the pre-amplifier only when the input signal level is too low (below

60 dBμV). Users may consult the automatic power level measurement of the input signal

when adding a channel on the ONE Compact.

NOTE

If the target channel's signal level is low, but other channels on the same input have a high level, these

could be saturating the pre-amplifier and causing bad signal quality. Consult the quality of all the

reception channels to decide whether to turn the pre-amplifier on or not.

3.3.2 Output adjustments (Output level/Slope)

• The output level may be adjusted between 93 and 113 dBµV

• The slope may be adjusted between 0 and -9 dB

The more channels that are added, the lower the output power will be that must be adjusted.

Software update:

In order to update the software, press the

Then press

Select file

update.

There are three different types of software updates that may be performed:

• Channel filter: This affects the behaviour of the filters.

• MCU: This update affects the behaviour of the system.

• Table of frequencies: This update affects the channels that depend on the chosen country or region.

to choose the correct file and then on the

button in Software updating on the following page.

ONE Compact_v1.1.7

button, followed by

Yes

to start the
