Peimar PSI-3400TLM Installation Manual

Monophase inverter
Hide thumbs
Table of Contents

Advertisement

Quick Links

MONOPHASE INVERTER
INVERTER MONOFASE
PSI-3400TLM
PSI-4500TLM
1
PSI-5200TLM
PSI-6000TLM
EN / IT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PSI-3400TLM and is the answer not in the manual?

Questions and answers

Related Manuals for Peimar PSI-3400TLM

Summary of Contents for Peimar PSI-3400TLM

  • Page 1 EN / IT MONOPHASE INVERTER INVERTER MONOFASE PSI-3400TLM PSI-5200TLM PSI-4500TLM PSI-6000TLM...

  • Page 3: Table Of Contents

    Table of Contents About this Installation Guide ..2 AC- and DC-Connection ....17 Safety Symbols....... 3 Starting the Inverter ...... 21 General Safety Requirements ..4 Commissioning ......22 Intended Use ........5 Inverter Configuration ....24 Inverter Function......8 Parallel Connection of PV-Ports ...

  • Page 4: About This Installation Guide

    Gruppo di destinazione: Fornitore Azienda da cui è stato Tecnici qualificati acquistato il prodotto Inverter Inverter fotovoltaico PSI PEIMAR descritto nelle presenti istruzioni per l’uso PSI-5200TLM Max. DC-Power 5200 W Max. AC-Power 5000 W PSI-6000TLM Max. DC-Power 6000 W...

  • Page 5: Safety Symbols

    Safety Symbols Life threatening voltages are Countermeasures that must processed inside the inverter. be taken in order to avoid the Hazardous situations that can lead to hazardous situation are indicated with death or serious injuries are indicated an arrow: with the “WARNING” symbol (1) on Î...

  • Page 6: General Safety Requirements

    General Safety Requirements 1. WARNING! Danger of electric 4. 2 people are required for shock! lifting and transporting. Î Read Installation Guide WARNING! Danger of electric carefully. Follow all shock and fire! instructions. Î Never modify the inverter except 2. Contact your supplier when you instructed otherwise by the have questions.

  • Page 7: Intended Use

    Intended Use The inverter (1) converts DC-power CAUTION! Risk of damaging from the PV-generator (2) to AC- the inverter! power. The AC-power is fed into the Î Do not connect other DC-power grid (3). In case of a grid failure: The sources (6) such as wind power inverter automatically disconnects systems, hydroelectric generators,...
  • Page 8 Electrical Safety 1. WARNING! Risk of electric 2. The inverter is not shock! The PV-panels emit a equipped with an internal dangerous DC-voltage when isolation transformer exposed to sunlight. 3. Local regulations and standards can require that an isolation transformer is additionally installed.
  • Page 9 DC-Disconnect / RCD 1. Local regulations and standards 2. The inverter is equipped can require that current-breakers with an integrated RCMU are installed on the DC-side. Type B (tested according to EN Contact your utility operator if you 62109-2 / IEC 60755). If local have questions.

  • Page 10: Inverter Function

    Inverter Function 1. DC-side surge voltage protection 10. Ethernet interface 2. DC-side insulation monitoring 11. SD card slot 3. DC-side disconnection switch 12. WiFi or RS485 interface. 4. Display, status LEDs, buttons Note: The inverter is equipped 5. AC-side disconnection relay with either WiFi or RS485 6.

  • Page 11: Labels And Markings On The Inverter

    Labels and Markings on the Inverter Type Label: Bottom of Inverter: General Symbols 7. DC connection area 1. Ensure proper disposal 8. Ethernet / RS485 2. CE-mark 9. Wifi-antenna Safety Symbols 10. Digital I/O connection 3. Read documentation! 11. AC-plug 4.

  • Page 12: Connections On The Inverter

    Connections on the Inverter 1. PV-plugs 2. Socket for RS485-cable 3. Socket for ethernet cable 4. Wifi-antenna 5. Opening for digital input and digital output 6. AC-cable plug 7. Connection points for additional PE-cable Collegamenti con l’inverter 1. Connettore FV 2.

  • Page 13: User Interface

    User Interface 1. Green LED (“Normal”): 4. OK-Key - On = Normal operation; Press OK-key in order to - Flashing = Waiting, checking or confirm entry. 5. Cursor-Keys: starting up; Press the cursor keys to navigate - Off = Possible failure. the menu and to increase or 2.

  • Page 14: Unpacking

    Unpacking Proceed as follows: 4. Check the items for visible 1. Check the packaging for damages. damages. 5. Contact your supplier when 2. Contact your supplier in case items are missing or the inverter packaging is damaged. is damaged. Do not install a 3.
  • Page 15 Required Tools The following tools are required for the installation of the inverter: 1. Cable stripping tool for cables (e.g. PV-AZM) 2. Drill 3. Multimeter 4. Hex key 5. Pencil 6. Screwdriver 7. Hammer 8. Level Strumenti Necessari Per installare l’inverter sono necessari i seguenti strumenti: 1.

  • Page 16: Mounting The Inverter

    Mounting the Inverter Requirements for the installation 3. Hang inverter on wall location are specified on the following mounting bracket. pages. 4. Check correct position. Proceed as follows: 5. Optional: Secure the inverter with 1. On plasterboard walls: Use center a padlock or screw.
  • Page 17 min. 30 cm min. 30 cm Standard 11-04-03 10 12:17 Today 14.6 hours minutes Total 52.7 hours Normal 15.21 kw 14.60 kw 49.99 Hz < > to Main Menu min. 17.5 cm 30 cm 38.0 cm 18.5 cm 18.0 cm 6 mm Standard Today...
  • Page 18 < 25 ° < +45 °C > +45 °C > -20 °C < -20 °C < 95 % > 95 %...

  • Page 19: Ac- And Dc-Connection

    AC-Connection - Requirements 1. Use suitable circuit breaker. 4. Observe values for wire 2. WARNING! Risk of fire! sizes. Î Do not connect any consumers 5. In France: Use a PE-connection with a minimum cross section to the AC-line. 3. Recommendation: Keep of 6 or 16 mm cable losses below 1 %.
  • Page 20 Connection of the AC Cable WARNING! Risk of electric shock! 5. Remove swivel nut and Î Deactivate AC-voltage when shove swivel nut over the connecting the AC-cable. cable. Proceed as follows: 6. Attach wires to AC-terminal. 0 V ? 1. Disconnect voltage. 7.
  • Page 21 DC-Connection - Requirements 1. CAUTION! Risk of damaging the 4. The DC-ports can be connected: inverter! Install diodes in order to avoid Î Ensure that the voltage and reverse currents. < 550 current is below the specified 5. Cover PV-modules when working values.
  • Page 22 PV Connection (PV Plugs) WARNING! Risk of electric shock! 5. Insert plug contact to the 6 - 7.5 mm Î Cover PV-modules when working plug. Pull on contact in on the connection cables. order to check that the contact is Proceed as follows: locked in the plug.

  • Page 23: Starting The Inverter

    Starting the Inverter Before starting: Proceed as follows for starting: • Make sure DC-switch is “OFF”. 1. Connect AC-plug. • Make sure AC-switch is “OFF. 2. Connect DC-plugs. • Make sure DC plugs are 3. Turn DC-switch to “ON”. connected. 4.

  • Page 24: Commissioning

    Commissioning After connecting to AC and DC • Specify Date and Time. - - - Date/Time power the inverter presents the • Press OK to confirm. screen on the left. YYYY • Press OK to start 2 0 1 6 commissioning.

  • Page 25: Messa In Funzione

    Messa in funzione Dopo il collegamento del lato AC e • Inserire data e ora. - - - Data/ora DC, l’inverter presenta la finestra • Premere OK per confermare. a sinistra. AAAA • Premere OK per avviare la 2 0 1 6 messa in funzione.

  • Page 26: Inverter Configuration

    Additional Inverter Configuration Use the PSI Browser for configuration. Any modification may only The inverters are connected to a PC be done in compliance with (3) with ethernet (1) or WiFi. A router the utility operator! (2) can be used in order to connect several inverters via ethernet.

  • Page 27: Parallel Connection Of Pv-Ports

    Parallel Connection of PV-Ports 1. It is possible to connect the two input ports in parallel. 2. Install diodes in order to prevent reverse currents. 3. When the ports are connected in parallel: Set the input mode of the inverter from “Independent” to “Parallel”.

  • Page 28: Opening The Inverter

    Opening the Inverter Proceed as follows: 4. WARNING! Danger of 1. Ensure that no water will enter electric shock! when the inverter is open. Î Wait for 5 minutes in order to 2. Disconnect AC-power. Disconnect let internal voltages discharge AC-plug.

  • Page 29: Sd Card / Digital Input / Digital Output

    Connections Inside Inverter The inverter is equipped with the Schematic diagrams of following interfaces: examples for the connection 1. SD-card memory port: For are available on the following pages. extension of the inverter memory and storage of yield data. WARNING! Risk of electric shock! 2.
  • Page 30 Digital Input Ports The inverter is equipped with 4 digital input ports (1). The digital input ports DI1 - DI4 can be used for the connection of a ripple control receiver (2). Ingressi digitali L’inverter è dotato di 4 ingressi digitali (1).
  • Page 31 Digital Output The inverter is equipped with 1 digital output port (relay) (1). The usage is possible with future firmware versions. Uscita digitale L’inverter è dotato di 1 uscita digitale (relè) (1) che può essere utilizzata con versioni di firmware successive.
  • Page 32 Ethernet / RS485 Connection Ethernet: Ethernet Connection RS485 Connection 1. Remove socket cap. Note: RS485 communication is 2. Insert the cable in cable gland optional. 3. Plug the cable into socket. 1. Remove socket caps. 2. Insert the cable in the cable glands.
  • Page 36 PSI-3_4-6_0KTL-IG_10_IT Art. No.: 614-04034-00...

This manual is also suitable for:

Psi-4500tlmPsi-5200tlmPsi-6000tlm
