USER'S MANUAL
NÁVOD K OBSLUZE
NÁVOD NA OBSLUHU
FELHASZNÁLÓI KÉZIKÖNYV
INSTRUKCJA OBSŁUGI
SRC 350
PROJECTION CLOCK RADIO
WITH AC REMOTE SWITCH OUTLET
RADIOBUDÍK S PROMÍTÁNÍM ČASU
A DÁLKOVĚ OVLÁDANOU ZÁSUVKOU
RÁDIOBUDÍK S PREMIETANÍM ČASU
A DIAĽKOVO OVLÁDANOU ZÁSUVKOU
RÁDIÓS ÉBRESZTŐ IDŐKIVETÍTÉSSEL
ÉS TÁVVEZÉRELT ALJZATTAL
RADIOBUDZIK Z PROJEKCJĄ CZASU
I ZDALNIE STEROWANYM GNIAZDEM
Advertisement
Table of Contents
Related Manuals for Sencor SRC 350
Summary of Contents for Sencor SRC 350
- Page 1 SRC 350 USER’S MANUAL PROJECTION CLOCK RADIO WITH AC REMOTE SWITCH OUTLET NÁVOD K OBSLUZE RADIOBUDÍK S PROMÍTÁNÍM ČASU A DÁLKOVĚ OVLÁDANOU ZÁSUVKOU NÁVOD NA OBSLUHU RÁDIOBUDÍK S PREMIETANÍM ČASU A DIAĽKOVO OVLÁDANOU ZÁSUVKOU RÁDIÓS ÉBRESZTŐ IDŐKIVETÍTÉSSEL FELHASZNÁLÓI KÉZIKÖNYV ÉS TÁVVEZÉRELT ALJZATTAL INSTRUKCJA OBSŁUGI...
- Page 3 Projection Clock Radio with AC Remote Switch Outlet 1. PROJECTION UNIT 2. DISPLAY 3. TO SET THE LIGHT INTENSITY HIGH 4. TO SET THE LIGHT INTENSITY LOW 5. LIGHT ON/OFF 6. ALARM 1 ON/SET 7. ALARM 2 ON/SET 8. CLOCK SET/MEMORY/SET WIRELESS TRANSMITTER CHANNEL 9.
-
Page 4: Power Connection
AC/DC Adaptor connection The clock radio unit can be powered by an external AC-DC adaptor, required the output DC 5V 500mA type (TL01-050050E) (included) POWER CONNECTION Plug the AC/DC adaptor to a household outlet AC source, connect the adaptor’s DC output plug to the DC-in jack of the clock unit. - Page 5 Snooze and deactivate alarm To delay the alarm, press SNOOZE, it will come on again in approx. 9 minutes. You may repeat this cycle several times during the alarm cycle. Note: The alarm includes three relaxation melodies, which can be set as alarms Brook Bubble Forest...
-
Page 6: Projection Unit
PROJECTION UNIT Focus setting: Adjust the projection clock brightness/focus by turning the brightness/focus adjustment wheel until the projected time is clearly shown on the ceiling or wall. To fl ip projected image by 180° fl ip button. To deactivate projection, press PROJECTION ON/OFF button Note: Projects time image on the ceiling or wall of a darkened room. - Page 7 AC SOCKET WITH WIRELESS REMOTE CONTROL to a household outlet AC Channel 1-2-3 switch POWER LED source. RESET BUTTON POWER OUTPUT CONTROL LIGHTING: AC 230VI MAX. 150W (INCANDESCENT LAMP) AC 230V/MAX. 60W (HALOGEN ENERGY SAVER LAMP) Description: Only control lighting Working frequency: 433MHz Effective distance:...
- Page 8 Press the ALARM botton Press the or and you can change the (Tune - or Tune +) button to sound mode (Buzzer, radio, set a sound mode. nature) for the alarm. „radio“ wake by radio „nature“ wake by nature sound „buzzer“...
-
Page 9: Technical Specifications
Set the channel selector switch to the channel-1 Set the channel selector switch to the channel-2 Set the channel selector switch to the channel-3 TECHNICAL SPECIFICATIONS Frequency range: 87.5 – 108 MHz Backup battery: 3 V (fl at lithium battery CR2032 × 1, not included) Power supply Power adapter: Input AC (alternating current) 100 - 240 V ~ 50/60 Hz;... - Page 10 WARNING 1. Indoor used only. 2. The remote switch unit should not be connect after each other. 3. The type of disconnection of the remote switch: electronic disconnection. 4. Use the provided adaptor with the Radio only. 5. Using only the accessories or parts provided by the manufacturer or its authorized agent. 6.
-
Page 11: Instructions And Information Regarding The Disposal Of Used Packaging Materials
If you wish to dispose of this product, request the necessary information about the correct disposal method from local government departments or from your seller. Fast ČR, a.s. declares that SRC 350 + SRC-WS conform to the basic requirements and other relevant provisions of the directive 1999/5/ES. The device can be operated in the EU without restriction. - Page 12 EN - 10...
