6.2 DMX and Art-Net settings

Setting the DMX address
Menu level 1 Menu level 2
'ADDRESS' 'DMX-512A'
'ArtNET'
The DMX start address is set and assigned to a channel via the 'ADDRESS' menu.
1.
Press [MENU] to activate the main menu.
2.
Press or repeatedly until the 'ADDRESS' submenu is shown on the display.
3.
Press to select the 'DMX-512A' submenu and confirm with [ENTER].
Menu level 3 Function
'Start:001...512'
Sets the DMX start
address.
'Patch:01... Selects the channel
12>>001...512' for which the start
address is being set.
'SubNET:001...255' Sets the ArtNET
address for a SubNET.
'Universe:001...255' Sets the ArtNET
address for an ArtNET
universe.
