Operating
Setting the dimmer curve
DPX-1210H NET DPX-1210S NET
30
dimmer pack
1. Press [MENU] to activate the main menu.
2.
Press or repeatedly until the 'LOCAL CONTROL' submenu appears on the display
and activate the submenu with [ENTER].
ð The set dimmer channel flashes.
3.
Press to move the cursor to the number of the dimmer channel (display shows 'LIVE
123456789012' ) whose parameters you want to change.
4.
Press or repeatedly until the display shows the desired value for the selected
dimmer channel.
5. Press [ESC] to exit the menu and return to display mode.
ð The set value is applied.
Menu level 1
'CURVES'
Menu level 2
'Linear'
'Square'
'NO-DIM'
Function
A linear dimmer curve is set.
A square dimmer curve is set.
Switch mode is activated. The
output power is 0% or 100%.
