Table 4-8. H Code Descriptions And Instruction Functions For - Hurco WINMAX Programming Manual

This table lists the Descriptions and Instruction Functions for the H codes used in the G65
macro instructions:
H Code Description
H01 Definition, Substitution
H02 Addition
H03 Subtraction
H04 Product
H05 Division
H11 Logical Sum
H12 Logical Product
H13 Exclusive OR
H21 Square Root
H22 Absolute Value
H23 Remainder
H24 Conversion from BCD to Binary
H25 Conversion from binary to BCD
H26 Combined Multiplication/Division
H27 Combined Square Root 1
H28 Combined Square Root 2
H31 Sine
H32 Cosine
H33 Tangent
H34 Arc tangent
H80 Unconditional Divergence (GOTO)
H81 If Statement, Equals
H82 If Statement, Not Equal
H83 If Statement, Greater Than
H84 If Statement, Less Than
H85 If Statement, Greater Than/Equals
H86 If Statement, Less Than/Equals
Table 4–8. H Code Descriptions and Instruction Functions for G65 Macro Instructions
WinMax Lathe NC Programming
Instruction Function
#a = #b
#a = #b + #c
#a = #b - #c
#a = #b * #c
#a = #b / #c
#a = #b .OR. #c
#a = #b .AND. #c
#a = #b .XOR. #c
#a = Ö#b
#a = |#b|
#a = #b - trunc (#b/#c) * #c
trunc: discard fractions less than 1.
#a = BIN(#b)
#a = BCD(#b)
#a = (#a * #b) / #c
#a = Ö(#b2 + #c2)
#a = Ö(#b2 - #c2)
#a = #b * SIN(#c)
#a = #b * COS (#c)
#a = #b * TAN(#c)
#a = TAN(#b/#c)
GOTO a
IF #b = #c, GOTO a
IF #b ¹ #c, GOTO a
IF #b > #c, GOTO a
IF #b < #c, GOTO a
IF #b >= #c, GOTO a
IF #b <= #c, GO TO a
704-0115-307 ISNC G Codes 4-43
