Table 15: PCM timing parameters
Parameter Description
T(sync) PCM_SYNC cycle time
T(synch) PCM_SYNC high level time
T(syncl) PCM_SYNC low level time
T(clk) PCM_CLK cycle time
T(clkh) PCM_CLK high level time
T(clkl) PCM_CLK low level time
PCM_SYNC setup time high before falling edge
T(susync)
of PCM_CLK
PCM_SYNC hold time after falling edge of
T(hsync)
PCM_CLK
PCM_IN setup time before falling edge of
T(sudin)
PCM_CLK
PCM_IN hold time after falling edge of
T(hdin)
PCM_CLK
T(pdout) Delay from PCM_CLK rising to PCM_OUT valid
Delay from PCM_CLK falling to PCM_OUT
T(zdout)
HIGH-Z
SIM7000 _Hardware Design _V1.04
Figure 21: Module to external codec timing
Smart Machine Smart Decision
Min. Typ. Max.
– 125 –
– 488 –
– 124.5 –
– 488 –
– 244 –
– 244 –
– 122 –
– 366 –
60 – –
60 – –
– – 60
– – 60
2018-1-31
Unit
μs
ns
μs
ns
ns
ns
ns
ns
ns
ns
ns
ns
