- Page 1 SWIT ELECTRONICS CO., LTD. Model： FLOW2000 3GSDI&HDMI 600m Wireless HD transmission User Manual Please read this user manual throughout before using Ver： A...
- Page 2 All brands and trademarks of SWIT Electronics Co., Ltd. are protected and other relative trademarks in this user manual are the property of their respective owners. Due to constant effort of product development, SWIT reserves the right to make changes and improvements to the product described in this manual without prior notice.
-
Page 3: Safety Precautions
Safety Precautions Please follow the safety precautions before using. The following conditions are not covered by warranty. 1. Unauthorized repairs or other Unauthorized operations. 2. Inappropriate placement including but not limited to lighting, fire, exposure to rain, water or gas. 3. - Page 4 1. Product Introduction FLOW2000 includes transmitter and receiver, adopts the latest encrypted transmission technology, Supports SDI and HDMI wirelessly transmitted in 600 meters scale (Line-of-Sight), 2 channels SDI/HDMI digital video transmission, auto pairing and OLED display. FLOW2000 is equipped with DC power connector, compact size, portable, and the receiving signal is very stable.
- Page 5 ⑼ USB： Micro USB, software upgrade interface ⑽ HDMI in： HDMI input (HDMI-A type connector) ⑾ Battery plate： “ F ” plates can be used. We recommend SWIT batteries like: S-8972, S-8970, S-8770,S-8975 compatible with SONY “L” series NP-F770/970. ⑿ SDI LOOP： SDI Loop out (BNC connector) ⒀...
- Page 6 ⑾ HDMI OUT: HDMI output (HDMI-A type connector) ⑿ SDI out: SDI output (BNC connector) ⒀ Battery plate： “ F ” plates can be used. We recommend SWIT batteries like: S-8972, S-8970, S-8770, S-8975 compatible with SONY “ L” series NP-F770/970.
- Page 7 4. OLED Display Boot Screen Main Screen （When Tx and Rx both have no signal connection, (When Tx and Rx have normal signal connection, Tx and Rx display the same. Fig.1) Tx and Rx display the same. Fig.2) Signal source No Signal Signal format Auto channel mode...
- Page 8 5. Setup connection ⑴ Connect the SDI in/HDMI in interface of the FLOW2000 transmitter to the SDI out/HDMI out of the camera or video output device. ⑵ Connect the SDI out/HDMI out interface of the FLOW2000 receiver to the SDI in/HDMI in of the monitor or switch station.
- Page 9 7. The way to get the best effective of Wireless Transmission ⑴ Set the antenna on both transmitter and receiver vertically straight up, no request to spread. If installed flat, still keep the antenna vertically straight up to extend transmission distance and stabilize transmission quality.
-
Page 10: Troubleshooting
8. Trouble shooting If the receiver failed to output video correctly, the possible causes are as below; please find the solution from following chart: The receiving Possible causes Solution video Check power connection and switch on The transmitter receiver is the transmitter and receiver not powered on Install the antennas properly and screw...
