Bedienungsanleitung
User Manual
PCE-MFM 2400 Serie| series Teslameter
User manuals in various languages (français,
italiano, español, português, nederlands, türk, polski,
русский, 中文) can be found by using our
product search on: www.pce-instruments.com
Letzte Änderung / last change: 17 December 2019
v1.0
© PCE Instruments

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCE-MFM 2400 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for PCE Health and Fitness PCE-MFM 2400 Series

  • Page 1 Bedienungsanleitung User Manual PCE-MFM 2400 Serie| series Teslameter User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Letzte Änderung / last change: 17 December 2019 v1.0 ©...
  • Page 2: Table Of Contents

    Deutsch Inhaltsverzeichnis Sicherheitsinformationen ..............1 Spezifikationen ..................2 Technische Spezifikationen ....................2 Lieferumfang ........................2 Optionales Zubehör ......................2 Systembeschreibung ................3 Gerät ..........................3 Anschlüsse ........................3 Display ..........................4 Funktionstasten ........................ 4 Vorbereitung ..................5 Stromversorgung ......................5 Inbetriebnahme ........................
  • Page 3 English Contents Safety notes ................... 8 Specifications ..................9 Technical specifications ....................9 Delivery contents ......................9 Optional accessories ......................9 System description ................10 Device ..........................10 Interfaces ........................10 Display ..........................11 Function keys ........................11 Getting started ..................12 Power supply ........................12 Preparation ........................12 Operation .....................
  • Page 4: Sicherheitsinformationen

    Sicherheitsinformationen Bitte lesen Sie dieses Benutzer-Handbuch sorgfältig und vollständig, bevor Sie das Gerät zum ersten Mal in Betrieb nehmen. Die Benutzung des Gerätes darf nur durch sorgfältig geschultes Personal erfolgen. Schäden, die durch Nichtbeachtung der Hinweise in der Bedienungsanleitung entstehen, entbehren jeder Haftung. ...
  • Page 5: Spezifikationen

    Spezifikationen Technische Spezifikationen Spezifikationen des Messgeräts PCE-MFM 2400 und PCE-MFM 2400+ Spezifikation Erläuterung 0 … 200 mT Messbereich 200 … 2400 mT 0 … 2000 Gs 2000 … 24000 Gs Genauigkeit ±1 % v. Mw. Auflösung 0,01 mT 0,1 Gs Messrichtung transversal (PCE-MFM 2400) axial (PCE-MFM 2400+)
  • Page 6: Systembeschreibung

    Systembeschreibung Gerät 1. Display 4. Transversaler Sensor 2. Folientastatur 5. Axialer Sensor 3. Batteriefach Anschlüsse 1. Anschlussbuchse © PCE Instruments...
  • Page 7: Display

    Display 1. Aktueller Messbereich 5. Magnetische Polarität 2. Hintergrundbeleuchtung 6. Aktueller Messwert 3. Haltemodus 7. Einheit (mT/Gs) 4. Batteriestatus 8. Prozentsatzanzeige des Messbereichs Funktionstasten Taste Bezeichnung Funktion Ein/Aus Gerät ein- und ausschalten Durch Drücken der Taste wird der aktuell gemessene Maximalmesswert auf dem Display beibehalten.
  • Page 8: Vorbereitung

    Vorbereitung Stromversorgung Zur Stromversorgung wird eine 9V Blockbatterie benötigt. Bevor Sie diese tauschen; schalten Sie das Gerät aus. Das Batteriefach befindet sich auf der Rückseite des Gerätes. Lösen Sie die Abdeckung, legen Sie die Batterie wie gekennzeichnet ein und verschließen Sie das Batteriefach wieder.
  • Page 9: Automatische Abschaltung

    Automatische Abschaltung Wenn 5 Minuten lang keine Eingabe erfolgt, schaltet sich das Messgerät automatisch aus und spart so Energie. Wenn Sie das Gerät wieder nutzen möchten, müssen Sie es mit wieder einschalten. Anzeigefunktionen Halten Um den jeweiligen Maximalwert korrekt ablesen zu können, hat das Messgerät eine Haltefunktion. Dazu müssen Sie die „HOLD“...
  • Page 10: Garantie

    Garantie Unsere Garantiebedingungen können Sie in unseren Allgemeinen Geschäftsbedingungen nachlesen, die Sie hier finden: https://www.pce-instruments.com/deutsch/agb. Entsorgung HINWEIS nach der Batterieverordnung (BattV) Batterien dürfen nicht in den Hausmüll gegeben werden: Der Endverbraucher ist zur Rückgabe gesetzlich verpflichtet. Gebrauchte Batterien können unter anderem eingerichteten Rücknahmestellen oder bei der PCE Deutschland GmbH zurückgegeben werden.
  • Page 11: Safety Notes

    Safety notes Please read this manual carefully and completely before you use the device for the first time. The device may only be used by qualified personnel and repaired by PCE Instruments personnel. Damage or injuries caused by non-observance of the manual are excluded from our liability and not covered by our warranty.
  • Page 12: Specifications

    Specifications Technical specifications Specifications of the meter PCE-MFM 2400 and PCE-MFM 2400+ Specification Description 0 … 200 mT Measurement range 200 … 2400 mT 0 … 2000 Gs 2000 … 24000 Gs Accuracy ±1 % of rdg. Resolution 0.01 mT 0.1 Gs Measuring direction transversal (PCE-MFM 2400)
  • Page 13: System Description

    System description Device 1. Display 4. Transversal sensor 2. Membrane keypad 5. Axial sensor 3. Battery compartment Interfaces 1. Connection socket © PCE Instruments...
  • Page 14: Display

    Display 1. Current measurement range 5. Magnetic polarity 2. Backlight 6. Percentage bar 3. HOLD mode 7. Unit (mT/Gs) 4. Current reading Function keys Description Function On/off Turn meter on/off By pressing this key, the measured maximum value will be held in the display.
  • Page 15: Getting Started

    Getting started Power supply For power supply, a 9 V block battery is required. Before replacing these, turn off the meter. The battery compartment is located at the rear side of the meter. Loosen the cover and insert the battery as marked.
  • Page 16: Auto Power Off

    Auto Power Off When no entries have been made for 5 minutes, the meter will turn off automatically to save energy. If you wish to use the meter again after Auto Power Off, press to turn it back on. Display functions Hold To enable the user to read the maximum value correctly, the meter has a Hold function.
  • Page 17: Warranty

    Warranty You can read our warranty terms in our General Business Terms which you can find here: https://www.pce-instruments.com/english/terms. Disposal For the disposal of batteries in the EU, the 2006/66/EC directive of the European Parliament applies. Due to the contained pollutants, batteries must not be disposed of as household waste. They must be given to collection points designed for that purpose.
  • Page 18 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 4 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 Soultz-Sous-Forets 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17 Tel.
  • Page 19 © PCE Instruments...
  • Page 20 User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Specifications are subject to change without notice. © PCE Instruments...
