- Page 1 Part No. 217314-B Rev 00 May 2006 4655 Great America Parkway Santa Clara, CA 95054 Installing the 8660 Service Delivery Module (SDM)
- Page 2 In the interest of improving internal design, operational function, and/or reliability, Nortel Networks Inc. reserves the right to make changes to the products described in this document without notice. Nortel Networks Inc. does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.
- Page 3 CE Marking Statement (Europe only) EN 55022 Statements This is to certify that the Nortel Networks 8000 Series Chassis and components installed within the chassis are shielded against the generation of radio interference in accordance with the application of Council Directive 89/336/EEC.
- Page 4 CE Marking Statement (Europe Only) EN 60950 Statement This is to certify that the Nortel Networks 8000 Series Chassis and components installed within the chassis are in compliance with the requirements of EN 60950 in accordance with the Low Voltage Directive. Additional National Differences for all European Union Countries have been evaluated for compliance.
- Page 5 Norma Oficial Mexicana (NOM): Exporter: Nortel Networks, Inc. 4401 Great America Parkway Santa Clara CA 95052 USA Importer: Nortel Networks de México, S.A. de C.V. Avenida Insurgentes Sur #1605 Piso 30, Oficina Col. San Jose Insurgentes Deleg-Benito Juarez México D.F. 03900...
- Page 6 30 days of purchase to obtain a credit for the full purchase price. “Software” is owned or licensed by Nortel Networks, its parent or one of its subsidiaries or affiliates, and is copyrighted and licensed, not sold. Software consists of machine-readable instructions, its components, data, audio-visual content (such as images, text, recordings or pictures) and related licensed materials including all whole or partial copies.
- Page 7 (for DoD entities). Customer may terminate the license at any time. Nortel Networks may terminate the license if Customer fails to comply with the terms and conditions of this license. In either event, upon termination, Customer must either return the Software to Nortel Networks or certify its destruction.
- Page 8 217314-B Rev 00...
-
Page 9: Table Of Contents
Getting help from the Nortel Web site ........ - Page 10 Installing and replacing an 8660 SDM ........
- Page 11 8660 SDM FW4 LEDs ........
- Page 12 Figures Figure 30 Removing the faceplate screws ....... . 55 Figure 31 Removing the console port standoffs .
- Page 13 Tables Table 1 Maximum number of 8660 SDM cards ......21 Table 2 8660 SDM LEDs ..........22 Table 3 iSD LEDs .
- Page 14 Tables 217314-B Rev 00...
-
Page 15: Preface
This guide is intended for qualified service personnel who need to install or replace an 8660 SDM in the chassis, or a firewall iSD in the 8660 SDM board. A qualified service person must have appropriate technical training and experience and be aware of the hazards involved in installing and replacing customer-replaceable units. -
Page 16: Hard-Copy Technical Manuals
Hard-copy technical manuals You can print selected technical manuals and release notes free, directly from the Internet. Go to the www.nortel.com/documentation URL. Find the product for which you need documentation. Then locate the specific category and model or version for your hardware or software product. Use Adobe* Acrobat Reader* to open the manuals and release notes, search for the sections you need, and print them on most standard printers. -
Page 17: How To Get Help
Latest documentation Nortel page for Ethernet Routing Switch documentation. Getting help from the Nortel Web site The best way to get technical support for Nortel products is from the Nortel Technical Support Web site: www.nortel.com/support This site provides quick access to software, documentation, bulletins, and tools to address issues with Nortel products. -
Page 18: Getting Help Over The Phone From A Nortel Solutions Center
Getting help over the phone from a Nortel Solutions Center If you do not find the information you require on the Nortel Technical Support Web site, and you have a Nortel support contract, you can also get help over the phone from a Nortel Solutions Center. -
Page 19: Chapter 1 About The 8660 Sdm
Service Director (iSD). The model name identifies the number of PrPMCs and disk drives that are included on the 8660 SDM board. For example, the SDM FW1 has one PrPMC and one disk drive; the SDM FW2 has two PrPMCs and two hard drives, and so on. -
Page 20: Figure 1 Sdm Fw4
20 Chapter 1 About the 8660 SDM Figure 1 SDM FW4 Firewall iSD Disk drive PrPMC Note: Firewall iSDs are installed from right to left (that is, for a FW1, the iSD is in mini-slot 4 of the SDM FW1 board; for a FW2, the firewall iSDs are installed in mini-slots 3 and 4, and so on). -
Page 21: 8660 Sdm Faceplate
11196EA 5 = Online LED Table 1 lists the maximum number of 8660 SDM boards that can be installed in each type of chassis. Note: The number of SDM cards that are supported in 8006 and 8010 chassis for Threat Protection System (TPS) configurations (TPS1-FW1, TPS2-FW2, and TPS4) is the same as those for Firewall configurations. -
Page 22: 8660 Sdm Leds
22 Chapter 1 About the 8660 SDM 8660 SDM LEDs The 8660 SDM has the following LEDs to indicate status: • “Online” LED that indicates the overall status of the module • Management port LEDs Figure 3 shows the location of the LEDs on the SDM FW4. -
Page 23: Firewall Isd Leds
Chapter 1 About the 8660 SDM 23 Firewall iSD LEDs Figure 4 shows the location of the LEDs on each firewall iSD. Table 3 on page 24 describes the LED colors. Figure 4 iSD LEDs Online WALL Utilization Activity 8660SDM... -
Page 24: Table 3 Isd Leds
24 Chapter 1 About the 8660 SDM Table 3 iSD LEDs Label Color/State Meaning Utilization Green/steady The number of lit LEDs indicates the level of kernel CPU utilization as follows: 1 LED ≥ 25% 2 LEDs = 50% 3 LEDs = 75%... -
Page 25: Maintenance Port
The Ethernet management port on the 8660 SDM is an MDI 10/100/1000Base-T port. Serial port The 8660 SDM has one serial port for attaching console devices. The console port provides terminal access to the 8660 SDM for the Command Line Interface (CLI). For information about pin assignments for this port, see “Console serial port”... - Page 26 26 Chapter 1 About the 8660 SDM 217314-B Rev 00...
-
Page 27: Installing The 8660 Sdm
Chapter 2 Installing the 8660 SDM This chapter provides instructions for installing and connecting the 8660 SDM in an 8003, 8006, 8010, or 8010co chassis. This chapter includes the following topics: Topic Page Chassis configuration requirements Preparing for installation Removing and installing a chassis filler panel... -
Page 28: Preparing For Installation
Install the 8660 SDM according to instructions in this chapter. Ensure that the first module is fully initialized prior to inserting the second (if you are inserting an 8660 SDM in a chassis where another 8660 SDM is already installed). See Firewall and Intrusion Sensor User Guide for instructions to configure the 8660 SDM. -
Page 29: Required Tools
Chapter 2 Installing the 8660 SDM 29 Required tools You require the following tools to remove or install a chassis filler panel: Phillips #0 or #1 screwdriver. Removing a chassis filler panel To remove a chassis filler panel: Use a Phillips screwdriver to loosen the two captive screws that fasten the filler panel to the chassis. -
Page 30: Installing A Chassis Filler Panel
30 Chapter 2 Installing the 8660 SDM Figure 6 Removing a filler panel from an 8010co chassis Fa il Pa ss 10227FA Pull the filler panel away from the slot. Installing a chassis filler panel To install a chassis filler panel: Locate the slot where you want to install the filler panel. -
Page 31: Installing And Replacing An 8660 Sdm
The estimated time to remove an 8660 SDM is 15 minutes. The estimated time to install an 8660 SDM is 15 minutes. Required tools You require the following tools to install or remove an 8660 SDM: Phillips #0 or #1 screwdriver. Installing the 8660 Service Delivery Module (SDM) -
Page 32: Removing An 8660 Sdm
Firewall configurations are stored in the disk drives that reside on the 8660 SDM. Therefore, when you replace an 8660 SDM with another, you must configure the iSDs on the new 8660 SDM, unless all disk drives in the two SDM boards were previously identically programmed. -
Page 33: Figure 7 Loosening Screws On The Sdm Fw4: 8003, 8006, Or 8010 Chassis
Chapter 2 Installing the 8660 SDM 33 To remove an 8660 SDM: Disconnect any cables attached to the ports of the 8660 SDM. Use a Phillips screwdriver to loosen the two captive screws that secure the 8660 SDM to the... -
Page 34: Figure 9 Ejecting The Sdm Fw4: 8003, 8006, Or 8010 Chassis
34 Chapter 2 Installing the 8660 SDM Rotate the insert/extract levers to eject the 8660 SDM from the chassis (see Figure 9 Figure 10). Figure 9 Ejecting the SDM FW4: 8003, 8006, or 8010 chassis 9397FA Figure 10 Ejecting the SDM FW4: 8010co chassis... -
Page 35: Figure 11 Removing An Sdm Fw4: 8003, 8006, Or 8010 Chassis
36). Caution: Ensure that the IDE cable(s) attached to the disk drive(s) does not get caught in a module above or beside the 8660 SDM when removing the module from the chassis. Figure 11 Removing an SDM FW4: 8003, 8006, or 8010 chassis... -
Page 36: Figure 12 Removing An Sdm Fw4: 8010Co Chassis
Figure 12 Removing an SDM FW4: 8010co chassis Fa il Pa ss 11202FA If you are installing a replacement 8660 SDM, see “Installing an 8660 SDM” on page 37. Otherwise, install a filler panel (see “Installing a chassis filler panel” on page 30). -
Page 37: Installing An 8660 Sdm
Chapter 2 Installing the 8660 SDM 37 Installing an 8660 SDM You can install an 8660 SDM with the chassis power on or off. In a new installation, Nortel recommends that you install all the modules before turning on the chassis power. -
Page 38: Figure 13 Installing An Sdm Fw4: 8003, 8006, Or 8010 Chassis
Co ns ole Acti vity On line 11205FA Figure 14 Installing an SDM FW4: 8010co chassis Fa il Pa ss 11203FA Slide the 8660 SDM into the chassis until its connector panel touches the chassis back panel. 217314-B Rev 00... -
Page 39: Figure 15 Seating The Backplane Connectors: 8003, 8006, Or 8010 Chassis
Chapter 2 Installing the 8660 SDM 39 Rotate the insert/extract levers to seat the 8660 SDM backplane connectors (see Figure 15 Figure 16). Figure 15 Seating the backplane connectors: 8003, 8006, or 8010 chassis F IR E W A On line... -
Page 40: Figure 17 Securing The Sdm Fw4 In The Chassis: 8003, 8006, Or 8010 Chassis
40 Chapter 2 Installing the 8660 SDM Use a Phillips screwdriver to tighten the two captive screws that secure the 8660 SDM to the chassis (see Figure 17 Figure 18 on page 41). Note: Ensure that both screws are tight for proper module operation. -
Page 41: Figure 18 Securing The Sdm Fw4 In The Chassis: 8010Co Chassis
Chapter 2 Installing the 8660 SDM 41 Figure 18 Securing the SDM FW4 in the chassis: 8010co chassis Fa il Pa ss 11204FA Installing the 8660 Service Delivery Module (SDM) -
Page 42: Turning On The Chassis Power
42 Chapter 2 Installing the 8660 SDM Turning on the chassis power To turn on the chassis power: Verify that all power cords are connected properly, and as described in the installation instructions for the power supplies. Turn all the power switches to the “On” position. -
Page 43: Replacing The Disk Drives
Put on an antistatic wrist strap. Halt all the disk drive on the SDM Firewall board. Nortel recommends that you log in from the 8600 console to connect to the iSD, then go to the boot menu to halt the iSD. -
Page 44: Estimated Time To Replace A Disk Drive
Remove the installed 8660 SDM. For instructions, see “Removing an 8660 SDM” on page Place the 8660 SDM on an antistatic bag or set it on an antistatic mat. Remove the damaged disk drive (see “Removing a disk drive” on page 45). -
Page 45: Removing A Disk Drive
You can loosen this screw by hand, or use a #1 Phillips head screwdriver. Figure 19 Loosening the disk drive captive screw 11208GA Slide the two disk drive tabs out of the two slots on the 8660 SDM tray (see Figure 20). -
Page 46: Figure 21 Disk Drive Connector
46 Chapter 3 Replacing the disk drives Disconnect the 44-pin disk drive cable from either the connector on the disk drive, or from the connector on the PrPMC (see Figure 21). Hold the disk drive firmly while disconnecting the cable. Figure 21 Disk drive connector 11209FA 217314-B Rev 00... -
Page 47: Installing A Disk Drive
Chapter 3 Replacing the disk drives 47 Installing a disk drive Connect the 44-pin disk drive cable to the disk drive connector (see Figure 22). Note: The red stripe on the edge of the 44-pin disk drive cable is the pin one indicator. -
Page 48: Figure 23 Connecting The Disk Drive Cable To The Prpmc Connector
23). Figure 23 Connecting the disk drive cable to the PrPMC connector 11209FA Slide the two disk drive tabs into the two slots on the 8660 SDM tray (see Figure 24). Figure 24 Sliding the disk drive tabs into the slots on the SDM FW2 tray... -
Page 49: Figure 25 Fastening The Disk Drive
Chapter 3 Replacing the disk drives 49 Tighten the captive screw that fastens the disk drive to the 8660 SDM tray (see Figure 25). Tighten this screw by hand, or use a Phillips screwdriver. Figure 25 Fastening the disk drive... - Page 50 50 Chapter 3 Replacing the disk drives 217314-B Rev 00...
-
Page 51: Chapter 4 Replacing A Prpmc
To prevent static discharge damage when you work with the 8660 SDM or the PrPMC, place each module on a grounded antistatic mat until you are ready to install it, or leave the module in the sealed Electrostatic Discharge (ESD) bag. -
Page 52: Estimated Time To Replace A Prpmc
• 3/16-inch nutdriver Removing a PrPMC Caution: Disk drives must be halted prior to removing an 8660 SDM from the chassis. Failure to do so can seriously damage the disk drive, and cause loss of data. Refer to “Replacing a disk drive on the 8660 SDM”... -
Page 53: Figure 26 Locating The Installed Prpmc On An Sdm Fw4
Chapter 4 Replacing a PrPMC 53 Remove the 8660 SDM from the 8600 series chassis. See “Removing an 8660 SDM” on page Locate the installed PrPMC (indicated by the numbers 1, 2, 3, and 4 in Figure 26) on the 8660 SDM. -
Page 54: Figure 28 Removing The Stiffener Screws
54 Chapter 4 Replacing a PrPMC Place the 8660 SDM on an antistatic bag, or set it on an antistatic mat. Remove the disk drive that sits behind the PrPMC that you will remove. See “Removing a disk drive” on page... -
Page 55: Figure 30 Removing The Faceplate Screws
30). Note: There are both fine-pitch and medium-pitch screws located along the bottom edge of the 8660 SDM faceplate. Remove the five medium-pitch screws only. These five screws secure the faceplate. Nortel recommends using a Phillips #0 to remove these screws. -
Page 56: Figure 32 Removing The Faceplate From The Sdm Fw4
56 Chapter 4 Replacing a PrPMC 10 Remove the faceplate from the 8660 SDM (see Figure 32). Figure 32 Removing the faceplate from the SDM FW4 11216FA 11 Use a Phillips screwdriver to remove the four bottom screws that secure each... -
Page 57: Figure 34 Sdm Fw4 Components Facing Up
Chapter 4 Replacing a PrPMC 57 12 Turn the 8660 SDM over so that the components are facing up (see Figure 34). Figure 34 SDM FW4 components facing up 11236EA 13 Use a Phillips screwdriver to remove the two screws that secure the back of... -
Page 58: Figure 36 Removing The Prpmc
58 Chapter 4 Replacing a PrPMC 14 Grasp the edges of the PrPMC. 15 Pull it straight up, and lift it out (see Figure 36). Figure 36 Removing the PrPMC 11219FA 16 Place the PrPMC in an antistatic bag, or set it on an antistatic mat. 17 Continue with “Installing a PrPMC”... -
Page 59: Installing A Prpmc
FW1, the iSD is in slot 4 of the SDM FW1 tray; for a FW2, the iSDs are installed in slots 3 and 4, and so on). Place the 8660 SDM on an antistatic bag, or set it on an antistatic mat. Hold the PrPMC with the components facing up (see Figure 37). -
Page 60: Figure 38 Seating The Prpmc In The Connector
Figure 38 Seating the PrPMC in the connector 11222FA Use a Phillips screwdriver to insert and tighten the two screws that secure the back of the PrPMC to the 8660 SDM (see Figure 39). Figure 39 Securing the back of the PrPMC... -
Page 61: Figure 40 Sdm Fw4 With Components Facing Down
Chapter 4 Replacing a PrPMC 61 Turn the 8660 SDM over so that the components are facing down (see Figure 40). Figure 40 SDM FW4 with components facing down 11213EA Use a Phillips screwdriver to insert and tighten the four bottom screws that... -
Page 62: Figure 42 Placing The Faceplate Against The Sdm Fw4 Tray
62 Chapter 4 Replacing a PrPMC Place the faceplate against the front of the 8660 SDM tray (see Figure 42). Figure 42 Placing the faceplate against the SDM FW4 tray 11225FA Use a 3/16-inch nutdriver to install the two console port standoffs (see Figure 43). -
Page 63: Figure 44 Securing The Faceplate
8660 SDM (see Figure 44). Figure 44 Securing the faceplate 11226FA 11 Turn the 8660 SDM over so the components are facing up (see Figure 45). Figure 45 SDM FW4 components facing up 11236EA Installing the 8660 Service Delivery Module (SDM) -
Page 64: Figure 46 Securing The Stiffener Screws
64 Chapter 4 Replacing a PrPMC 12 Insert and tighten the four screws that secure the stiffeners to the board (see Figure 46). Figure 46 Securing the stiffener screws 11208JA 13 Install the disk drive for the firewall iSD. See “Installing a disk drive”... -
Page 65: Removing And Installing A Prpmc Filler Panel
Chapter 4 Replacing a PrPMC 65 Removing and installing a PrPMC filler panel Nortel ships the SDM FW1 and FW2 with a filler panel covering each empty module slot. Before you install a new PrPMC, you must remove the appropriate filler panel. -
Page 66: Removing A Prpmc Filler Panel
Locate the slot where you must install the filler panel. Place the filler panel over the slot Use a Phillips screwdriver to insert and tighten the two screws that secure the filler panel to the 8660 SDM faceplate. 217314-B Rev 00... -
Page 67: 8660 Sdm Specifications
Appendix A 8660 SDM specifications This appendix includes the following topics: Topic Page Specifications Management port Console serial port Installing the 8660 Service Delivery Module (SDM) -
Page 68: Specifications
8660 SDM specifications Specifications Note: The following hardware specifications for SDM FW1, FW2, and FW4 are the same as when used with the Threat Protection System (TPS). Table 4 lists the specifications for the SDM FW1, FW2, and FW4. Table 4 Specifications for the SDM FW1, FW2, and FW4... -
Page 69: Management Port
The management port is a 10/100/1000Base-T Ethernet port implemented on an RJ-45 connector wired as an MDI connection. Table 5 shows the pin assignments for this connector. Table 5 Pin assignments: 8660 SDM management port Connector Pin number Signal Output transmit data + (TX+) -
Page 70: Table 6 Pin Assignments: 8660 Sdm Console Port
8660 SDM specifications Table 6 lists the pin assignments for the console port for both the Data Terminal Equipment (DTE) and DCE settings. Table 6 Pin assignments: 8660 SDM console port Connector Pin number Switch position DCE (left) DTE (right) -
Page 71: Index
Index Numbers SDM 28, 37 8660 SDM description 19 installing and replacing 31 maintenance port described 25 Management port 69 chassis configuration requirements 27 dedicated slots 27 pin assignments connectors Console port 70 DB-9 69 Ethernet Management port 69 RJ-45 69... - Page 72 72 Index technical publications 16 text conventions 15 for technical documentation 16 217314-B Rev 00...
