Summary of Contents for Exmark STANDON Series
- Page 1 STANDON For StandOn Serial Nos. 406,294,345 & Higher (to fit all Turf Tracer and Turf Tracer HP Units 510,000–919,999) (to fit all Turf Tracer X-Series and Turf Tracer S-Series Units 920,000 and Higher) (to fit all Viking Hydro Units 510,000 and Higher) Part No.
- Page 2 State of California to cause cancer, birth defects, or other reproductive harm. Exmark reserves the right to make changes or add improvements to its products at any time without incurring any obligation to make such changes to products manufactured previously.
-
Page 3: Introduction
All Exmark parts are thoroughly tested and inspected before leaving the factory, however, attention is required on your part if you are to obtain the fullest measure of satisfaction and performance. -
Page 4: Table Of Contents
Contents Introduction ............3 Safety ..............5 Safety Alert Symbol ......... 5 General Safety ..........5 Safety and Instructional Decals ....... 6 Specifications ............7 Systems ............7 Dimensions............. 7 Setup ..............8 Operation ..............10 Before Operation ...........10 Pre-Start............10 Operating Instructions ........11 During Operation Safety.........11 After Operation..........11 Transporting ..........11... -
Page 5: Safety
Safety Safety General Safety Exmark designed and tested this accessory to offer Safety Alert Symbol reasonably safe service; however, failure to comply with safety instructions may result in injury or death. This Safety Alert Symbol () is used both in this manual •... -
Page 6: Safety And Instructional Decals
1. Pinch point hazard–Do Not use drawbar to lift StandOn. Only use platform side handles to lift and rotate StandOn. decal126-1400 126-1400 1. Warning-Read the Operator’s manual. Use only Exmark riding attachments. Use of other riding attachments may create a hazardous condition resulting in injury. decal126-1411 126-1411 1. -
Page 7: Specifications
Specifications Specifications Systems Tire Tread Size Semi-Pneumatic Smooth 11 x 4.00-5 For operators over 250 lb (113 kg), it is recommended to use pneumatic tire assembly P/N 103-3798. Dimensions Overall Width: 18.5 inches (47.0 cm) Overall Length: 35.4 inches (89.9 cm) Overall Height: 14.6 inches (37.1 cm) Weight:... -
Page 8: Setup
Setup Setup Item Item Quantity Description Quantity Description Nut, Nyloc 3/8-16 Flg Screw-HH 1/2-13 x 5 Plate, Back-Up Nut-Nyloc 1/2-13 Pin-Lynch Asm-Sulky Frame W/Decals Pin-Pivot Screw, HH 3/8-16 x 1 1/4 Washer–Spring Disc Asm-Mount Plate W/Decals Decals-Replacement (Turf Tracer Asm-Drawbar W/Brgs and Decal and Viking Hydro Only) Cover-Dust... - Page 9 Setup Installing the Mount Plate: plates, and four 3/8-16 inch nyloc nuts as shown in Figure 6. Use Figure 4 to identify the model and correct mounting pattern. If your unit has four holes Note: Backup plates are not used on Turf Tracer drilled in the rear surface of the engine deck, HP models (item 2 in Figure 4).
-
Page 10: Operation
• Do Not modify the StandOn. • Evaluate the terrain to determine what accessories and attachments are needed to properly and safely perform the job. Only use on machines approved by Exmark. • Wear appropriate personal protective equipment such as safety glasses, substantial slip-resistant g192311 footwear, and hearing protection. -
Page 11: Operating Instructions
Operation After Operation For operation of StandOn with Viking Hydro, Turf Tracer S-Series, and Turf Tracer HP on hilly terrain, front weight kit accessory, P/N 103-2637, General Safety is recommended. • Park machine on level ground, disengage drives, For operators over 250 lb (113 kg), it is set parking brake, stop engine, remove key or recommended to use pneumatic tire assembly, disconnect spark plug wire. - Page 12 Operation g192304 g192305 Figure 9 Figure 11 1. Platform side handles 1. Left platform side handle 3. Latch 2. Lift up Slowly and carefully rotate the StandOn until it contacts the drawbar (see Figure 10). • Lowering the StandOn into Operating Position: If holding the left platform side handle, rotate the StandOn counterclockwise;...
-
Page 13: Maintenance
Unauthorized modifications to the original equipment or failure to use original Exmark parts could lead to serious injury or death. Unauthorized changes to the machine, engine, fuel or venting system, may... -
Page 14: Check Standon For Buildup
Lubricate Grease Fittings Insert one bearing, one new seal into the wheel. Note: See chart for service intervals. Note: Seals (Exmark PN 103-0063) must be Stop engine, wait for all moving parts to stop, and replaced. remove key. Engage parking brake. -
Page 15: Adjustments
Maintenance Adjustments Tire Adjustment To obtain additional ground clearance, the platform wheel can be repositioned (see Figure 13). g023980 Figure 13 1. Wheel can be mounted in either hole for height adjustment Note: To achieve more ground clearance for higher cutting heights, raise the platform by using the lower wheel adjustment hole. -
Page 16: Information
While the exposure from Exmark products may be negligible or well within the “no significant risk” range, out of an abundance of caution, Exmark has elected to provide the Prop 65 warnings. Moreover, if Exmark does not provide these warnings, it could be sued by the State of California or by... - Page 17 Notes:...
- Page 18 Notes:...
- Page 19 Service Record Date: Description of Work Done: Service Done By:...
- Page 20 Place Model No. and Serial No. Date Purchased Label Here (Included in the Literature Pack) or Fill in Below Model No. Serial No. ©2019 Exmark Mfg. Co., Inc. Part No. 4504-766 Rev. A 2101 Ashland Ave. (402) 223-6375 Beatrice, NE 68310 Fax (402) 223-5489...
