Summary of Contents for Peimar PSI-X1P800-MIC
- Page 1 PSI-X1P800-MIC PSI-X1P1000-MIC MICRO-INVERTER Installation manual...
- Page 2 Il est important de souligner que toutes les spécifications techniques, les informations et les chiffres figurant dans cette fiche technique sont des valeurs estimées. Peimar se réserve le droit de modifier les spécifications techniques, les informations et les chiffres contenus dans ce document à tout moment et sans préavis.
-
Page 4: Table Of Contents
Safety ...................6 1.1. General Safety ..................6 1.2. Safety Instructions of PV, Inverter and Grid ..........7 1.2.1. Safety Instructions of PV .............7 1.2.2. Safety Instructions of Microinverter ..........7 1.2.3. Safety Instructions of Utility Grid ..........9 1.2.4. Inverter backfeed current onto the array ........9 1.2.5. - Page 5 Installation .................21 4.1. Accessories ....................21 4.2. Microinverter Installation ................22 4.3. Microinverter System Initiating ..............33 4.3.1. Initiate the System ..............33 4.3.2. Setup Monitoring System ............34 Troubleshooting and Maintenance ..........40 5.1. LED Indicator Status ................40 5.2. Troubleshooting ..................41 5.3. On-Site Inspection (for qualified installer only) ........42 5.4.
-
Page 6: Safety
The safety instructions in this document serve as supplementary guidelines to local laws and regulations. Peimar shall not be liable for any consequences resulting from the violation of the storage, transportation, installation, and operation regulations outlined in this document. -
Page 7: Safety Instructions Of Pv, Inverter And Grid
1. If the equipment runs abnormally, do not use it by force. Otherwise, electric shock or fire may occur. 2. Do not open the enclosure in any case without authorization from Peimar. Unauthorized opening will void the warranty and cause lethal danger or serious injury due to electric shock. - Page 8 4. Authorized service personnel must use insulated tools and wear protective equipment when installing or working with this equipment. 5. Keep away from flammable, explosive materials to avoid fire disaster. 6. Risk of high-voltage and hot surface! Ensure the device are within the limit of safe voltage potential and temperature before touching any part of the microinverter.
-
Page 9: Safety Instructions Of Utility Grid
ATTENTION 1. Children should be supervised to ensure that they do not play with the appliance. NOTICE 1. Before installing and maintaining the equipment, please read the User Manual and Installation Guide. 2. Comply with local safety rules and regulations before all electrical installations 3. -
Page 10: Safety Instructions Of Ac Trunk Cable
1.2.5. Safety Instructions of AC trunk cable DANGER 1. Avoid installing the AC trunk cable connnectors while power is connected. AVERTISSEMENT 1 Check if the AC trunk cable conductors are not damaged. Only when the exposed wires are not damaged, the system can function properly. 2. -
Page 11: Product Overview
Product Overview 2.1. Microinverter System Description A microinverter system is composed of PV grid-connnected microinverters, PV modules, and grid. Microinverter data are transmitted to Peimar monitoring platform Peimar Portal. Modules photovoltaïques X1P-MIC Router Peimar Portal X1P-MIC The X1P-MIC manages system energy. Microinverters convert the direct current power generated from the PV modules into grid-compatible AC current. -
Page 12: Highlights
Peimar X Portal is an intelligent, multifunctional monitoring platform that can be accessed either remotely or through a hard wired connection. With the Peimar Cloud, the operators and installers can always view key and up-to-date data and set it remotely. -
Page 13: Appearance
2.3. Appearance 2.3.1. Overview 2.3.2. Dimensions 260 mm 40 mm... -
Page 14: Terminals Of Microinverter
2.3.3. Terminals of Microinverter Spare ground For standby earth connection cable clip PV terminal For PV connection. Indicator Show the status of the device. Antenna To receive and transmit Wi-Fi signal. AC terminal For AC connection. A connection component for electrical devices which need grounding (perferred Earth lug grounding method). -
Page 15: Symbols On The Label And Microinverter
2.3.4. Symbols on the Label and Microinverter CE MARK The microinverter complies with the requirementsof the applicable CE guidelines. BEWARE OF HOT SURFACE The microinverter can become hot during operation. Avoid contact during operatior. DANGEROUS ELECTRIC VOLTAGE Danger to life due to high voltages in the Microinverter! WARNING, DANGER! Risk of electric shock! DANGER TO LIFE due to high voltage! -
Page 16: Preparation Before Installation
Preparation before Installation 3.1. Unpacking and Inspection 3.1.1. Unpacking The microinverter undergoes 100% testing and inspection before shipping from the manufacturing facility. However, transport damage may still occur. Before unpacking the Microinverter , please verify that the model and outer packing materials for damage, such as holes and cracks. -
Page 17: Selection Of Installation Location
Sold separately: Specifications Quantity AC trunk end cap AC trunk connector AC trunk port disconnect tool 1.2 m / 2 m / 2.4 m AC trunk cable AC end cable-M Male connector Female connector DC extension cable * Refer to the actual delivery for the optional accessories. 3.3. - Page 18 -40°C-+65°C 0-100%RH NOTICE For outdoor-installation, precautions against direct-sunlight, rain -exposure and snow- accumulation are-recommended. Exposure to direct sunlight raises the temperature inside the device. This temperature rise poses no safety risks,but-may impact the device performance.
-
Page 19: Installation Angel Requirement
3.3.2. Installation Angel Requirement NOTICE Install the microinverter on the bracket. Make sure the bracket is parallel with the rail. Parallel to the rail 3.4. Tools Requirement 3.4.1. Recommended Equipment Installation tools include but are not limited to the following recommended ones. If necessary, use other auxiliary tools on site. -
Page 20: Recommended Equipment
3.4.2. Recommended Equipment AC circuit Current: 50A for 10 AWG/40 A for 12 AWG (If there are additional safety breaker regulations, please refer to the local safety regulations) Guide rail According to actual needs Sliding block Matching with the guide rail Screw Matching with the guide rail AC cable... -
Page 21: Installation
Installation 4.1. Accessories... -
Page 22: Microinverter Installation
PSI-XMIC-CAB240AC-10 PSI-XMIC-CAB200AC-10 1.2 m / 2 m / 2.4 m AC trunk cable. PSI-XMIC-CAB160AC-10 PSI-XMIC-CAB120AC-10 DC extension cable (if necessary) PSI-XMIC-CONN-TAC AC trunk connector PSI-XMIC-ENDCAP AC trunk end cap PSI-XMIC-DISCTOOL AC trunk port disconnect tool PSI-XMIC-CONN-FAC Female connector PSI-XMIC-CONN-MAC Male connector PSI-XMIC-CABM500AC-10 AC end cable-M NOTICE... -
Page 23: Rail Installation
WARNING, DANGER! Pay attention to the earth lug. Risk of hand injury! Rail Installation 1) The installer has to install the rails on the roof and fix them with screws to ensure a stable installation environment for microinverters. Plan the Number and Installation Location of Microinverters 1) Arrange the installation number and location of each microinverter according to the layout of the photovoltaic system. - Page 24 Install the Microinverter on the Rail 1) Place the sliding bolcks and screws on the maked place of the rail. 2) Hang on microinverters. The sliver cover side with performance lable of the microinverter shall be placed upwards. 3) Tighten the screws. 9±0.1 N·m NOTICE Choose the screwdriver according to the corresponding screws of the rail.
- Page 25 b) Plug the male terminal of AC trunk cable into the female terminal of AC trunk connector. AC trunk cable Female Male c) Band the AC trunk cable with cable ties. In order to better fix the AC cable, it is recommended to use more cable ties to band the AC cable.
- Page 26 NOTICE When connecting AC cables in the middle, please follow the diagram below. e) Cover vacant AC ports with AC trunk end cap. Male NOTICE The male head of the AC trunk connector connected to the first microinverter needs to be connected with the AC Trunk End Cap.
-
Page 27: Complete The Installation Map
NOTICE Avoid placing AC connectors nearby any drainage channels. If you need to disconnect the AC connector from the AC cable, use the AC Trunk Port Disconnect Tool (see packing list). Complete the Installation Map a) Remove the serial number label on the machine and attach to the installation map following the planed installation place. - Page 28 We provide two grounding methods for this series of microinverters. If the earth lug doesn't touch the rail or the rail is not on the ground, please try method 2. Method 1 (major grounding method) Let the earth lug touch the rail. Method 2 Strip the PE cable, place the PE cable on the rail and fix it with screws 1.2 ±...
- Page 29 Connect Multiple PV Modules to Microinverter NOTICE At least two or three trained and experienced workers are required to finish this step. WARNING, DANGER! Please connect PV terminals in the correct way. Reverse connection may damage the microinverter! a) One or two workers hold the PV pannel nearby microinverter, while the other one connects PV terminals of each microinverter to the corresponding DC cable of PV module.
- Page 30 b) Cover the PV modules above the microinverters and fix the PV panels. c) Insert the AC end cable-M to the last female connector of the AC trunk connector, and connect the other end of AC end cable-M to the distribution box (L, N and PE cables must be connected accordingly).
- Page 31 NOTICE The length of AC end cable shall depends on the actual installation scence. NOTICE If you didn't buy AC end cable-M, please follow the procedures below to make the wire before connecting to the distribution box. Please use 4-6 mm2 three core soft wire cable. Single core hard wire cable cannot be used in the following steps.
- Page 32 g) Thread part I, part II and part III into the AC end cable-M. Thread L, N and PE cables into the corresponding hole of part IV. Screw down part IV with part I. h) Insert the AC end cable-M to the last female connector of the AC trunk connector, and connect the other end of AC end cable-M to the distribution box (L, N and PE cables must be connected accordingly).
-
Page 33: Microinverter System Initiating
4.3. Microinverter System Initiating 4.3.1. Initiate the System Checking before Power-on • Check the device installed correctly and securely; • All AC cables are connected correctly and securely; • All DC cables are connected correctly and securely; • Make sure all photovoltaic panels are connected correctly and securely; •... -
Page 34: Setup Monitoring System
Scan the QR code to download the monitoring app. App Store Google Play Store Peimar X Portal Step 2: Create an Account Click on [Sign Up] to create an account, fill in your information, and then log in to your account. - Page 35 Step 3: Create a Site Click on [+] in the main interface, then fill in the corresponding information to create your site. NOTICE The app registration through creating a new account is intended for end users. If you wish to request an agent account, please contact technical support.
- Page 36 Step 4: Add device Following the previous step, you will enter the [Add Device] interface. Input the QR code on the device, and then click [Add Device]. NOTICE If scanning the QR code step fails,.then try to scan the one dimensional code. Scanning one dimensional code may lead to inaccurate scan results).
- Page 37 Step 5: Wi-Fi Setup In this step, you will start to configurate Wi-Fi. NOTICE If the Wi-Fi configuration fails, please refer to the PSI-X-H-WIFI-3.0 installation manual for troubleshooting.
- Page 38 Step 6: Verify Layout Information After the Wi-Fi configuration, click on [Layout] in the [Power Station Detail] interface and select [Edit now].
- Page 39 Step 7: Customize the layout of the components Select the corresponding device to customize the component layout and then [Save] the settings. Afterwards, users can view the power and connection status of each component, and check the total power at the bottom. NOTICE Layout feature is available after WiFi configuration succeeds, please ensure that Wi-Fi is configurated successfully before check layout information.
-
Page 40: Troubleshooting And Maintenance
Troubleshooting and Maintenance 5.1. LED Indicator Status LED Indicator Status Description Microinverter startup. If the light flashes once in 1s, Yellow light flash flashes in 10s or still flashes after 10s, microinverter startup fails or DSP firmware is upgrading. Yellow light steady on Microinverter standby/self-checking. -
Page 41: Troubleshooting
Please check the warning or fault information on the App and read the suggested solutions below when error occurs. Contact Peimar Assistance for further assistance. Please be prepared to describe the details of your system installation and provide the model and serial number of the Microinverter. -
Page 42: On-Site Inspection (For Qualified Installer Only)
Software Overcurrent Protection Fault. Wait for a while to check if the inverter is back to normal. IE00011 SW OCP Fault Disconnect PV and grid, then reconnect. Or seek help from us. Isolation Fault. IE0013 IsoFault Check the connections of the inverter. Or seek help from us. -
Page 43: Maintenance
More frequent maintenance service is needed in the worse work environment. Please make records of the maintenance. WARNING, DANGER! Only qualified person can perform the maintenance for the Microinverter. Only use the spare parts and accessories approved by Peimar for maintenance. 5.4.1. Maintenance routines Item... -
Page 44: Decommissioning
Use APP to scan or type in the SN of the microinverter to be used. • Make sure the AC breaker is turned off and install the microinverter according to Installation Steps described in this manual. • In Peimar X Portal app, unbind the original microinverter and bind new model... -
Page 45: Packing The Microinverter
6.2. Packing the Microinverter • Load the microinverter into the original packing material if possible. • If the original packing material is not available, you can also use the packing material which meets the following requirements: • Suitable for the weight of product. •... -
Page 46: Technical Data
Technical Data DC Input PSI-X1P800-MIC PSI-X1P1000-MIC Max. recommended DC power 320-540 W 400 - 670 W Max. PV voltage 60 V MPPT voltage range 22 - 60 V Nominal input voltage 33 V Max. PV current 2 x 15 A... - Page 47 Efficiency, Safety and Protection MPPT efficiency 99.9 % Maximum efficiency 96.5 % Protection class CA: I; CC: II/III Ingress protection rating IP67 Noise emission(typical) < 25 dB Operating temperature range -40 ~ 65 °C (> 45 Derating) Humidity 0 ~ 100 % Storage temperature -40 ~ 65 °C Generic Data Dimensions (W/H/D)
-
Page 48: Wiring Diagram
Wiring diagram 8.1 230 V AC Single phase Refer to Technical Data for the number of microinverters per AC branch Phase - L1 Distribution panel Ground 8.2 120 V / 240 V AC Split phase Refer to Technical Data for the number of microinverters per AC branch circuit Phase - L1 &... -
Page 49: 230 V / 400 V Ac Three-Phase
8.3 230 V / 400 V AC Three-Phase Refer to Technical Data for the number of microinverters per AC branch circuit Phase - L1 Refer to Technical Data for the Distribution number of microinverters panel per AC branch circuit Ground Phase - L2 Refer to Technical Data for the number of microinverters per... -
Page 50: 120 V / 208 V Ac Three-Phase
8.4 120 V / 208 V AC Three-Phase Refer to Technical Data for the number of microinverters per AC branch circuit Phase - L1 & L2 Refer to Technical Data for the Distribution number of microinverters per panel AC branch circuit Ground Phase - L1 &... - Page 52 | www.peimar.com Version: 2025_02_00...
