Using The Projector - Sencor SDC 8200 User Manual

NOTE:
1. If no key is pressed during the alarm period, the alarm will turn off automatically. Alarm beeping lasts for 2
minutes.
2. Press [ SNOOZE ] button to stop the current alarm and enter snooze. Alarm icon will be fl ashing
continuously. The alarm will sound again in 5 minutes. Snooze can be operated continuously in
24 hours.
3. Press [ ALARM ] button to turn off alarm function.
1. Press [ LOOP ] key to turn on or turn off the backlight colour change.
2. Turn off the loop function and press [ RAINBOW ] key, the backlight will change its colour in this sequence:
white > red > orange > yellow > green > cyan > blue > purple.
3. Turn off the loop function and press [ TUNE ] key, the backlight will display 256 colours.
CHECKING AND DELETING MAX/MIN TEMPERATURE RECORDS
1. Press [ MAX/MIN ] key once to check the maximum temperature records. Press it twice to check the
minimum records. Press it again to exit.
2. Press and hold [ MAX/MIN ] key for 3 seconds to delete the maximum and minimum temperature records,
with "beep" tone.
MAX temperature record
Plug the DC jack to turn the projector on, rotate the projector to project the light beam to a dark background
within 1-4 meters, the projected data will be displayed on the dark background as following diagram.
NOTE:
1. If using DC power, the projected data will be always on.
2. Press the [ ] key will reverse the projected data. The rotate angle of the projector is ±90º.
3. Adjust the quality of the projected data by adjusting the FOCUS knob.
CAUTION:
• Do not dispose old batteries as unsorted municipal waste. Collection of such waste separately for special
treatment is necessary.
• Danger of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the
instructions
• The socket outlet shall be installed near the equipment and shall be easily accessible
COLOUR CHANGE DISPLAY

USING THE PROJECTOR

EN - 6
MIN temperature record
