PANEL ALERT TYPE OF PROBLEM
A01 The fire does not ignite.
A02 The fire goes off abnormally.
The temperature of the pellets hopper or the
A03 Thermostat
water temperature exceed the envisioned
alarms
safety threshold.
A04 Smoke overheating.
A05 Pressure
Flue gas pressure switch trip.
switches alarm
A08 Abnormal smoke fan operation.
A09 Smoke probe faulty.
Routine maintenance alert (it does not block
SERVICE
the system).

10.12 ALARM RESET

To reset the alarm you must keep the 1 (ESC) button pressed for some time. The stove performs a check to determine whether the
warning cause is still present.
If this is the case, the warning will be shown again, otherwise the stove will switch to the OFF position.
If the warning is still present, contact a service centre.
11

ROUTINE MAINTENANCE

11.1 INTRODUCTION

For a long working life of the stove, have a periodic cleaning of the stove as described in the following paragrafs.
• Fume outlet pipes (fume conduit + chimney flue + chimney pot) must always be cleaned, scrubbed and checked by an authorized
technician in compliance with local regulations, with the instructions of the manufacturer and those of your insurance company.
• If there are no local regulations and no instruction from your insurance company, it is necessary to have your fume pipe, chim-
GRACE - SPIRIT - TALAS
3 3 3
SOLUTION
Check whether the brazier is clean / level of pellets in
the hopper.
Check pellet level in the tank.
Check that the burning pot is correctly positioned
in its case and does not contain deposits or unburned
material.
Check that the pellet cover and the fire door are
correctly closed.
Clogged flue
Check the level of pellets in the hopper.
Wait for the cooling stage to end, cancel the alarm and
restart the boiler setting the fuel loading at minimum
(SETTINGS menu - Pellet Recipe).
Check that dust does not clog the aeration grid on the
stove back.
If the alarm persists, contact the service centre. Check
if the room fan works properly (if present).
The set smoke threshold has been exceeded. Reduce
pellets loading (SETTINGS menu - Pellet Recipe).
Check for chimney obstructions/fire door opening, pel-
let tank opening, gasket seals, side fire ducts cleaning,
clogged hose connection, excess flue length, unfavou-
rable weather conditions and clogged stove.
If the alarm persists, contact the service centre.
If the alarm persists, contact the service centre.
When this flashing message appears upon start-up, it
means that the preset operating hours have elapsed
before maintenance. Contact the service centre.
