parkell TurboSENSOR D560-110 Instructions For Use Manual

This manual, in whole or in part, should not be considered a substitute for formal training in Ultrasonic Scaling.
Appropriate professional education is STRONGLY RECOMMENDED prior to using this device clinically.
DEVICE DESCRIPTION
The Parkell TurboSENSOR™ is an autotune
magnetostrictive ultrasonic tooth scaler that
operates at either 25 KHz or 30 KHz.
The TurboSENSOR automatically detects
whether the handpiece contains a 25 KHz or
30 KHz insert, and switches to the correct
operating frequency. The TurboSENSOR has
an expanded low-power range to improve
patient comfort during debridement, and a
power-boosting, user-controlled Turbo feature
to increase scaling power when needed for
heavy deposits. The unit is designed to work
with Parkell inserts. For information about
usage with non-Parkell inserts, please see
our warranty policy.
INTENDED USE/INDICATIONS:
For removal of calculus, plaque and oral debris
from teeth during dental prophylaxis/scaling.
CONTRAINDICATIONS TO USE
Because of the potential for electromagnetic
interference, this device should not be used on
patients or by clinicians with cardiac
pacemakers, internal defibrillators,
intracorporeal fluid pumps or any other
25KHZ OR 30KHZ INSERTS:
Device automatically switches
operating frequency to match
(insert not included).
WATER CONTROL
CAUTION: RX ONLY
AUTOCLAVABLE REMOVABLE
KNOB
Indicates low-power range where
large changes in knob produce
subtle changes in tip amplitude.
STOCK NO. D560-110
STOCK NO. D560-230
STOCK NO. D560-100
implantable electronic devices, or in close
proximity to sensitive patient monitoring
devices such as pulse oximeters.
WARNINGS
• The water supply to the scaler should always
be turned off whenever the device is being
connected, disconnected, or when not in use.
• The power supply cord functions as the AC
power disconnect device for the scaler.
• The transformer should be located above and
away from any sources of water that may
enter the unit. As with all electrical devices,
the unit should not be immersed in water or
other liquids. Do not reach for the device if it
has fallen into liquid until power is
disconnected, and do not use the device after
it has fallen into liquid. Return the device to
Parkell for servicing.
• Modification of this device will void the
warranty, and may violate safety codes,
endangering the patient and/or the clinician.
• This equipment is not suitable for use in the
presence of a flammable anesthetic gas
mixture (when used along with air or oxygen).
HANDPIECE SHEATH.
"PERIO" LIGHT:
INSTRUCTIONS FOR USE
24-HOUR SAFETY HOTLINE
1-800-535-5053
"TURBO" LIGHT:
Indicates the device is operating
in high-power "Turbo" mode
(footswitch fully depressed).
(110VAC)
(230VAC)
(100VAC)
A00414revL0218
"ON" INDICATOR:
Lights only when
footswitch is
depressed.
