LD630/LD640
Network Interface Manual
Technical Reference

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LD630 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Oki LD630

Summary of Contents for Oki LD630

  • Page 1 LD630/LD640 Network Interface Manual Technical Reference...

  • Page 2: Table Of Contents

    ■ Table of Contents 1. Specifications......................... 3 2. How to Connect......................5 2-1 Initial Wireless LAN Connection (Windows 2000) ............ 6 2-2 Initial Wireless LAN Connection (Windows XP, Server 2003) ........6 2-3 Initial Wireless LAN Connection (Windows Vista, Server 2008, Server 2008R2, 7) . 11 2-4 Initial Wireless LAN Connection (Windows 8, Server 2012) ........

  • Page 3: Specifications

    1. Specifications (1) WLAN USB Adapter (IEEE 802.11b/g) LD630/LD640 requires WLAN USB adapter to use the wireless LAN function. LD630/LD640 is compatible with WLAN adapters using the Ralink RT73, ZD1211rw chipset. WLAN USB adapters using chipsets other than Ralink RT73, ZD1211rw won’t work when they are connected to LD630/LD640.
  • Page 4 LD630/LD640 (2) Ethernet / WLAN Protocol Layer Protocol Network Layers ARP, IP, ICMP Transport Layers TCP, UDP DHCP, DNS Raw Print SMTP (notify printer status) Application Layers HTTP, HTTPS (setting) FTP (settings) TELNET (settings) (3) Ethernet Security HTTPS (SSL2.0, SSL3.0, TLS1.0)

  • Page 5: How To Connect

    LD630/LD640 2. How to Connect Both Ethernet and WLAN can be configured through the printer’s Ethernet interface. Likewise, both Ethernet and WLAN can also be configured though the printer’s WLAN interface. When you want to change the Ethernet or WLAN of the printer, the network settings of the host (PC, PDA, etc) and Ethernet or WLAN of the printer must configured properly configured so that communication can be established.

  • Page 6: Initial Wireless Lan Connection (Windows 2000)

    LD630/LD640 2-1 Initial Wireless LAN Connection (Windows 2000) Windows 2000 does not support wireless network setting. When you use Windows 2000, you need to set the utility option as below after installing utility program related to the wireless lan driver that you use.
  • Page 7 LD630/LD640 3) Select Internet Protocol (TCP/IP), and then click Properties. 4) Set the IP settings as shown below, and then click OK. - 7 -...
  • Page 8 LD630/LD640 5) Select the Wireless LAN tab, and then select “Use Windows to configure my wireless network settings.” Click the [Advanced] button. 6) Select “Computer-to-computer (ad hoc) network only.” - 8 -...
  • Page 9 LD630/LD640 7) Click the [Add] button. 8) Enter “OKI_adhoc” as the Network name (SSID). Select the connection, even if the network is not broadcasted. Network Authentication: Select [Open] Data Encryption: Select [Disabled] Click the [OK] button. - 9 -...
  • Page 10 LD630/LD640 9) Click the “Connect” tab and check “Connect when this network is in range.” 10) Check whether the settings are updated as shown below, and then click [Close] When the printer is set to the default value (Adhoc mode, SSID: OKI_adhoc), it will automatically connect.

  • Page 11: Initial Wireless Lan Connection (Windows Vista, Server 2008, Server 2008R2, 7)

    LD630/LD640 2-3 Initial Wireless LAN Connection (Windows Vista, Server 2008, Server 2008R2, 7) When wireless utility program is installed, you have to set the wireless control values via the program, otherwise you have to terminate the program in order to do proper setting after following the steps 'Control Panel>>Administrative tools>>...
  • Page 12 LD630/LD640 3) Click the “Change adapter settings”. Click the “wireless network adaptor’s Properties”. 4) Select Internet Protocol Version 4(TCP/IPv4), and then click Properties. - 12 -...
  • Page 13 LD630/LD640 5) Set the IP settings as shown below, and then click OK. 6) Click the “Manage wireless networks”. - 13 -...
  • Page 14 LD630/LD640 7) Click the “Add”. 8) Click the “Create an ad hoc network”. - 14 -...
  • Page 15 LD630/LD640 9) Click the “Next”. 10) ‘Network name’ = OKI _adhoc, ‘Security type’ = Open, ‘Save this network’ check, and then click the “Next”. - 15 -...
  • Page 16 LD630/LD640 11) Click the “Close”. 12) After completing configuration, OKI_adhoc network will be created. When the printer is set to the default value (Adhoc mode, SSID: OKI_adhoc), it will automatically connect. - 16 -...

  • Page 17: Initial Wireless Lan Connection (Windows 8, Server 2012)

    LD630/LD640 2-4 Initial Wireless LAN Connection (Windows 8, Server 2012) -Please follow the settings below. 1) Click the “Settings>>Control Panel”. - 17 -...
  • Page 18 LD630/LD640 2) Click the “View network status and tasks”. 3) Click the “Change adapter settings”. Click the “wireless network adaptor’s Properties”. - 18 -...
  • Page 19 LD630/LD640 4) Select Internet Protocol Version 4(TCP/IPv4), and then click Properties. 5) Set the IP settings as shown below, and then click OK. - 19 -...
  • Page 20 LD630/LD640 6) Click the “Settings>>Available(Wireless Lan)”. 7) Click the “OKI_adhoc”. - 20 -...

  • Page 21: Configuration

    LD630/LD640 3. Configuration LAN Setting Values Classification Item Remarks Input Range Home LAN setting status display Printer Name Printer name 0~32 letters 0~32767 integers TCP Raw port that the Printer Port (except 21, 23, 25, 80, printer can use 443, 3318)
  • Page 22 LD630/LD640 WLAN Setting Values Classification Item Remarks Input Range Home WLAN setting status display Printer Name Printer Name 0~32 letters TCP Raw port that the printer 0~32767 integers Printer Port can use (except21,23,25,80,443,3318) ID to use for ftp, telnet, web-...

  • Page 23: Configuration Tool

    LD630/LD640 3-1 Configuration Tool Execute Net Configuration from Start menu. (Start>>Okidata>>Net Configuration) Click the Ethernet Configuration button when the printer is connected to the Ethernet, or click the WLAN button when the printer is connected through WLAN. LAN Configuration - 23 -...
  • Page 24 The following warning message may pop up if the firewall is installed. Select [Unblock], and then retry the Search operation. Select the LD630/LD640 printer from the list and press the [Setting] button, and then the following window for setting Ethernet settings will pop up.
  • Page 25 (Device Baudrate setting, which is used for other models, is not necessary for LD630/LD640.) Select the LD630/LD640 printer from the list and press the [Configuration(Web)] button, and then the Login window will pop up. Enter the ID and Password set for the printer, and then click OK (Default settings are ID: “admin”, Password: “password”)
  • Page 26 When you log in, you will see the web browser for changing the Ethernet and WLAN settings as shown below. WLAN Configuration When you press the Search button, the LD630/LD640 printer connected to the network will be shown in the list. - 26 -...
  • Page 27 LD630/LD640 Select the LD630/LD640 printer from the list and press the [Setting] button, and then the following window for changing the WLAN settings will pop up. Enter the proper IP Address, Subnet Mask, and Gateway of the currently used network, and then click the [Save] button to save the settings.
  • Page 28 LD630/LD640 Select the LD630/LD640 printer from the list and press the [Configuration(web)] button, and then the Login window will pop up. Enter the ID and Password set in the printer, and click OK. (Default settings are ID: “admin”, Password: “password”) When you log in, you will see the web browser for changing the Ethernet and WLAN settings as shown below.
  • Page 29 LD630/LD640 You can search for the information of the wireless network by pressing the BSS Info button. When you press the BSS Info button, information about the SSID, BSSID, Network Model, and Encryption information of the network in close range will be shown as follows.

  • Page 30: Web Browser

    LD630/LD640 3-2 Web Browser LD630/LD640 supports the security enhanced https protocol as well as http. When SSL of the web server of LD630/LD640 is enabled, you must enter the address with “https” instead of “http” in the address bar to connect to the web-server.
  • Page 31 LD630/LD640 When the ID and Password match the ones registered in the printer, the following window will be opened. Both LAN and WLAN can be configured from this window. LAN Configuration Selection - 31 -...
  • Page 32 LD630/LD640 Settings related to Home, System, Protocol, and Network (LAN) can be configured in this window. Wireless LAN selection Home, System, Protocol, Network (WLAN), and Authentication can be configured from this window, and the wizard mode is also provided for easier step by step configuration.

  • Page 33: Ftp

    LD630/LD640 3-3 FTP The configuration files will be downloaded and uploaded to and from the current path. In the following case, the current path is “C:\Documents and Settings”. Enter “ftp Printer IP”, and enter the ID and Password set for the printer.
  • Page 34 LD630/LD640 The contents of the LD630D.config file are as follows. * The format of the configuration file is “Configuration item: Setting value”. Uploading a file that doesn’t have the format shown above will not change the setting values. - 34 -...

  • Page 35: Telnet

    LD630/LD640 3-4 Telnet Enter “telnet Printer IP”. Enter the ID and Password set for the printer. The screen related to the network configuration will then be displayed. You can select the menu to configure and edit the settings. - 35 -...

  • Page 36: Smtp

    LD630/LD640 4. SMTP The changes of the status of the printer are monitored, and a notification e-mail is sent to the registered administrators. SMTP must be enabled to use the SMTP function. You can use the web browser, telnet, or ftp to enable the SMTP.
  • Page 37 LD630/LD640 Click the Configuration button to display the following window. - 37 -...
  • Page 38 LD630/LD640 Check the SMTP setting values SMTP User ID Check the ID registered to the mail server. SMTP Password Enter the password for the corresponding User ID. Enter the mail server. (Example: Domain or mail server IP) SMTP Server Name * Check DNS settings when entering domain.

  • Page 39: Ethernet/Wlan Test By Using Windows Test Page

    LD630/LD640 5. Ethernet/WLAN Test by using Windows Test Page You can use the Windows printer driver as shown below when there is no test program. Operating systems that allow you to use the Windows printer driver are Windows 2000, XP, Server 2003, Vista, Server 2008, Server 2008R2, 7, 8 , Server2012.
  • Page 40 LD630/LD640 4) Select the “Ports” tab from the “Properties” window. 5) Click “Add Port…” - 40 -...
  • Page 41 LD630/LD640 6) Select “Standard TCP/IP Port” and click “New Port...” 7) Click the [Next] button in the “Add Standard TCP/IP Printer Port Wizard” window. 8) Enter the IP address assigned to the printer in the “Printer Name or IP Address” field in the “Add Port”...
  • Page 42 LD630/LD640 9) Click the [Next] button in the “Additional Port Information Required” window. [Note] - Click the [Next] button to proceed without any changes. 10) Click the [Finish] button at the “Completing the Add Standard TCP/IP Printer Port Wizard” window.
  • Page 43 LD630/LD640 12) Click the “Configure Port...” button in the “Properties” window. 13) Enter the same number as the local port number set during the installation of the interface card in the “Port Number” field in the Raw Settings. [Note] - Do not change any other items except the RAW Settings.
  • Page 44 LD630/LD640 14) Click [OK] when you finish entering the required values, and then click the [Apply] button. 15) Select the “General” tab in the Properties window, and then select the “Print Test Page” to check the printing status. - 44 -...

  • Page 45: Factory Reset

    LD630/LD640 6. Factory Reset This function changes the Ethernet and WLAN settings of the printer to the initial factory settings. Method In order to carry out the factory reset, turn off the printer, and then turn on the printer while pressing the reset button as shown in the following picture.
  • Page 46 LD630/LD640 Factory Reset Values Printer Name LD630T or LD630D or LD640T or LD640D Printer Port Number 9100 Printer Name User ID admin User Password password Disabled TELNET Disabled HTTPS Disabled Disabled SMTP Server Name: "" SMTP Port Number: 25 Protocol From Address : ""...

  • Page 47: Troubleshooting

    802.11 mode Check whether AP supports 802.11b or 802.11g. Oki data printer supports 802.11b/g, and 802.11a is not supported. Network Mode Check the network mode of the printer. Network mode must be set to “Infrastructure” to connect to AP and “Ad-hoc”...
  • Page 48 LD630/LD640 Port Check whether the port configured in the printer and the host (PC, PDA) are the same. Authentication / Encryption Check the authentication/encryption setting status. Check whether the settings of the printer and the AP (wireless terminals) are the same.
  • Page 49 PC and confirm whether recognition operation is normal. Check whether WLAN USB adaptor uses the Ralink RT73 chipset. WLAN USB adaptors that use chipsets other than RT73 of Ralink won’t work when it is connected to LD630/LD640. - 49 -...
  • Page 50 Fax:+353 (0)1 4049591 Liebermannstrasse A02 603 http://www.oki.ie Telefon: +36 1 814 8000 22345 Brun am Gebirge Telefax: +36 1 814 8009 Oki Systems Ireland Limited - Tel: +43 223 6677 110 Website: www.okihu.hu Northern Ireland Drucker Support: OKI Systems (Italia) S.p.A.
  • Page 51 Fax: 1-856-222-5260 Lingkaran Syed Pura 59200, Romania Email: LASatisfaction@okidata.com Kuala Lumpur, Malaysia Oki Data de Mexico, S.A. de C.V. Tel: +40 21 303 3138 Tel: (60) 3 2287 1177 Fax: +40 21303 3150 Fax: (60) 3 2287 1166 Mariano Escobedo #748, Piso 8 Website: http://romania.oki.com...
  • Page 52 Oki Data Corporation 4-11-22 Shibaura, Minato-ku,Tokyo 108-8551, Japan www.okiprintingsolutions.com Rev2...
