Olivetti MF22 Manual

Hide thumbs Also See for MF22:
Table of Contents

Advertisement

Quick Links

1
1.1
Product Overview..........................................................................1-1
1.2
Trademarks and Copyrights ........................................................1-2
2
2.1
Operating Environment ................................................................2-1
2.2
Accessories...................................................................................2-1
3
3.1
Using a Network Connection .......................................................3-2
3.2
Using a Parallel Connection.........................................................3-4
3.2.1
Specifying the Interface Settings ................................................3-5
4
4.1
Connected Using a Network Connection....................................4-2
4.1.1
4.2
Uninstalling the Printer Driver .....................................................4-8
5
5.1
5.1.1
Windows 98/Me ..........................................................................5-2
5.1.2
Windows 2000/NT 4.0 ................................................................5-3
5.1.3
Windows XP/Server 2003...........................................................5-3
5.2
Common Controls.........................................................................5-4
5.3
Settings ..........................................................................................5-6
5.3.1
Setup Tab ...................................................................................5-6
5.3.2
Paper Tab...................................................................................5-6
5.3.3
Quality Tab .................................................................................5-7
-1

Advertisement

Table of Contents
loading

Related Manuals for Olivetti MF22

Summary of Contents for Olivetti MF22

  • Page 1: Table Of Contents

    Welcome Product Overview................1-1 Trademarks and Copyrights ............1-2 Before Using the Controller Operating Environment ..............2-1 Accessories...................2-1 Connecting to a Computer Using a Network Connection ............3-2 Using a Parallel Connection............3-4 3.2.1 Specifying the Interface Settings ..........3-5 Installing the Printer Driver When This Machine and the Computer are Connected Using a Network Connection........4-2 4.1.1 Installing the Printer Driver Using the Add Printer Wizard..4-2...
  • Page 2 5.3.4 Device Option Setting Tab ............5-7 5.3.5 Job Management Tab ..............5-8 Setting Device Options ..............5-9 Network Printing in a Windows Environment Network Connection Methods That Can Be Selected in Each Windows OS ............ 6-1 Setting the IP Address for This Machine........6-3 Accessing Printer Management Utility ........
  • Page 3 Retrieving Images Using TWAIN ..........8-4 8.4.1 Setting the Option Dialog Box ............8-6 8.4.2 Searching the Scanner ...............8-7 Using the Box Functions Overview ..................9-1 Environment Required for the Box Functions ......9-2 Using the Box Functions..............9-3 10 Using Printer Management Utility 10.1 System Requirements ..............10-1 10.2 Accessing Printer Management Utility........10-1...

  • Page 5: Welcome

    Welcome Welcome This manual describes the printing and scanning functions and operations of the printer controller for the Olivetti digital color copier MF22. Product Overview The printer controller is a device used for adding printing, network printing, scanning and box functions to the MF22 copier.

  • Page 6: Trademarks And Copyrights

    Welcome Trademarks and Copyrights Trademarks Ethernet is a registered trademark of Xerox Corporation. Microsoft, Windows and Windows NT are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. Novell and NetWare are registered trademarks of Novell, Inc. PCL is a registered trademark of Hewlett-Packard Company Limited.

  • Page 7: Before Using The Controller

    Before Using the Controller Before Using the Controller Operating Environment The printer controller operates in the following environments. Computer IBM PC or compatible Operating System Windows 98/98SE, Windows Me, Windows 2000, Windows XP, Windows NT 4.0 (SP6a or later), or Windows Server 2003 64 MB or more Network Connection Connection...
  • Page 8 Before Using the Controller...

  • Page 9: Connecting To A Computer

    Connecting to a Computer Connecting to a Computer In order to send print data from a computer to this machine, or to capture data scanned using this machine, it is necessary to connect this machine to the computer. There are two ways to connect this machine to the computer. A network connection can be used to connect this machine to the computer over a network, or a parallel connection can be used to connect this machine directly to the computer.

  • Page 10: Using A Network Connection

    Connecting to a Computer Using a Network Connection To use this machine in a network environment, use a 10Base-T/100Base- TX cable (Ethernet cable) to connect this machine to the network. Important Be sure to use a Category 5 or 5E cable that complies with the 10Base-T/100Base-TX standard.
  • Page 11 Connecting to a Computer When this machine is turned on, LED1 will light up. LED1: LINK Lights up if this machine is properly connected to the network. LED2: ACT Blinks depending on the data reception status.

  • Page 12: Using A Parallel Connection

    Connecting to a Computer Using a Parallel Connection Use a parallel cable (IEEE 1284, Centronics) to connect the parallel port on this machine to the parallel port on the computer. The parallel port on this machine supports IEEE 1284 Type B. Note To connect this machine to the computer using a parallel connection, the optional local interface kit is required.

  • Page 13: Specifying The Interface Settings

    Connecting to a Computer 3.2.1 Specifying the Interface Settings If necessary, specify the parallel interface settings from this machine’s control panel. Parallel interface setting Press the [Utility] key on this machine’s control panel, touch [Admin. Mode], and then enter the administrator access code. Touch [Printer Setting], then [Common Setting].
  • Page 14 Connecting to a Computer...

  • Page 15: Installing The Printer Driver

    “For Windows XP/Server 2003” on page 4-5 Note To connect this machine to a computer using a parallel connection, the optional local interface kit is required. Memo For details on the installation procedure for parallel connection, refer to the MF22 Printer Controller User’s Guide.

  • Page 16: When This Machine And The Computer Are Connected Using A Network Connection

    Installing the Printer Driver When This Machine and the Computer are Connected Using a Network Connection 4.1.1 Installing the Printer Driver Using the Add Printer Wizard Note In order to perform IPP printing operations, the printer driver must be installed so that IPP printing can be set up when the printer driver is installed.
  • Page 17 Installing the Printer Driver Note For details on installing the printer driver in a network environment, refer to “6 Network Printing in a Windows Environment”. Because it is necessary to specify other network settings in advance when installing the printer driver using a network connection, install it using a local connection at this time.
  • Page 18 Installing the Printer Driver LPT1 Specify the connection port. Select here. Follow the on-screen instructions to perform the installation. Note Do not perform a test print at this point. Perform the test print after the network settings have been specified. When installation is complete, make sure that the icon of the installed printer appears in the “Printers”...
  • Page 19 Installing the Printer Driver For Windows XP/Server 2003 While Windows is running, load the CD-ROM into the computer’s CD- ROM drive. In Windows, click the [Start] button, and then click “Printers and Faxes”. For Windows XP, click Add a printer on the Printer Tasks menu.
  • Page 20 Installing the Printer Driver Local printer attached to this computer, and then click the Select [Next] button. Automatically detect and install my Plug and Play Clear the printer check box. Note For details on installing the printer driver in a network environment, refer to “6 Network Printing in a Windows Environment”.
  • Page 21 Installing the Printer Driver Click the [OK] button. The Printers list appears. Click the [Next] button. Follow the on-screen instructions to start the installation. Note Perform a test print after the network settings have been specified. When installation is complete, make sure that the icon of the installed printer appears in the “Printers and Faxes”...

  • Page 22: Uninstalling The Printer Driver

    Installing the Printer Driver Uninstalling the Printer Driver If it becomes necessary to delete the printer driver, for example, when you want to reinstall the printer driver, follow the procedure below to delete the driver. Uninstalling the printer driver For Windows 98/Me/2000/NT, click the [Start] button, point to “Settings”, and then click “Printers”.

  • Page 23: Setting Up The Printer Driver

    Setting Up the Printer Driver Setting Up the Printer Driver The printer driver setup dialog box can be displayed from the “Printers” (for Windows XP/Server 2003, “Printers and Faxes”) window of the Windows. Settings specified in the printer driver setup dialog box displayed using the procedure described below will be applied when printing from any application.

  • Page 24: Displaying The Printer Driver Setup Dialog Box

    Windows 98/Me Display procedure In Windows, click the [Start] button, point to “Settings”, and then click “Printers”. Select the “OLIVETTI MF22 PCL5c” icon. On the “File” menu, click “Properties”. The printer driver setup dialog box shown below appears. Note Use the settings on the 5 tabs at the top of the dialog box to set up the...

  • Page 25: Displaying The Printer Driver Setup Dialog Box In Windows 2000/Nt 4.0

    Display procedure In Windows, click the [Start] button, point to “Settings”, and then click “Printers”. Select the “OLIVETTI MF22 PCL5c” icon. To display the “Device Option Setting” tab, click “Properties” on the “File” menu. To display the “Setup”, “Paper”, “Quality”, or “Job Management” tab, perform the following procedures after selecting the icon in step 2.

  • Page 26: Common Controls

    Setting Up the Printer Driver Common Controls The following describes the common settings and buttons that are displayed on all five tabs (“Setup”, “Paper”, “Quality”, “Device Option Setting”, and “Job Management”). Click this button to close the printer driver setup dialog box and apply any settings that have been changed.
  • Page 27 Setting Up the Printer Driver To save the current settings, click the [Save] button. The Save Easy Set Name dialog box appears. Enter the name of the set (10 characters or less), and then click the [OK] button. After the settings have been saved as a set, they can be retrieved by selecting the appropriate set name from the drop-down list.

  • Page 28: Settings

    Setting Up the Printer Driver Settings 5.3.1 Setup Tab Item Description N-up Prints multiple pages on one page. Watermark Prints a watermark on the pages. The watermark text can be changed or edited. Duplex/Booklet Selects the duplex or booklet printing setting. Paper Source Specifies the paper source and the type of paper.

  • Page 29: Quality Tab

    Setting Up the Printer Driver 5.3.3 Quality Tab Item Description Select Color or Selects the color mode. If “Color (Manual)” is selected, clicking the Grayscale [Detail of Color Settings] button displays the Detail of Color Settings dialog box, where detailed color settings can be specified. Exposure Modes Selects the color matching mode.

  • Page 30: Job Management Tab

    Prints a distribution number in the background. Access Code Specifies the assigned access number (password) when the Copy Track mode is set from this machine. Memo For details on the printer driver settings, refer to the MF22 Printer Controller User’s Guide.

  • Page 31: Setting Device Options

    Setting Up the Printer Driver Setting Device Options You can enable options installed on this machine from the printer driver. Setting procedure Display the printer driver setup dialog box (refer to “Displaying the Printer Driver Setup Dialog Box” on page 5-2), and then click the “Device Option Setting”...
  • Page 32 Setting Up the Printer Driver 5-10...

  • Page 33: Network Printing In A Windows Environment

    Network Printing in a Windows Environment Network Printing in a Windows Environment Network Connection Methods That Can Be Selected in Each Windows OS This chapter describes the settings that must be specified for network printing. Setting procedures differ depending on the method of network printing used (Windows, LPR, or IPP printing).
  • Page 34 Network Printing in a Windows Environment Network Printing in a NetWare Environment NetWare Version Protocol Used Emulation Service Mode NetWare 4.x NDS/Bindery PServer/NPrinter NetWare 5.x/6 PServer TCP/IP NDPS(lpr) Memo For the print procedures on NetWare, refer to the MF22 Printer Controller User’s Guide.

  • Page 35: Setting The Ip Address For This Machine

    Network Printing in a Windows Environment Setting the IP Address for This Machine First, use this machine’s control panel to assign an IP address to this machine. Note When specifying network settings, follow the instructions of the network administrator. Setting procedure Press the [Utility] key on this machine’s control panel, touch [Admin.
  • Page 36 Network Printing in a Windows Environment network, so it is not necessary to assign them manually. However, note the following when setting “DHCP” to “Enable”: Check with the network administrator that the DHCP server exists. If the DHCP server does not exist, be sure to specify settings for “IP Address”, “Subnet Mask”, and “Gateway Address”.

  • Page 37: Accessing Printer Management Utility

    Network Printing in a Windows Environment Accessing Printer Management Utility Setting the IP address for this machine enables you to access Printer Management Utility. Use your Web browser to directly access Printer Management Utility. Access procedure Start up the Web browser. In the URL field, enter the IP address for this machine as shown below, and then press the [Enter] key.

  • Page 38: Windows Printing

    Network Printing in a Windows Environment Windows Printing You can use Windows printing to print directly over the Microsoft network. Note To perform Windows printing, the NetBEUI protocol must be installed on your computer. 6.4.1 Operations on This Machine Set the IP address on this machine. For the setting procedure, refer to “Setting the IP Address for This Machine”...
  • Page 39 Network Printing in a Windows Environment Specify settings for the following. Enable Windows Printing Service: Set whether to use the Windows printing service. Select “Enable” here. NetBIOS Name: Specify the NetBIOS name (up to 15 alphanumeric characters). Printing Service Name: Specify the printing service name (up to 13 alphanumeric characters).

  • Page 40: Printer Driver Settings

    Network Printing in a Windows Environment 6.4.2 Printer Driver Settings For Windows 98/Me Click the [Start] button, point to “Settings”, and then click “Printers”. Right-click the icon for the installed printer, and then click “Properties”. On the “Details” tab, click the [Add Port] button. Select Network, and then click the [Browse] button.

  • Page 41: Lpr Printing (Windows 2000/Xp/Nt 4.0/Server 2003)

    Network Printing in a Windows Environment LPR Printing (Windows 2000/XP/NT 4.0/Server 2003) The LPR print service is supported as standard in Windows 2000/XP/NT 4.0. TCP/IP is used as the network protocol. 6.5.1 Operations on This Machine Specify the IP address for this machine. For the setting procedure, refer to “Setting the IP Address for This Machine”...
  • Page 42 Network Printing in a Windows Environment For Windows NT 4.0 Click the [Start] button, point to “Settings”, and then click “Printers”. Right-click the icon of the installed printer, and then click “Properties”. On the “Ports” tab, click the [Add Port] button. In the Available Printer Ports list, select...

  • Page 43: Ipp Printing (Windows 2000/Xp/Server 2003)

    Network Printing in a Windows Environment IPP Printing (Windows 2000/XP/Server 2003) The IPP (Internet Printing Protocol) print service is supported as a standard in Windows 2000/XP/Server 2003. TCP/IP is used as the network protocol. 6.6.1 Operations on This Machine Specify the IP address for this machine. For the setting procedure, refer to “Setting the IP Address for This Machine”...
  • Page 44 Network Printing in a Windows Environment Specify settings for the following. Printer URI: The URL of the printer that can be used for IPP printing is displayed. Enable IPP: Set whether to perform IPP printing. Select “Enable” here. Accept IPP Jobs: Set whether to use the IPP reception function.

  • Page 45: Installing The Printer Driver

    (\Driver\English\Printer\Win2KXP), and then click the [OK] button. Printers Check that “OLIVETTI MF22 PCL5c” is displayed in the list, and then click the [Next] button. Select whether to set the printer as the default printer, and then click the [Next] button.
  • Page 46 Network Printing in a Windows Environment Click the [Finish] button to exit the Add Printer Wizard. Once the settings for the printer have been specified, you can use the printer in the same way as a default local printer. Also, if you set up the printer for sharing in Windows, it can be used as a network printer by other Windows computers over the network.

  • Page 47: Using The Scan Functions

    Attaches the scanned data to an e-mail and sends it to a device that supports Internet faxing. In addition, received image data can be printed. Memo For the setup and operating procedures in each Scan Mode, refer to the MF22 Printer Controller User’s Guide.

  • Page 48: Environment Required For The Scan Functions

    Using the Scan Functions Environment Required for the Scan Functions The following environment is required to send image data (send and receive for Internet faxing) using the scan functions. Note All scan functions can only be used under a TCP/IP network environment.

  • Page 49: Supported File Formats

    Using the Scan Functions Supported File Formats You can select TIFF, PDF, or JPEG for the scan data file format. The transmission file is created according to the specified file format. One of the extensions below is attached to the file name according to the specified file format.

  • Page 50: Scan To E-Mail

    Using the Scan Functions Scan to E-mail Sends the image data scanned on this machine as an attached file to an e-mail address. Suitable for sending low-resolution data. Requires a network environment with a mail server. Mail Server Client Computer Client Computer...

  • Page 51: Scan To Ftp Server

    Using the Scan Functions Scan to FTP Server Sends the image data scanned on this machine to a specified folder on the FTP server. Suitable for sending high-resolution data. Requires a network environment with an FTP server. Allows you to select whether to use the e-mail notification function, which sends an e-mail message containing information indicating the storage location of the image data.

  • Page 52: Scan To Pc

    Using the Scan Functions Scan to PC Sends the image data scanned on this machine directly to a computer using FTP. Requires an FTP server application on the computer and the application must be running when receiving the image data. Client Computer FTP server application...

  • Page 53: Scan To Hdd

    Using the Scan Functions Scan to HDD Sends the image data scanned on this machine to a specified folder (box) on the hard disk installed in this machine. Suitable for sending high-resolution data. Allows you to select whether to use the e-mail notification function, which sends an e-mail message containing information indicating the storage location of the image data.

  • Page 54: Scan To Internet Fax

    Using the Scan Functions Scan to Internet FAX Attaches the image data scanned on this machine to an e-mail and sends it to a device that supports Internet faxing. The image data is sent with the “Black” Color Mode setting in the TIFF format at 200 ×...

  • Page 55: Internet Fax Reception

    Using the Scan Functions Internet FAX Reception Receives e-mails sent from a device that supports Internet faxing and prints out the data. The following image data can be received. “Black” Color Mode setting, TIFF format, 200 × 200 dpi/200 × 100 dpi Device that supports Internet faxing Printout...
  • Page 56 Using the Scan Functions 7-10...

  • Page 57: Scanning Images Using Twain (Pc Scanning Function)

    Scanning Images Using TWAIN (PC Scanning Function) Scanning Images Using TWAIN (PC Scanning Function) TWAIN is an interface used to import images scanned on a certain device onto different computer platforms. Here, TWAIN refers to controlling this machine’s scanner and importing the scanned data into the application. To use TWAIN, a TWAIN driver must be installed on the computer and TWAIN configuration is required in this machine.

  • Page 58: Setting The Panel Lock Timeout For Twain

    Scanning Images Using TWAIN (PC Scanning Function) Setting the Panel Lock Timeout for TWAIN Using Printer Management Utility or this machine’s control panel, set the panel lock timeout for using TWAIN to import images onto the computer. Using Printer Management Utility Start up Printer Management Utility.
  • Page 59 Scanning Images Using TWAIN (PC Scanning Function) Using this machine’s control panel On this machine’s control panel, press the [Utility] key, touch [Admin. Mode], and then enter the administrator access code. Touch [Network Setting], then [Twain]. Specify the setting for the “Operation Lock Time for TWAIN” parameter.

  • Page 60: Retrieving Images Using Twain

    Scanning Images Using TWAIN (PC Scanning Function) Retrieving Images Using TWAIN Retrieval procedure Set the document on this machine. In the application used to retrieve images, carry out the TWAIN scan operation (for example, click “Select Device” on the “File” menu). Select the retrieval destination for the scanned data (IP address:port number).
  • Page 61 Scanning Images Using TWAIN (PC Scanning Function) Paper Size: Set the paper size to be scanned. Resolution: Set the resolution. Settings: 600 dpi, 400 dpi, 300 dpi, or 200 dpi Pixel Type: Specify the type of data to be scanned. Settings: “Full Color”, “Gray Scale”, or “Black &...

  • Page 62: Setting The Option Dialog Box

    Scanning Images Using TWAIN (PC Scanning Function) 8.4.1 Setting the Option Dialog Box Click the [Option] button in the Scan dialog box to open the dialog box shown below. You can specify a range and perform clipping. Drag the pointer to select the part of the image to be clipped, and then click the [Select] button.

  • Page 63: Searching The Scanner

    Scanning Images Using TWAIN (PC Scanning Function) 8.4.2 Searching the Scanner Click the [Setting] button in the dialog box used to select the retrieval destination of the scanned data to open a dialog box used to search the scanners. You can specify the following search conditions. Broadcast Searches using the broadcast protocol.
  • Page 64 Scanning Images Using TWAIN (PC Scanning Function)

  • Page 65: Using The Box Functions

    Memo For the procedure of saving the image data in the box on the hard disk, refer to the MF22 Printer Controller User’s Guide. Overview The following box functions are available on this machine. Use the appropriate type that matches your network environment and application.

  • Page 66: Environment Required For The Box Functions

    Using the Box Functions Environment Required for the Box Functions To forward image data using a box function, the following environment is required. Note All box functions can only be used under a TCP/IP network environment. Environment Environment Required to Forward Required to Receive Other Limitations Image Data...

  • Page 67: Using The Box Functions

    Mode], and then enter the administrator access code. Touch [Admin. Set.], then [Box Function] (page 2/4). Touch [Permit], and then touch [Enter]. Memo For the setup and operating procedures of the box function, refer to the MF22 Printer Controller User’s Guide.
  • Page 68 Using the Box Functions...

  • Page 69: Using Printer Management Utility

    Using Printer Management Utility Using Printer Management Utility Printer Management Utility is a device control utility program provided by the HTTP server built into the printer controller. Start up a Web browser on a computer on the network and access Printer Management Utility to easily change the copier settings.

  • Page 70: 10.2.1 Operation

    Using Printer Management Utility 10.2.1 Operation Printer Management Utility operation is identical to that for Internet Web pages. You can click a link on the page to jump to the link destination, or click the [Back] (or [Forward]) button to display the previous (or next) page.
  • Page 71 Using Printer Management Utility 1. Status Display The statuses of this machine’s printer section and this machine’s scanner section are displayed using icons and text. The message “Ready” appears when this machine is operating normally. If an error has occurred in this machine, the status of the problem/error and other error information are shown.

  • Page 72: Logging In To Administrator Mode

    Using Printer Management Utility 10.4 Logging in to Administrator Mode You can switch between User mode and Administrator mode. However, you must enter Administrator mode to specify system configurations or network configurations. Login procedure Administrator’s Code In the box on the User mode page, enter the §...
  • Page 73 Using Printer Management Utility If the unauthorized access lock is enabled on this machine’s control panel and you enter a wrong administrator’s code three times, the login is determined to be invalid and you will no longer be able to log in to Administrator mode.
  • Page 74 Using Printer Management Utility 10-6...

  • Page 75: Using The Box Utility

    Using the BOX Utility Using the BOX Utility The BOX Utility is a program used to retrieve, print, or send as an e-mail attachment the image data that has been stored on the hard disk using the Scan to HDD operation. The data is exchanged with the copier using FTP. Note To use this utility program, an optional hard disk must be installed in this machine.

  • Page 76: System Requirements

    Using the BOX Utility 11.1 System Requirements Computer IBM PC or compatible Pentium II 450 MHz with 128 MB or more (Pentium III 1 GHz with 256 MB or more recommended) Operating System Windows 98SE, Windows Me, Windows 2000, Windows XP, or Windows NT 4.0 (SP 6a or later) Network Environment A TCP/IP network is required.

  • Page 77: Installing The Box Utility

    Using the BOX Utility 11.3 Installing the BOX Utility Note If other application programs are running, close them before starting the installation. If another application is running, the program may not be installed correctly. Procedure Open the folder that contains BOX Utility on the supplied CD-ROM (the “BoxUtility”...

  • Page 78: Using The Box Functions

    Using the BOX Utility 11.4 Using the Box Functions To use BOX Utility, you must enable the box functions from this machine’s control panel. Setup procedure On this machine’s control panel, press the [Utility] key, touch [Admin. Mode], and then enter the administrator access code. Touch [Admin.

  • Page 79: Registering The Copier

    Up to 10 copiers can be registered. Registration procedure Click the [Start] button, and then click “Programs” – “OLIVETTI” – “BOX Utility” – “BOX Utility” to start up the BOX Utility. On the “Setup” menu, click “Register MFP Controller”.
  • Page 80 Using the BOX Utility Press the computer keyboard’s [Enter] key and click the [OK] button. The registration is saved. You can also edit or delete registrations and change the order that the registrations are displayed in the Register MFP Controller dialog box. 11-6...

  • Page 81: Connecting The Copier

    Using the BOX Utility 11.6 Connecting the Copier Connect the copier to access the image data on the copier hard disk. Connection procedure On the “Communicate” menu, click “Connect”. You can also click on the toolbar. A dialog box used to select the destination appears. If multiple copiers are registered, select the copier to be connected Connecting MFP from the...
  • Page 82 Using the BOX Utility Click the [Connect] button. A list of image data in the selected box appears. Disconnecting from the copier To disconnect from the copier, click “Disconnect” on the § “Communicate” menu, or click on the toolbar. 11-8...

  • Page 83: Main Window

    Using the BOX Utility 11.7 Main Window After connecting the copier and selecting a box, a list of image data is displayed. Memo For the operating procedures on the List Window, refer to the MF22 Printer Controller User’s Guide. 11-9...

  • Page 84: Image Display Window

    Using the BOX Utility 11.8 Image Display Window An image display window opens when you select a file from the main window, then click “Open” on the “Command” menu. You can perform the operations described below in the image display window.

  • Page 85: Troubleshooting

    Troubleshooting Troubleshooting 12.1 Unable To Print This chapter explains the troubleshooting procedures for possible malfunctions. Perform the troubleshooting procedures given below when this machine does not print, even after you have executed the print command from your computer. Symptom Probable Cause Action A message appears, An error has occurred in this...

  • Page 86: Unable To Specify Desired Settings Or Unable To Print As Specified

    Memo Some of the printer driver functions cannot be combined with other functions. For details, refer to the MF22 Printer Controller User’s Guide. Symptom Probable Cause...
  • Page 87 Troubleshooting Symptom Probable Cause Action Stapling cannot be Number of pages that can be Change the Copies setting. performed. stapled when FS-501 is installed: Up to 30 pages Number of pages that can be stapled when FS-601 is installed: Up to 50 pages on A4/ Letter or smaller paper, and up to 25 pages on B4/Legal or larger paper...
  • Page 88 Troubleshooting 12-4...
