Summary of Contents for eletab ELTGM02-1

  • Page 1 ELTGM02-1 EleTab_service@outlook.com www.facebook.com/EleTabus...
  • Page 2 Read the entire instrution manual before you start installation and assembly. If you have any questions regarding any of the instructions or warnings, Please contact at EleTab_service@outlook.com for assistance. CAUTION: Use with products heavier than the rated weights indicated may result in instability causing possible injury.
  • Page 3: Tools Required

    Parts Tools required M (x1) N (x1) Phillips 4mm Allen 6mm Allen Screwdriver Wrench Wrench (not included) Components A (x1) B (x1) C (x1) D (x1) E (x1) Column Base Clamp Clamp Plate Grommet Plate F (x1) G (x1) H (x1) I (x2) J (x3) VESA Plate...
  • Page 4 STEP 1 Choose a mounting option OPTION A: Grommet Installation Mount column (A) to base (B) using short bolts (I). Tighten with 6mm Allen wrench (N). Mount grommet plate (E) to base using flat head bolts (J) and tighten with 4mm Allen wrench (M).
  • Page 5 Place the base over grommet hole in desk, and secure using grommet bolt (L) and support plate (K). Tighten with 6mm Allen wrench (N). Please note, desktop thickness must be 3/8” - 1” (10mm - 25mm). STEP 1 (Continued) OPTION B: Clamp Installation Mount clamp plate (D) to base using flat head bolts (J) and tighten with 4mm Allen wrench (M).
  • Page 6 For desktop thickness between 15-25mm. For 5/8” - 1” (15 - 25mm) desktop thickness: Place the base near the back edge of the desk. Position clamp (C) on base and desktop, then tighten clamp screws with 4mm Allen wrench (M). Install cable clip (G) to column For desktop thickness between 10-20mm.
  • Page 7 STEP 2 Attach the monitors to the arm Mount VESA plate (F) to back of monitor using screws (M-A or M-B) and washers (M-C), making sure the slot in back is facing down. Slide monitor with VESA plate onto mounting bracket on column. Tighten the screw on the side of the bracket to secure the monitor.
  • Page 8: Step 3 Cable Management

    If needed, adjust the bolt on the side of the hinge behind the VESA plate to tighten or loosen the tilt angle. STEP 3 Cable management Loosen the knob to adjust monitor height. Manage cables and store tools using installed cable clip.
  • Page 9 Adjust as Desired ±10 ° +10 ° -10° ±180 °...
  • Page 10: Warranty & Service

    We encourage you to write a review sharing your experierience. Should you have any issues, please don't hesitate to contact us. Scan the qr code below for more products from EleTab For further services: EleTab_service@outlook.com...
