5.5

Serial Port Specifications

RS232/RS485/RS422
RS232/RS485/RS422
5.6

Operating Environment

The RUGGEDCOM RS401 is rated to operate under the following environmental
conditions.
Ambient Operating
Temperature
Ambient Storage Temperature
Ambient Relative Humidity
Maximum Altitude
a
Measured from a 30 cm (12 in) radius surrounding the center of the enclosure.
b
Non-condensing.
5.7

Mechanical Specifications

Weight
Ingress Protection
Enclosure
5.8

Dimension Drawings

Note
All dimensions are in millimeters, unless otherwise stated.
RUGGEDCOM RS401
Installation Manual, 11/2022, C79000-G8976-1017-12
Port Type
RS232 Standard RS232
Shielded Serial Cable
RS485 Shielded Twisted-Pair
Shielded Twisted-Pair
Shielded Twisted-Pair
a
b
1.9 kg (4.2 lb)
IP30
18 AWG Galvanized Steel
Media Distance
15 m (49 ft)
1200 m (3937 ft)
1200 m (3937 ft)
1200 m (3937 ft)
-40 to 85 °C (-40 to 185 °F)
-40 to 85 °C (-40 to 185 °F)
5% to 95%
2000 m (6562 ft)
Technical Specifications
5.5 Serial Port Specifications
Connector Type
DB9
Insulated Terminals
DB9
RJ45
31
