- Page 1 Video Intercom Indoor Station Quick Start Guide...
- Page 2 Trademarks and other Hikvision marks are the property of Hikvision and are registered trademarks or the subject of applications for the same by Hikvision and/or its affiliates. Other trademarks mentioned in this manual are the properties of their respective owners. No right of license is given to use such trademarks without express permission.
- Page 3 Video Intercom Indoor Station·Quick Start Guide TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT WILL HIKVISION, ITS DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES...
- Page 4 Video Intercom Indoor Station·Quick Start Guide Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
- Page 5 Video Intercom Indoor Station·Quick Start Guide Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into Warnings and Cautions: Warnings: Neglecting any of the warnings may cause serious injury or death. Cautions: Neglecting any of the cautions may cause injury or equipment damage.
- Page 6 Video Intercom Indoor Station·Quick Start Guide Exposing the equipment to direct sun light, low ventilation or heat source such as heater or radiator is forbidden (ignorance can cause fire danger). Do not aim the device at the sun or extra bright places. A blooming or smear may occur otherwise (which is not a malfunction however), and affecting the endurance of sensor at the same time.
-
Page 7: Table Of Contents
Video Intercom Indoor Station·Quick Start Guide Table of Contents 1 Getting Started ..................... 1 1.1 Activate Indoor Station ......................1 1.2 Set SIP Sever ..........................2 1.2.1 Set Private SIP ........................2 1.2.2 Set Standard SIP ........................ 3 1.3 Set Network ..........................5 1.3.1 Set Indoor Station Network Parameters ................ -
Page 8: Getting Started
Video Intercom Indoor Station·Quick Start Guide 1 Getting Started Here the local operation of indoor stations with touch screen is taken as example. The DS-KH6210-L should be operated with physical keys. The SOS key works as a return key; the Unlock key works as direction keys ▲and◄ to turn up and left; the Live View key works as direction keys ▼and►... -
Page 9: Set Sip Sever
Video Intercom Indoor Station·Quick Start Guide STRONG PASSWORD RECOMMENDED– We highly recommend you to create a strong password of your own choosing (using a minimum of 8 characters, including at least three kinds of following categories: upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product. -
Page 10: Set Standard Sip
Video Intercom Indoor Station·Quick Start Guide Figure 1-2 SIP Protocol Selection 3. Tap Device to enter the device management page. Figure 1-3 Device Management 4. Tap SIP Server, and enter the IP address of the SIP server. 5. Tap to save. 1.2.2 Set Standard SIP With the standard SIP, your indoor station can connect to any intercom device, software client, and phones which also support the standard SIP. - Page 11 Video Intercom Indoor Station·Quick Start Guide Make sure you have added a VoIP account in the standard SIP server. Steps: 1. Tap Settings -> Configuration -> SIP Settings to enter SIP Settings page. 2. Select Standard Protocol. Default admin password is 888999. ...
-
Page 12: Set Network
Video Intercom Indoor Station·Quick Start Guide Figure 1-5 Set VoIP Account 4. Tap to save the standard SIP settings. 1.3 Set Network 1.3.1 Set Indoor Station Network Parameters Network connection is mandatory for the use of the indoor station. Set the network parameters after activating the indoor station. -
Page 13: Set Linked Device Ip
Video Intercom Indoor Station·Quick Start Guide Figure 1-6 Network Settings 2. Enable DHCP, then the indoor station can search and get an IP address automatically. Skip the following steps if you have set an IP address for the indoor station by DHCP function. - Page 14 Video Intercom Indoor Station·Quick Start Guide With the standard SIP protocol, intercom can be realized when all these devices support the standard SIP protocol. The doorphone does not support adding with the standard SIP protocol. Here take door station network settings as example. Steps: 1.
-
Page 15: Set Indoor Station No
Video Intercom Indoor Station·Quick Start Guide 2. Tap Main Door Station to pop up the device information dialog box. Figure 1-10 Device Information Dialog Box 3. Select a door station type based on your actual door station type, and set the door station IP address. - Page 16 Video Intercom Indoor Station·Quick Start Guide Figure 1-11 Set Indoor Station No. 3. Select Indoor Extension to set the indoor extension No. and the room name. For Example: Set the indoor extension No. as 1, and the room name as Hello Room. What to do next You can press 201 on the door station to call the indoor station, and press 1 on the indoor station to call indoor extension.
- Page 17 Video Intercom Indoor Station·Quick Start Guide UD13066B...
