Configuration Overview

Table 3
General specifications:
TB/cabinet
Server:drive ratio
Disk drives
Network
Redundancy
Servers (1U Dell)
3U disk-enclosure DAEs
Gbe switches
10Gbe switches
Cabinet specifications:
Height
Width
Depth
Weight (lbs)
Maximum power (W),
with 1TB 7200 rpm
drives
20 EMC Atmos Hardware Guide
Atmos has three promo-code configurations for deployment. Promo
codes 1 and 3 leverage Dense Storage hardware and rack-enclosure
components. Promo code 5 uses Dense Storage hardware in a
NEMA-standard 40U rack. The promo-code configurations are listed
in Table 3.
Promo Code Configurations
Promo 1
360
1:60
1TB, 7200 rpm
2TB, 5400 rpm
2TB, 7200 rpm
Gbe
PDU, PS, fan
6
24 (12 trays)
1 Allied Telesis 24-port
N/A
82.44"
24"
43"
2,548
10,290
Promo 3
240
1:15
1TB, 7200rpm
2TB, 5400 rpm
2TB, 7200 rpm
Gbe
PDU, PS, fan
16
16 (8 trays)
2 Allied Telesis 24-port
N/A
82.44"
24"
43"
2,282
10,020
Promo 5
120
1:15
1TB, 7200 rpm
2TB, 5400 rpm
2TB, 7200 rpm
Gbe
PDU, PS, fan
8
8
1 Allied Telesis 24-port
N/A
70"
24"
40"
1,356 lbs
4,880
