Installation

WS103 dimensions

WS103 dimensions (mm [in])
59.00 [02.32]
75.00
[02.95]

Connectors

© Danfoss | April 2016
23.50 [0.925]

WS103 connectors and indicator element

WS103 is equipped with the following connectors and indicator element
1
1. CAN / Power connector
2. RS232 connector
3. Power / CAN / Status LED indicator element
33.50 [01.32]
2
3
kwa1459393937324
Ø4.3
59.00
[02.32]
Ø4.3
