Playnation 07-0022 Manual

Megaphone mounting the pivot brackets

TOOLS REQUIRED: SMALL PHILLIPS SCREWDRIVER OR P2 BIT WITH ELECTRIC SCREWDRIVER

PARTS INCLUDED:

1- MEGAPHONE WITH RUBBERIZED MOUTH PIECE ATTACHED

2-PIVOT BRACKETS

2-L-SHAPED MOUNTING BRACKETS

7-M4 X 30mm PHILLIPS COUNTERSUNK HEAD SCREWS

1: PLACE THE MEGAPHONE BETWEEN THE TWO PIVOT BRACKETS.

2: ATTACH THE TWO PIVOT BRACKETS TOGETHER WITH AN M4 x 30mm PHILLIPS COUNTERSUNK

HEAD SCREW .

M4 x 30mm

PHILLIPS COUNTERSUNK

HEAD SCREW

MEGAPHONE (07-0022)

MOUNTING THE PIVOT BRACKETS

NOTE: IF YOU HAVE TROUBLE ALIGNING THESE PARTS

PLACE THE SLOT IN ONE OF THE L-SHAPED MOUNTING

BRACKETS OVER BOTH OF THESE FLANGES TO ALIGN

THEM. THEN INSTALL THE SCREW. THEN REMOVE THE L-

SHAPED BRACKET.

*FOR RESIDENTIAL USE ONLY*

*FOR CHILDREN AGES 3-11*

MEGAPHONE

PIVOT BRACKETS

RUBBERIZED

MOUTH PIECE

DO NOT USE

IF MISSING.

Table of Contents

Do you have a question about the 07-0022 and is the answer not in the manual?

Page 1 MEGAPHONE (07-0022) MOUNTING THE PIVOT BRACKETS TOOLS REQUIRED: SMALL PHILLIPS SCREWDRIVER OR P2 BIT WITH ELECTRIC SCREWDRIVER PARTS INCLUDED: 1- MEGAPHONE WITH RUBBERIZED MOUTH PIECE ATTACHED 2-PIVOT BRACKETS 2-L-SHAPED MOUNTING BRACKETS 7-M4 X 30mm PHILLIPS COUNTERSUNK HEAD SCREWS 1: PLACE THE MEGAPHONE BETWEEN THE TWO PIVOT BRACKETS.
Page 2 MEGAPHONE (07-0022) MOUNTING TO 4 X 4 BOARD 1: CENTER THE MEGAPHONE ON TOP OF THE 4 X 4 BOARD. 2: PLACE THE PIVOT BRACKETS ON TOP OF 4 X 4 BOARD AND ATTACH WITH THE M4 x 30mm PHILLIPS COUNTERSUNK HEAD SCREWS PROVIDED.
Page 3 MEGAPHONE (07-0022) MOUNTING TO 2 X 4 BOARD 1: PLACE ONE OF THE "L" SHAPED BRACKET AGAINST THE 2 X 4 BOARD SO THAT THE BRACKET SECTION WITH THE CUTOUT FACES UP. FASTEN THE "L" SHAPED BRACKET TO THE 2 X 4 BOARD WITH THE M4 x 30mm PHILLIPS COUNTERSUNK HEAD SCREWS PROVIDED.
