SUPPLY CIRCUIT WIRING

TABLE 1

MAXIMUM WIRING LENGTH

FROM RPS TO FIXTURE
LENGTH (FT)
WIRING
SIZE AWG
#20
#18
#16

KEY

B BLACK:
Y YELLOW: EXITS/CVRE: 12/24 VDC POS +
R RED:
BL BLUE:
220 VFW Avenue, Grasonville, MD 21638
MUEBB
100
170
430
STANDARD
J- BOX
NOTE: IF SECURITY / NIGHT LIGHTING
IS NOT SUPPLIED OR REQUIRED, CAP
OFF BLUE LEAD TO POWER
CONVERTER
COMMON: 12/24 VDC NEG -
EMERGENCY: 24VDC POS +
SECURITY/ NIGHT LIGHTING: 24 VDC POS +
Signtex Lighting
•
LED Mullion Mount Emergency Light
OUTPUT
24 VDC
TO
BRANCH
FIXTURE
CIRCUITS
#16- 20 AWG
IN/ OUT
BL
R
B
TEL: (410)827- 8300 Fax: (410)827- 8866
Remote Series MUE-RE
