- Page 1 TEMPERATURE AND PRESSURE GAUGE English Installation and operating guide Temperature And Pressure Gauge...
-
Page 3: Table Of Contents
Instruction Manual TAP / Temperature And Pressure Gauge English Contents Introduction ..................4 General information ................ 6 Important safety notice ..............7 Technical Data ................. 8 Parts description ................9 Transport, packaging and storage ..........13 Setup, operation ................14 Maintenance ................. -
Page 4: Introduction
/ or on your mobile device. - Up to 6 TAP devices can be monitored on your mobile device. - Create report and send by e-mail to your office. - Uses common AAA batteries. - TAP is available in a suitable case either as single or double set. - Page 5 - TAP is available in a suitable case either as single or double set. Instruction Manual TAP / Temperature And Pressure Gauge English CE/FCC Conform CE/FCC Conform CE/FCC Notice This device meets the norm EN300 440. CE/FCC Notice FCC: This device meets the requirements in accordance to part 15 of the F This device meets the norm EN300 440.
-
Page 6: General Information
ISO 9001. The TAP has been developed for long term use. REFCO takes energy The TAP has been developed for long term use. REFCO takes energy sa saving and environmental impact into consideration when procuring environmental impact into consideration when procuring materials and m materials and manufacturing its products. -
Page 7: Important Safety Notice
The TAP must not be used for anything other than the below-stated purposes. Illustration Explanation The TAP should not be exposed to moisture or used in damp or wet environments. Warning: Seriuos physical injury can occur Damage to the equipment may occur Remove refrigerants from the TAP and the hoses after use. -
Page 8: Technical Data
English Instruction Manual TAP / Temperature And Pressure Gauge Technical Data Temperature clamp, TAP-CLAMP Property Value Thermocouple: K-type -40 °C to +125 °C / -40 °F to +257 °F Temperature range: Accuracy of +/- 1 °C / +/- 1.8 °F... -
Page 9: Parts Description
Instruction Manual TAP / Temperature And Pressure Gauge English The TAP can be used with the following refrigerants: R11, R113, R114, R12, R123, R124, R13, R134a, R13B1, R22, R227, R23, R290, R32 R401A(Liq), R401A(Vap), R401B(Liq), R401B(Vap), R402A(Liq), R402A(Vap), R402B(Liq), R402B(Vap), R403B(Liq),... - Page 10 English Instruction Manual TAP / Temperature And Pressure Gauge English Instruction Manual TAP / Temperature And Pressure Gauge Pressure Gauge Pressure Gauge Slider switch Battery case cover Online / Offline LED Indicator light 4 x 1.5 V AAA Display DOWN...
- Page 11 By pressing [ON/OFF] + [UNIT] button same time < 1 sec. the following mode is activated: UNIT - Set number of TAP-CLAMP. Scroll from T1 to T6 by pressing [UNIT] button < 1 sec. (once set, setting remains) By pressing [ON/OFF] + [UNIT] button same time >...
- Page 12 English Instruction Manual TAP / Temperature And Pressure Gauge Buttons and functions on TAP Pressure Gauge ON / OFF Scroll UP Scroll DOWN MENU ON by short pressing < 1 sec. OFF by pressing ≥ 1 sec. ON / OFF - Backlight on - Display shows "OFF"...
-
Page 13: Transport, Packaging And Storage
TAP CLAMP Transport, packaging and storage Transport The TAP is delivered from the factory in a plastic box, with or without different accessories as ordered. Inspect the TAP for any potential transportation damage. Any obvious damage should be reported to the vendor immediately. -
Page 14: Setup, Operation
Ensure the batteries are inserted observing the correct polarities. Do not leave dead batteries in the battery Purpose and use compartment. If you will not be using the TAP CLAMP for a long period of time, remove the batteries from the battery compartment. - Page 15 The TAP must not be used for a TAP Pressure Gauge The TAP should not be expose Set-up TAP Insert 4 x 1.5 V (AAA) batteries in the battery compart- ment on the back side of the TAP. Remove refrigerants from the T Ensure the batteries are inserted observing the correct polarities.
- Page 16 English Instruction Manual TAP / Temperature And Pressure Gauge Set - Press [MENU] button ≥ 1 sec. to activate selection favorites mode. - Press [DOWN] button< 1 sec. to scroll down to the refrigerant menu. - Press [SET] button ≥ 1 sec. to enter refrigerant menu. - Press [UP] or [DOWN] button < 1 sec. to scroll to the desired refrigerant.
- Page 17 If no device can be found, " No Signal" appears on display before return to menu. - If device be found, display shows a list of found TAP CLAMP ID(s). - Select desired TAP CLAMP ID by pressing [UP] or [DOWN] button <...
- Page 18 English Instruction Manual TAP / Temperature And Pressure Gauge Update Updating refrigerants. See in chapter maintenance. Version Current version of refrigerant chart is shown. SD Mode This function is used in combination for update. See in chapter maintenance. P-Zero Resetting pressure sensor.
-
Page 19: Maintenance
Resetting pressure sensor on TAP pressure gauge The TAP must not be used for anything other th The TAP pressure sensor can be reset in order to avoid incorrect mea- surement values. The TAP should not be exposed to moisture or... - Page 20 The accuracy of all measuring devices will degrade over time. Calibration improves the accuracy of the TAP. On this device temperature and pressure can be re-calibrated. bration improves the accuracy of the TAP. On this device temperature...
- Page 21 English Room temperature calibration 1. Turn off the TAP-CLAMP. 2. Place the TAP-CLAMP at constant temperature at 25 ± 3 °C con- dition for 2 hrs. to ensure the temperature of the K – thermocou- ple to be even. 3. While holding [UNIT], press [ON / OFF] until display shows "CALL"...
-
Page 22: Guarantee
English Instruction Manual TAP / Temperature And Pressure Gauge Guarantee Your new TAP has been developed in accordance with the latest oc- cupational health and ergonomic requirements and reflects the latest state-of-the-art technology. REFCO Manufacturing Ltd has been certi- fied in accordance with DIN EN ISO 9001: 2008. Regular quality con- trol checks as well as an accurate manufacturing process guarantee... - Page 23 Instruction Manual TAP / Temperature And Pressure Gauge English...
- Page 24 English Instruction Manual TAP / Temperature And Pressure Gauge REFCO Manufacturing Ltd. Industriestrasse 11 6285 Hitzkirch - Switzerland Telefon +41 41 919 72 82 Telefax +41 41 919 72 83 info@refco.ch www.refco.ch...
