RKC INSTRUMENT CB100 Initial Setting Manual page 33

2
0: No alarm
1: Deviation high alarm
2: Deviation high/low alarm
3: Process high alarm
5: Deviation low alarm
6: Band alarm
Do not set 4, 8, 12 or 14. Malfunction may result.
3
0: PID action with autotuning (Direct action), time proportioning output (relay contact output,
voltage pulse output, trigger (for triac driving) output or triac output.
1: PID action with autotuning (Reverse action), time proportioning output (relay contact output,
voltage pulse output, trigger (for triac driving) output or triac output.
3: Heat/cool PID action with autotuning, heat-side time proportioning output (relay contact
output, voltage pulse output or triac output) or cool-side time proportioning output (relay
contact output, voltage pulse output, triac output).
4: PID action with autotuning (Direct action) or current output.
5: PID action with autotuning (Reverse action) or current output.
7: Heat/cool PID action with autotuning, heat-side current output or cool-side time
proportioning output (relay contact output, voltage pulse output, triac output).
11: Heat/cool PID action with autotuning, heat-side time proportioning output (relay contact
output, voltage pulse output or triac output) or cool-side current output.
15: Heat/cool PID action with autotuning, heat-side current output or cool-side current output.
Do not set 2, 6, 8, 9, 10, 12, 13 or 14. Malfunction may result.
4
0: Alarm 1 (Energized alarm), alarm 2 (Energized alarm)
1: Alarm 1 (De-energized alarm), alarm 2 (Energized alarm)
2: Alarm 1 (Energized alarm), alarm 2 (De-energized alarm)
3: Alarm 1 (De-energized alarm), alarm 2 (De-energized alarm)
4: Alarm 1 (Energized alarm, Z-124 specification provided), alarm 2 (Energized alarm)
5: Alarm 1 (De-energized alarm, Z-124 specification provided), alarm 2 (Energized alarm)
6: Alarm 1 (Energized alarm, Z-124 specification provided), alarm 2 (De-energized alarm)
7: Alarm 1 (De-energized alarm, Z-124 specification provided), alarm 2 (De-energized alarm)
8: Alarm 1 (Energized alarm), alarm 2 (Energized alarm, Z-124 specification provided)
IMCB04-E10
3. COMMUNICATION INITIAL IDENTIFIER
7: Process low alarm
9: Deviation high alarm with hold action
10: Deviation high/low alarm with hold action
11: Process high alarm with hold action
13: Deviation low alarm with hold action
15: Process low alarm with hold action
Continued on the next page.
27
