Power too high for the amount of water
■
Excessive hand pressure applied
■
No water spray
Water line blocked or kinked
■
Water fi lter clogged
■
Water canal in insert blocked
■
No water supply
■
Water bottles empty
■
Insert does not go into handpiece
Lubricate 'O' ring with water and use
■
twisting motion to seat insert
Insert falls out of handpiece or water leaks
from front of handpiece
'O' ring damaged or worn. Replace 'O'
■
ring on insert.
Additional Specifi cations:
Protection Against Electric Shock—Class
■
1, Type B applied part
Equipment not suitable for use in the
■
presence of a fl ammable anesthetic mixture
(when used with air or with oxygen).
Protection Against Ingress of Liquids—
■
Foot Switch & Scaler - IPX1 (drip-proof),
Power Supply - IPX0 (Ordinary)
Mode of Operation of Equipment—
■
Intermittent: 66% duty cycle, 10 minutes
on, 5 minutes off.
Operating conditions: 15-35°C, 10-80%
■
RH (non-condensing)
Transport and Storage conditions: 10-
■
40°C, 10-80% RH (non-condensing)
As an additional safety feature, the
■
microprocessor will reduce the output
power in the unlikely event the device is
left running, other than in normal usage.
European Authorized Representative (Not a dealer/distributor): EMERGO EUROPE
Molenstraat 15, 2513 BH, The Hague, The Netherlands • Tel: +31 (0)70 345 8570 • Fax: +31 (0)70 346 7299
300 Executive Drive, Edgewood, NY 11717
Toll-Free: 1-800-243-7446 • Phone: 631-249-1134 • Fax: 631-249-1242
E-mail: info@parkell.com • www.parkell.com • Made in U.S.A.
This equipment produces electromagnetic
energy and may cause interference with
other electronic devices. Should this occur,
changing the positioning or location of the
device may be necessary.
The power supply line cord is the AC power
disconnect device for the scaler.
The symbol on the scaler indicates the
Protective Earth connection.
The symbol or
alert the user to the presence of important
operating and maintenance (servicing)
instructions in the literature accompanying
the scaler.
Service:
The handpiece sheath, power supply, foot
pedal, water fi lter, dip tubes, bottles and
ultrasonic inserts are all detachable and may
be replaced by the user. Contact Parkell for
a list of authorized inserts. Otherwise, there
are No User Serviceable Items in this scaler,
including the foot controller.
For service, return the unit freight prepaid
and carefully packed to Parkell Repair Dept.,
300 Executive Drive, Edgewood, NY 11717,
with an explanation of problem. During the
warranty period, the unit will be repaired and
returned to you. After the warranty period,
we will call with an estimate and request
approval.
If you have any questions or a problem with
the installation or use of your scaler, please
call our Toll-Free Technical Support Service
at 1-800-243-7446 from 9am to 5:30pm
Eastern time (outside USA and Canada,
call 631-249-1134).
is intended to
