TECHNICAL DATA
Amprobe UAT-620 Underground Utilities Locator Kit

Key features

Rated CAT IV 600 V, ensuring safety when working with energized cables
Multiple tracing modes allow you to locate and trace energized and de-energized utilities
Depth measurement up to 20 ft
Receiver's high-contrast display allows for clear viewing in full sunlight and features an automatic backlight for shaded
and dark area
Product overview: Amprobe UAT-620 Underground Utilities Locator
Kit
Accidentally hitting a utility line during a project can lead to costly repairs and create hazardous public safety situations.
Digging in the wrong place can also lead to unnecessary delays and costs for your project, and ultimately, your company.
Avoid this disruption with the rugged and durable Amprobe UAT-600 Series, designed to accurately pinpoint underground
utilities and buried services up to 100 feet deep with accurate depth measurement to 20 feet.
The locating kit comes complete and ready for use with a Transmitter, Receiver, test lead kit, batteries and additional fuses,
all in a mobile, protective duffle bag. Also included is a Signal Clamp for transmitting a signal when it is not possible to make
electrical contact with the cable to be traced. For applications where ground fault locating is required, use the UAT-600
Transmitter in combination with the optional A-Frame accessory.

Main applications

Locate energized 50/60 Hz cables carrying current
Identify the location of all metallic utilities: pipes*, energized and de-energized cables
