- Page 1 ALP RANGE: ALP BAS C, ALP 1HBF C, ALP 4HBSM C, ALP WMBAS C, ALP WMBF C, ALP 2HBF C Installation Instructions & User Guide IMPORTANT: Please keep this booklet for future reference and request of replacement parts.
-
Page 2: Table Of Contents
Contents Thank you for choosing Bristan, the UK’s leading taps and showers expert. We have designed this product with your enjoyment in mind. To ensure that it works to its full potential, it needs to be fitted correctly. These fitting instructions have been created to give you all of the information you need and, if you need any further help, please do not hesitate to contact us. -
Page 3: Important Safety Information
Important Safety Information • Please read these instructions thoroughly and retain for future use. • All products manufactured and supplied by Bristan are safe provided they are installed, used correctly and receive regular maintenance in accordance with these instructions. •... -
Page 4: General Information
General Information This product has been tested to the Water Regulations Advisory Scheme (WRAS) and satisfies the requirements of the Water Supply (Water Fittings) Regulations 1999 and current bylaws. For full Installation Requirements & Notes (IRN) please visit www.wras.co.uk/directory. Designed to comply with BS EN 200 for combination taps to be used within systems designed to BS 6700. -
Page 5: Specifications
Specifications Working pressure Minimum Product Code Inlet distance from cold water tank to outlet (metres) ALP BAS C M10 15mm Compression Flexible Tails ALP 1HBF C M16 22mm Compression Flexible Tails ALP 4HBSM C M16 22mm Compression Flexible Tails ALP WMBAS C 15mm Compression Threaded Tail ALP WMBF C 15mm Compression Threaded Tail... -
Page 6: Dimensions
Dimensions Basin Mixer Basin Mixer 1 Hole Bath Filler Dimensions are approximate and in millimetres. - Page 7 Dimensions Cont. Bath Shower Mixer Bath Shower Mixer Wall Mounted Basin Mixer 120 135 Dimensions are approximate and in millimetres.
- Page 8 Dimensions Cont. Wall Mounted Bath Filler 120 140 2 Hole Bath Filler Dimensions are approximate and in millimetres.
-
Page 9: Installation Requirements
Installation Requirements Flexible Connecting Pipes Care must be taken when connecting the flexible connection pipes to the household pipework to ensure they do not bend sharply and kink or twist. See below for recommended ways to fit the flexible connecting pipes. Slight 90°... -
Page 10: Installation
Installation Basin Mixer / 1 Hole Bath Filler 1. Screw the flexi tails into the bottom of the mixer body / bath filler by hand only (DO NOT OVERTIGHTEN). 2. Feed the flexi tails through the hole in the basin/bath, ensuring the washer is fitted between the body and the basin/ bath to create a water tight seal. -
Page 11: Bath Shower Mixer
Installation Cont. Bath Shower Mixer 1. Fit the spout and the side body to the bath ensuring that the washers are fitted between the bodies and the fixing surface to create a water tight seal. 2. Secure the spout to the bath using the washer and metal backnut. - Page 12 Installation Cont. Bath Shower Mixer Cont. 7. Connect the side body to the diverter using the flexi tail supplied. 8. Connect the spout to the diverter using the flexi tail supplied. 9. Fit the shower head holder to the bath. Remove the backnut and the washers and feed the threaded tail through the hole in the bath.
-
Page 13: Wall Mounted Basin Mixer And Bath Filler
Installation Cont. Wall Mounted Basin Mixer and Bath Filler 1. Remove the spout from the basin mixer / bath filler by loosing the grub screw. 2. Decide on the final position of the basin mixer/ bath filler. Install suitable battons into the wall cavity if required. -
Page 14: Hole Bath Filler
Installation Cont. 2 Hole Bath Filler 1. Fit the spout and the side body to the bath ensuring that the washers are fitted between the bodies and the fixing surface to create a water tight seal. 2. Secure the spout to the bath using the washer and metal backnut. -
Page 15: Maintenance
If necessary replace the cartridge using parts supplied by Bristan only. Replace the cartridge into the body. Replace the cartridge shroud, shroud cover and the handle. Tighten the grub... -
Page 16: Troubleshooting
Troubleshooting Symptom Cause Remedy No flow or low Partially closed isolation valve. Open isolation valve. flow rate Instantaneous water heater Increase water flow rate or cycles on and off as flow rate or pressure through system to pressure is too low. meet required minimum working pressure of tap. -
Page 17: Notes
Notes Please use this space to add any notes you or your installer may have regarding the plumbing system / installation of this product. -
Page 18: Guarantee
Bristan Guarantee At Bristan, we want to make things as easy as possible for our customers. That’s why we offer solid guarantees on all our products, effective from the date of purchase, to give you peace of mind. To start your free guarantee, simply scan the QR code and register your product. - Page 20 This Booklet covers product codes ALP BAS C, ALP 1HBF C, ALP 4HBSM C, ALP WMBAS C, ALP WMBF C, ALP 2HBF C Helpline 0330 026 6273 Bristan Group Ltd. Birch Coppice Business Park Dordon Tamworth Staffordshire B78 1SG A Masco Company Web: www.bristan.com...
