M2K03 Setting Clock and Schedules
SETTING THE TIME CLOCK - TIME SCHEDULES
To set the schedule, follow the instructions below.
Step 1
Press and hold the
button until the display goes blank. Press the
and
buttons to select
between 'CLOC' and 'SCHE' . Select the 'SCHE' mode by pressing the
button.
Step 2
Once the schedule function has been selected, 'DAY1' is displayed. You may scroll through the days
requiring programming by using the
and
buttons. When the desired day is
displayed select it by pressing the
button. E.g. 'DAY 1' = Monday, 'DAY 2' = Tuesday.
Step 3
The display will now read 'SCH 1' .
Note that this 7 day time clock is capable of 2 on / off times per day refered to as, schedule 1 & schedule 2.
If only one event is required per day then enter no times for schedule 2.
Press the
button and select 'SCH 1' The display will then flash "ON" followed by the on time.
Use the
and
buttons to adjust the on time then press the
button to save the time
setting. 'OFF' followed by '----' will then be displayed. Set the "OFF" time and press the
button.
Step 4
The display will now show 'SCH 2' . Press the
button. Either enter an 'ON' and 'OFF' time or
ignore it by pressing the
button again. Note if no time is entered for 'SCH 2' then '----' will be
displayed for the 'ON' time and the 'OFF' time will not be displayed.
Step 5
The display will now read 'DAY 2' . Repeat steps 2 and 3 for each day as required. If the 'DAY 2'
'ON' and 'OFF' time is to be the same as 'DAY 1' , Then press
when the '----' is displayed for the
'ON' time. Note if a mistake is made press
to delete the unwanted time. Press
to return to the
previous setting. Press and hold the
button to save and exit.
ENABLE THE AUTO FUNCTION
Pressing the
button 'ON' will allow the unit to run under the control of it's programmed weekly
timeclock.
SETTING THE TEMPERATURE
*Note the range of this adjustment can be restricted.
When the
or
buttons are depressed. The set point will be displayed Continuing to press
either the
or
buttons will increase or decrease the set point. If the
or
buttons have not
been depressed for 5 seconds the display will revert to the sensed temperature.
VENT CONDITION MODE
The
button will toggle the unit between Vent and Condition. On state = Condition.
AFTER HOURS MODE
The
button will allow the unit to run for either a pre-determined timed period, an adjustable time
period or continuously depending on the programmed options. Pressing the
button while in the
after hours mode will toggle the unit to 'OFF' .
