7
Technical specifications
Input connections
Output connections
Channel fuse
DPX-1210H NET
(Item no. 469657)
Voltage supply
Terminals
(3-phase connection, 400 V, 32 A max. per phase)
Signal input
1 × DMX 512 via 3-pin XLR socket
1 × DMX 512 via 5-pin XLR socket
1 × Art-Net via RJ45 socket
Voltage supply
2 × Harting industrial connectors,
16-pin
Signal output
1 × DMX 512 via 3-pin XLR socket
1 × DMX 512 via 5-pin XLR socket
Single-phase
1 × circuit breaker per channel, each 10 A, 96 A max.
Three-phase
1 × circuit breaker per channel, each 10 A, 32 A max.
Technical specifications
DPX-1210S NET
(Item no. 469658)
12 × safety sockets with hinged lid
DPX-1210H NET DPX-1210S NET
dimmer pack
45
