parkell Integra D680 Manual page 2

Dip Tube
Easily-removable dual reservoirs
give you a choice of irrigants
Ultrasonic inserts are not included with the
Parkell Integra. However, this scaler will
accept any scaler insert manufactured by
Parkell, Cavitron/Dentsply
or other "Cavitron-compatibles".
Specifi cations:
Operating frequencies - 25KHz and
■
30KHz
Operates at room temperature between
■
50°F and 95°F (10°C - 35°C)
Weight: 35 oz. / Dimensions: 5"W x 6"H
■
x 11.5"D
Power: l20VAC model - 60Hz, 120VA;
■
230VAC model - 50Hz, 120VA; 100VAC
model - 50/60Hz, 120VA;
Locating your Integra Scaler:
• Locate the device where the control
panel will be easy to reach during
scaling procedures.
• The scaler requires a grounded electrical
outlet and optionally, a source of drinking
Figure 1
Power
Foot Pedal
Easy-to-clean touch panel resists all
Digital fl uid and power
controls mean fast,
precise settings (Use
the Smart Foot Pedal
for hands-free power
adjustment.)
Automatically adjusts operating
frequency to match either 25KHz
or 30KHz inserts
, Hu-Friedy ,
® ®
External water
fl ow regulator
External water
connection
standard disinfectants
quality, sediment free water at 20-50 psi.
We suggest that an external water fi lter be
used to minimize the frequent changes
of the device's in-line water fi lter.
Change the in-line fi lter when it becomes
visibly discolored.
• The scaler and its separate transformer
generate a minimal amount of heat. Avoid
covering them, as this will prevent normal
cooling by the air.
Connecting your Integra to the Water
Supply:
Before plugging in the device, connect
the scaler's water line to a supply of
drinking quality water (20-50psi). The
male quick-connect that comes on the
end of the water hose is the same as that
currently fi tted to the Cavitron
you are replacing an older scaler that uses
a different type of connection, remove the
fi tting from the old unit and attach it to the
water line.
External
water
source
Internal
bottle
Autoclavable Handpiece-holder
handpiece mounts on left
sheaths or right
scaler. If
®
Rear
bottle
Front
bottle
