Removing the Harness System

1 - Press the harness adjuster buckle and pull the shoulder straps forward to
loosen the harness (Fig.2).
2 - At the back of the seat, remove the shoulder straps from the metal yoke
(Fig.3).
3 - Pull the shoulder straps forward out of the seat (Fig.3).
4 - Remove the tongue's from the shoulder straps, roll the straps up and place
them underneath the cover (Fig.4)
NOTE: Clip the tongues back into the buckle so they do not get lost.
5 - Remove the buckle by lifting up the cover, twisting the buckle bracket
sideways and remove it from the base (Fig.5&6).
To replace the harness system, follow the steps in reverse.
IMPORTANT: Store the harness buckle in a safe place for future use.
