Tip the filter housing and remove the filter cover to drain the fluid into an approved container. Dispose of the fuel according to
local regulations.
Fuel Filter Inspection
The fuel filter is an important component in the fuel delivery system and should be inspected for debris or degradation every
100 hours of operation. Replace the fuel filter when necessary.
Filter Housing Installation
1.
Place the filter housing mounting tabs into the slots on the bracket and push down on the filter housing to slide the
mounting tabs into the lock position.
2.
Lubricate the filter O‑ring seals with clean oil.
3.
Install the filter and tighten the cover securely.
4.
Install the red service cap.
5.
Connect the battery cables.
6.
Turn the ignition key to the ON or RUN position. Do not start the engine.
7.
Inspect the filter housing and hoses for leaking fuel.
IMPORTANT: Inspect for leaking fuel before starting the engine.
Battery
Refer to specific instructions and warnings accompanying your battery. If this information is not available, observe the following
precautions when handling a battery.
Recharging a weak battery in the boat, or using jumper cables and a booster battery to start the engine, can cause serious
injury or product damage from fire or explosion. Remove the battery from the boat and recharge in a ventilated area away
from sparks or flames.
An operating or charging battery produces gas that can ignite and explode, spraying out sulfuric acid, which can cause
severe burns. Ventilate the area around the battery and wear protective equipment when handling or servicing batteries.
Multiple EFI Engine Battery Precautions
Alternators: Alternators are designed to charge the battery that supplies electrical power to the engine that the alternator is
mounted on. When batteries for two different engines are connected, one alternator will supply all of the charging current for
both batteries. Normally, the other engine's alternator will not be required to supply any charging current.
EFI electronic control module (ECM): The ECM requires a stable voltage source. During multiple engine operation, an
onboard electrical device may cause a sudden drain of voltage at the engine's battery. The voltage may go below the ECMs
minimum required voltage. Also, the alternator on the other engine may now start charging. This could cause a voltage spike in
the engine's electrical system.
In either case, the ECM could shut off. When the voltage returns to the range that the ECM requires, the ECM will reset itself,
and the engine will operate normally. The ECM shuts off and resets itself so quickly that the engine may only seem to have an
ignition miss.
Batteries: Boats with multiengine EFI power packages require each engine be connected to its own battery. This ensures that
the engine's ECM has a stable voltage source.
90-8M0099741
JUNE 2015
eng
58367
WARNING
!
WARNING
!
Section 5 - Maintenance
Page 61
