Slide the monitor onto the head of swivel arm, install the security nut (K). Make
sure the security nut is installed before you rotate the monitor.

STEP 3 Adjust the tension

Adjust gas spring tension by turning
screw with 6mm Allen wrench (P) .
Clockwise(" - " direction) reduces
tension, counter Clockwise("+"
direction increases tension. The tension
should be just enough to hold your
monitor in place without lifting itself
up.
P
Be sure to keep the arm in horizontal
position during adjustment .0r else it
would be difficult to adjust the mount or
damage the mount.
P
If needed, adjust the bolt on
the side of the hinge behind
the VESA plate to tighten or
loosen the tilt angle support.
K
