Battery Level Indicator
When the battery level indicator has no black bars showing, it means the battery is close to depletion.
To warn the user of this, the radio will start beeping periodically as well as flashing the backlight of the
display, indicating that the battery needs to be changed.
Status LED
The status LED has a very simple and traditional design. When a signal is received, it turns green, when
transmitting, it turns red, and is off when in standby.
Side Button 1 – Call (Broadcast FM and alarm)
Press [CALL] momentarily to start the broadcast FM receiver. Another momentary press turns the
broadcast FM receiver off. Press and hold to [CALL] activate the alarm function. Press again to turn it off.
Side Button 2 – MONI (Monitor and Flashlight)
Press [MONI] momentarily to turn on the LED flashlight. Another momentary press turns the flashlight
off. Press and hold [MONI] to monitor the signal. This will open up the squelch and permit listening to
the unfiltered signal.
VFO / MR – Mode Button
Pressing [VFO/MR] switches between Frequency (VFO) Mode and Memory (MR) Mode. Memory mode
is sometimes also referred to as Channel mode. To save frequencies to channel memory the radio must
be in Frequency (VFO) mode.
A/B – Select Button
The [A/B] button switches between A (upper) and B (lower) displays. The frequency or channel on the
selected display becomes the active listening and transmit frequency or channel. To save frequencies to
channel memory the radio must be set to use the A display.

Numeric Keypad

The device comes standard with a full numeric keypad:
