- Page 1 Model: S-4904T/R Wireless HD Transmission System User Manual Please read this User Manual throughout before using.
- Page 2 All internal technologies of this product are protected, including device, software and trademark. Reproduction in whole or in part without written permission is prohibited. ． All brands and trademarks of SWIT Electronics Co., Ltd. are protected and other relative trademarks in this user manual are the property of their respective owners. ．...
-
Page 3: For Your Safety
For Your Safety Before start, please follow the safety precautions below Do not try the followings: 1. Unauthorized repairs or parts replacement or other operations. 2. Inappropriate placement including but not limited to lighting, fire, exposure to rain, water or gas. 3. -
Page 4: Product Introduction
Support AES 128-bit encryption to protect the transmission. Battery plate optional ◆ ◆ ◆ ◆ User can choose Gold mount or V-lock mount for the transmitter S-4904T and receiver S-4904R . ◆ ◆ ◆ ◆ All-Metal Shell Both the transmitter and receiver adopt metal shell which is durable and solid. -
Page 5: Product Instruction
3. Product Instruction Transmitter S-4904T Front view Rear view LED status indicators: ⑴ 、 ⑵ Including Power, Video Signal and Wireless connection condition indicators Wireless frequency dial switch ⑶ Set frequency range from 0 ～ 9 , in total 10 channels SDI in: 3G/HD/SD-SDI input (BNC connector) ⑷... - Page 6 Receiver S-4904R Front view Rear view Antenna ⑴ Power installer: V-mount or Gold mount lock for optional. To power through the same battery mounted on ⑵ the monitor. ⑶ 1/4”-20 threaded hole. W ireless received signal strength indicator ⑷ RSSI ：...
-
Page 7: Build Connection
When S-4904R detect the recognizable video signal, ”Video”indicator will light and OSD will dispappear. Remark: S-4904T support SDI input and HDMI input, and it will automatically detect the connected signal input. If both SDI and HDMI are connected, S-4904T will give priority to transmit SDI signal. - Page 8 6. How to get the best effect of wireless transmission ⑴ Set the antennas of S-4904T and S-4904R as below Fig2 and Fig 3 to extend the transmission distance and achieve stable transmission quality. Fig2 Fig3 Set the receiver S-4904R as high as possible like Fig 4.
-
Page 9: Optional Battery Plate
S-4904R provides V-mount or Gold mount two-sided plates for installing between monitor and battery,so that the battery can power the monitor and S-4904R simultaneously. Gold mount V-mount Note: The battery plates are fixed on S-4904T and S-4904R at factory, please specify the suitable plate type before purchase. -
Page 10: Troubleshooting
The transmission distance is out of Try the wireless transmission at a closer effective range or being interfered by distance or clean out the obstacles obstacles. 9. Specifications Model Transmitter S-4904T Receiver S-4904R Input 3G/HD/SD-SDI × 1 , HDMI ×... -
Page 11: Packing List
10. Packing List Transmitter S-4904T × Receiver S-4904R × Antenna × Articulating arm trestle Crab clamps D-tap to 5.5/2.1mm pole cable × 1 × 1 × 5.5/2.1mm pole power adaptor × Power cable × Flat Screwdriver × Warranty card ×... - Page 12 Product Registration Link...
