5.5
ESD Notes
SIM7000 is sensitive to ESD in the process of storage, transporting, and assembling. When
SIM7000 is mounted on the users' mother board, the ESD components should be placed beside the
connectors which human body may touch, such as SIM card holder, audio jacks, switches, keys, etc.
The following table shows the SIM7000 ESD measurement performance without any external ESD
component.
Table 34: The ESD performance measurement table (Temperature: 25℃, Humidity: 45%.)
Part
VBAT,GND
Antenna port
Other PADs
Contact discharge
+/-6K
+/-5K
+/-1K
Air discharge
+/-12K
+/-10K
+/-3K
