Playnation Chill 'N Manual

Chill 'N Swing with Glider Brackets (04-0031)
1. The Chill 'N Swing comes with a two ropes on each side fastened to steel rings. The steel
ring is approximately 2" in diameter on the outside and is approximately 1/4" thick. The
distance from the bottom of the swing to the top of the ring is approximately 71". This
distance may be adjusted by tying knots in the ropes underneath the swing seat.
The Chill 'N Swing seat is approximately 43-1/2" L x 21-1/2" W. The seat has a metal perimeter
frame with foam padding on the outside perimeter. The frame is wrapped in nylon strapping.
The seat surface is made of nylon web strap material which is wrapped around the frame
and then stitched to itself. Individual web straps are woven and sewn together.
2.See page 3 for instructions to install the Glider Brackets and hang the Chill 'N Swing.
3. A distance of 8" should exist between the outside surface of the Chill 'N Swing seat and any
adjacent swing or swing structure. Also, a minimum of 8" should exist between the bottom of
the Chill 'N Swing Seat and the protective surfacing on the ground.
4. Safety comes first when swinging. Always obey the safety rules when swinging and when
walking around a swing set. We have included a Safety Tips Guide on page 2.
5. Chill 'N Swing Weight Limit: 220 lbs. Also, do not exceed the weight limit of the swing
hangers or swing beam.
Tie knots
in ropes under
seat to adjust
height of swing. Seat
43-1/2"L x 21-1/2"W
*FOR RESIDENTIAL USE ONLY*
*FOR CHILDREN AGES 3-11*
Dual ropes
on each side
Example of
Glider Brackets.
See page 3 for
installation details.
1
