LD630/LD640
Net Configuration Tool Manual
Technical Reference

Advertisement

loading
Need help?

Need help?

Do you have a question about the LD630 and is the answer not in the manual?

Questions and answers

Related Manuals for Oki LD630

Summary of Contents for Oki LD630

  • Page 1 LD630/LD640 Net Configuration Tool Manual Technical Reference...

  • Page 2: Table Of Contents

    ■ Table of Contents 1. Manual Information ......................3 2. Operating System (OS) Environment ................3 3. Software Installation & Deletion ................... 4 3-1 Installation........................ 4 3-2 Deletion ........................6 4. Configuration Tool ......................8 4-1 Configuration Tool ....................8 4-1-1 Ethernet Configuration ..................

  • Page 3: Manual Information

    This Net Configuration Tool Manual provides information on the utility program used to set printer operation conditions. We at Oki Data maintain ongoing efforts to enhance and upgrade the functions and quality of all our products. In following, product specifications and/or user manual content may be changed without prior notice.

  • Page 4: Software Installation & Deletion

    LD630/LD640 3. Software Installation & Deletion 3-1 Installation 1) Execute install file. 2) Click the “Next” button. - 4 -...
  • Page 5 LD630/LD640 3) Click the “Next” button. (Install to: C:\Program Files\Okidata\Net Configuration Setup\) 4) Installation will be completed on click the “Finish” button. - 5 -...

  • Page 6: Deletion

    LD630/LD640 3-2 Deletion (1) Windows 2000/XP/Server 2003 1) Click and activate the “Add/Remove Programs” icon in the Control Panel. 2) Select “Net Configuration Setup” and click the “Change/Remove“ button. 3) Click the “Yes” button to completely remove the application. - 6 -...
  • Page 7 LD630/LD640 (2) Windows Vista/Server 2008/Server 2008R2/7/8/Server 2012 1) Click and activate the “Programs and Features” icon in the Control Panel. 2) Select “Net Configuration Setup” and click the “Uninstall” button. 3) Click the “Yes” button to completely remove the application.

  • Page 8: Configuration Tool

    LD630/LD640 4. Configuration Tool 4-1 Configuration Tool Execute Net Configuration from Start menu. (Start>> Okidata>> Net Configuration.exe) Click the Ethernet Configuration button when the printer is connected to the Ethernet, or click the WLAN button when the printer is connected through WLAN.
  • Page 9 LD630/LD640 When you press the Search button, the printer connected to the network will be shown in the list. The following warning message may pop up if the firewall is installed. (Warning message do not print out in “Windows 2000 / Server 2012”.) (1) Windows XP/Server 2003/Vista/Server 2008/Server 2008R2 Select [Unblock], and then retry the Search operation.
  • Page 10 LD630/LD640 (2) Windows 7/8 Select [Allow access], and then retry the Search operation. Select the printer from the list and press the [Setting] button, and then the following window for setting Ethernet settings will pop up. - 10 -...
  • Page 11 LD630/LD640 Enter the proper IP Address, Subnet Mask, and Gateway for the currently used network, and then press the Save button to save the settings. (Device Baudrate setting, which is used for other models, is not necessary for our printer.) Select the printer from the list and press the [Configuration(Web)] button you will see the web browser for changing the Ethernet setting as shown below.
  • Page 12 LD630/LD640 Enter the ID and Password set in the printer, and click OK. (Default settings are ID: “admin”, Password: “password”) When you log in, you will see the web browser for changing the Ethernet settings as shown below. - 12 -...

  • Page 13: Wlan Configuration

    LD630/LD640 4-1-2 WLAN Configuration When you press the Search button, the printer connected to the network will be shown in the list. - 13 -...
  • Page 14 LD630/LD640 Select the printer from the list and press the [Setting] button, and then the following window for changing the WLAN settings will pop up. Enter the proper IP Address, Subnet Mask, and Gateway of the currently used network, and then click the [Save] button to save the settings.
  • Page 15 LD630/LD640 Select the printer from the list and press the [Configuration(web)] button, and then the Login window will pop up. Enter the ID and Password set in the printer, and click OK. (Default settings are ID: “admin”, Password: “password”) When you log in, you will see the web browser for changing the WLAN settings as shown below.
  • Page 16 LD630/LD640 You can search for the information of the wireless network by pressing the BSS Info button. When you press the BSS Info button, information about the SSID, BSSID, Network Model, and Encryption information of the network in close range will be shown as follows.
  • Page 17 LD630/LD640 [Note] More information about options, please refer to ‘Network interface Manual’. - 17 -...
  • Page 18 Fax:+353 (0)1 4049591 Liebermannstrasse A02 603 http://www.oki.ie Telefon: +36 1 814 8000 22345 Brun am Gebirge Telefax: +36 1 814 8009 Oki Systems Ireland Limited - Tel: +43 223 6677 110 Website: www.okihu.hu Northern Ireland Drucker Support: OKI Systems (Italia) S.p.A.
  • Page 19 Fax: 1-856-222-5260 Lingkaran Syed Pura 59200, Romania Email: LASatisfaction@okidata.com Kuala Lumpur, Malaysia Oki Data de Mexico, S.A. de C.V. Tel: +40 21 303 3138 Tel: (60) 3 2287 1177 Fax: +40 21303 3150 Fax: (60) 3 2287 1166 Mariano Escobedo #748, Piso 8 Website: http://romania.oki.com...
  • Page 20 Oki Data Corporation 4-11-22 Shibaura, Minato-ku,Tokyo 108-8551, Japan www.okiprintingsolutions.com Rev2...

This manual is also suitable for:

Ld640
