- Page 1 SLDR, SLDG Laser Detectors Users Manual December 2018 (English) © 2018 Fluke Corporation. All rights reserved. Specifications are subject to change without notice. All product names are trademarks of their respective companies.
- Page 2 LIMITED WARRANTY AND LIMITATION OF LIABILITY This Fluke product will be free from defects in material and workmanship for three years from the date of purchase. This warranty does not cover fuses, disposable batteries, or damage from accident, neglect, misuse, alteration, contamination, or abnormal conditions of operation or handling.
-
Page 3: Table Of Contents
Table of Contents Title Page Introduction ......................How to Contact Fluke.................... Safety Information....................Product Familiarization ..................Use the Detector ....................Maintenance ......................Clean the Product .................... Batteries......................Specifications...................... - Page 4 SLDR, SLDG Users Manual...
-
Page 5: Introduction
Use the Product with a laser level to identify new level and grade marks. The SLDR senses a red laser beam. The SLDG senses a green laser beam. How to Contact Fluke To contact Fluke, call one of the following telephone numbers: • Technical Support USA: 1-800-44-FLUKE (1-800-443-5853) •... - Page 6 SLDR, SLDG Users Manual • Do not use the Product if it operates incorrectly. • Do not use the Product if it is altered or damaged. • Remove the batteries if the Product is not used for an extended period of time, or if stored in temperatures above 50 °C.
-
Page 7: Product Familiarization
Laser Detectors Product Familiarization Product Familiarization Table shows the features of the Product. Table 2. Features Item Description Function Fast - Detector is too low. Beeper output signal Solid - Detector is on-grade. Slow - Detector is too high. ... - Page 8 SLDR, SLDG Users Manual Table 2. Features (cont.) Item Description Function Use to transfer reference marks 53.18 mm from the edge of Offset notch the detector. Accepts the rod clamp screw to attach the clamp to the Vertical rod clamp screw thread Detector vertically.
- Page 9 Laser Detectors Product Familiarization Figure shows how to attach the rod clamp to the Product. Figure 1. Rod Clamp Attachment...
-
Page 10: Use The Detector
SLDR, SLDG Users Manual Use the Detector Use the Detector and a laser level to identify new level and grade marks. To identify new level and grade marks: 1. Put the bottom of the laser level on a stable surface or tripod. 2. -
Page 11: Maintenance
Laser Detectors Maintenance Maintenance To maintain the Product, clean the case, front and rear LCDs, and laser beam reception window and replace the battery. W Caution To prevent damage to the Product, do not drop the Product. Treat the Product as a calibrated instrument. -
Page 12: Specifications
SLDR, SLDG Users Manual Specifications Working Range ..............≥6 m to ≤60 m (≥20 ft to ≤200 ft) Detection Height............... ≤50 mm (2 in) Accuracy Fine................0.75 mm Medium ..............1.75 mm Power Batteries..............1 x 9 V Alkaline IEC LR61 Battery Life............... ≥30 hrs, continuous use, as tested Dimensions (H x W x L) ..............83 mm x 83 mm x 32 mm (3.25 in x 3.25 in x 1.25 in) Weight...
