FI-7000 FiberInspector
The FI-7000 FiberInspector
defects that can cause unsatisfactory performance or failures in fiber optic
networks.
Accessing the Product Manuals
This guide provides basic information to help you get started using the tester.
For more detailed information, see the latest versions of the Versiv Users
Manual and the Versiv Technical Reference Handbook provided on the Product
Manuals DVD and on the Fluke Networks website.
Safety Information
Warning or Caution: Risk of damage or destruction to equipment or software. See
explanations in the manuals.
Warning: Risk of fire, electric shock, or personal injury.
This key turns the Product on and off.
To prevent possible fire, electric shock, or personal injury:
Read all safety information before you use the Product.
Carefully read all instructions.
Do not open the case. You cannot repair or replace parts in the
case.
Do not modify the Product.
Use only replacement parts that are approved by Fluke Networks.
Do not touch voltages > 30 V AC rms, 42 V AC peak, or 60 V AC.
Do not use the Product around explosive gas, vapor, or in damp or
wet environments.
PN 4467086, 4/2014
2014 Fluke Corporation
All product names are trademarks of their respective companies.
Getting Started Guide
™
video probe lets you see dirt, scratches, and other
Warning
Video Probe
Pro
™
Advertisement
Table of Contents
Related Manuals for Fluke FiberInspector Pro FI-7000
Summary of Contents for Fluke FiberInspector Pro FI-7000
- Page 1 Do not modify the Product. Use only replacement parts that are approved by Fluke Networks. Do not touch voltages > 30 V AC rms, 42 V AC peak, or 60 V AC. Do not use the Product around explosive gas, vapor, or in damp or wet environments.
-
Page 2: Connectors, Keys, And Leds
Have an approved technician repair the Product. For Products with rechargeable batteries, use only AC adapters approved by Fluke Networks for use with the Product to supply power to the Product and charge the battery. Caution To prevent damage to the Product or cables under test and to prevent data loss, read all safety information given in all documentation supplied with the Product. - Page 3 GPU173.EPS Figure 1. Connectors, Keys, and LEDs Headset jack. : Starts a test. To start a test, you can also tap TEST on the display. Power key. : Press to go to the home screen. ...
-
Page 4: How To Do A Fiberinspector Test
How to Do a FiberInspector Test 1. Power the Tester Charge the battery if necessary. Connect the ac adapter to ac power and to the adapter connector () shown in Figure 1. You can use the tester while the battery charges. 2. -
Page 5: Clean The Connector
GPU168.EPS Figure 3. How to Use the FI-1000 Probe Turn the dial to move the view of the endface. GPU175.EPS ® Figure 4. How to Use the Optional MPO/MTP Inspection Tip 4. Clean the Connector Use proper cleaning procedures to clean the connector you will inspect. 5. -
Page 6: Examine The Results
6. Examine the Results See Figure 5: Manual limit selected (default): To give a PASS or FAIL grade to the image, tap GRADE. Test limit selected: To see an analysis of the defects, tap ANALYZE. The tester uses the selected test limit to give scratches and defects a PASS (green highlight) or FAIL (red highlight) grade. -
Page 7: About Projects
NEW PROJECT. See the Users Manual or Technical Reference Handbook on the DVD for more information. Registration Registering your product with Fluke Networks gives you access to valuable information on product updates, troubleshooting tips, and other support services. - Page 8 니다 . LIMITED WARRANTY AND LIMITATION OF LIABILITY Fluke Networks mainframe products will be free from defects in material and workmanship for one year from the date of purchase. Parts, accessories, product repairs and services are warranted for 90 days, unless otherwise stated. Ni-Cad, Ni- MH and Li-Ion batteries, cables or other peripherals are all considered parts or accessories.
