- Page 1 CEV.FR SWIT ELECTRONICS CO., LTD Model: S-4904P （ Wireless HD Transmission System with Panel Receiver） User Manual Ver:A Please read this User Manual throughout before using...
-
Page 2: Preface
All internal technologies of this product are protected, including device, software and trademark. Reproduction in whole or in part without written permission is prohibited. ． All brands and trademarks of SWIT Electronics Co., Ltd. are protected and other relative trademarks in this user manual are the property of their respective owners. ．... -
Page 3: Safety Precautions
For Your Safety Before start, please follow the safety precautions below Do not try the followings: 1. Unauthorized repairs or parts replacement or other operations. 2. Inappropriate placement including but not limited to lighting, fire, exposure to rain, water or gas. 3. -
Page 4: Table Of Contents
Contents Preface ..............................1 Safety Precautions ..........................2 Contents ..............................3 Packing list .............................. 3 Product Introduction ..........................4 Features ..............................4 Product Instruction ..........................5 Transmitter S-4904T ..........................5 Receiver S-4990 ..........................6 Frenquency ............................. 7 Build Connection ............................. 8 Optional battery plate .......................... -
Page 5: Product Introduction
Product introduction This broadcast industry wireless system includes S-4904T transmitter and S-4990 receiver, adopts WHDI (OFDM) technology, supports uncompressed 3G/HD/SD-SDI and HDMI wirelessly transmitted in 1000 meters scale, and with less than 1ms latency, which is widely used in on-site shooting and director monitoring. Features Uncompressed 3G/HD/SD-SDI and HDMI transmission Support up to 1080p 50/60 uncompressed SDI &... -
Page 6: Product Instruction
Product instruction Transmitter S-4904T Front view Rear view ⑴ 、 ⑵ LED status indicators: Including Video Signal and Power indicators ⑶ Wireless frequency dial switch Set frequency range from 0 ～ 9 , in total 10 channels ⑷ SDI in 3G/HD/SD-SDI input (BNC connector) ⑸... -
Page 7: Receiver S-4990
Receiver S-4990 Rear view Handle ⑴ VESA bracket ⑵ Control area: ⑶ RSSI R eceiving signal LED indicator ① ： ② STATUS ： V ideo signal and power status indicator ③ CHANNEL ： D igital display frequency channel ④ Button ：... -
Page 8: Frenquency
Bottom view On/Off Switch the power On/Off ⑴ DC in Support DC 7-36V voltage input, 4-pin lockable LEMO connector ⑵ ⑶ SDI Out SDI output (BNC connector) Frequency Dial Switch 1. Using ONE set of devices under the same environment Dial the frequency switch of both transmitter and receiver to the same channel (transmitter dial number same to receiver digital display number), the default channel number is “0”: S-4904T... -
Page 9: Build Connection
Build connection ⑴ Connect the SDI or HDMI video source with the “SDI IN” / “HDMI IN” port of S-4904T transmitter. ⑵ Connect the “SDI OUT” / “HDMI OUT” port of S-4990 receiver with monitor or other receiving devices. ⑶ Dial the S-4904T and S-4900 to the same frequancy channel. -
Page 10: Accessory
Accessory 1 Supporting carbon fiber monopod Installation instruction 1 、 Snap the monopod installing module on the carrying case mounting block, and screw tightly, see Fig 1. 2 、 I nsert the monopod into the installing module, and clockwise screw tightly, see Fig 2.. Fig 1 Fig 2 Note: The above accessory only included in luxury package. -
Page 11: Trouble Shooting
Trouble shooting If the receiver failed to output video correctly, the possible causes are as below, please find the solution from following chart: receiving Possible causes Solution video Check power connection and switch on the No power transmitter and receiver The antennas are not installed properly and Install the antennas properly and screw tightly screwed tightly...
