Summary of Contents for Montarbo Fire15LP

  • Page 1 MANUALE D’ISTRUZIONI OWNER’S MANUAL...
  • Page 2: Table Of Contents

    Dati tecnici | Technical specifications Curva di risposta | Response curve Esempi di collegamento | Connection examples Parti di ricambio | Spare parts Novembre 2015 ©2015 Elettronica Montarbo srl | M000071 | Rev. 00 November 2015 Manuale d’istruzioni | Fire15LP...
  • Page 3: Italiano

    Per qualsiasi intervento di manutenzione o riparazione, rivolgetevi alla Elettronica Montarbo srl e/o a personale altamente qualificato specificamente segnalato da questa. • Nel predisporre l'apparecchio all'utilizzo, assicurarsi che la forma e la portata della superficie di appoggio siano idonee a sostenerlo, considerando sia il peso che l'ingombro del prodotto.
  • Page 4 Introduzione Fire15LP è un sistema passivo full-range a due vie con impedenza Componenti di alta qualita costruiti secondo specifiche Montarbo ® 8 Ω. Il box in multistrato di betulla ed i trasduttori di grande qualita garantiscono grande efficienza ed una timbrica calda e brillante. La Woofer da 15"...
  • Page 5 (cavi di segnale). » Per istruzioni cablaggio dei connettori vedere pag. 6. Attenzione! Non collegare mai due amplificatori alla stessa cassa. speakON ® è un marchio registrato da Neutrik ® AG, registrato negli USA e altri Paesi. Fire15LP | Manuale d’istruzioni...
  • Page 6 Attenzione: i morsetti [2+] e [2–] non sono utilizzati. inserto vista interna 4 - Effettuati i collegamenti sull’inserto infilarlo nel corpo e avvitare morsetti quest’ultimo alla bussola. Il connettore da utilizzare è un Neutrik speakON modello NL4-FC. ® ® ® corpo connettore speakon chiuso Manuale d’istruzioni | Fire15LP...
  • Page 7 ATTENZIONE ALL’IMPEDENZA TOTALE IN PARALLELO Se si collegano due sistemi da 8 Ω in parallelo, l’amplificatore vedrà una impedenza di carico di 4 Ω, che è perfettamente sopportata da tutti gli amplificatori e mixer amplificati Montarbo ® e da quasi tutti gli altri costruttori.
  • Page 8 Manuale d’istruzioni | Fire15LP...
  • Page 9 This product does not contain user serviceable parts. To prevent fire and/or electrical shock, never disassemble it or remove the rear panel. For maintenance and servicing always refer to the official Montarbo Distributor in your Country or to qualified personnel specifically authorised by the Distributor.
  • Page 10 Introduction Fire15LP is a two-way full-range, passive speaker system, with 8 Ω Top-quality components, custom-designed according to Montarbo ® impedance. specifications: The cabinet made of birch plywood and the high-quality trasductors 15" woofer with neodymium magnet. provide great efficiency and a warm and brilliant sound. The lightness and ease of assembly allow quick installations.
  • Page 11 » For detailed instructions about connector wiring, see page 12. Warning! Never connect two amplifiers to the same loudspeaker. speakON ® is a trademark under property of Neutrik ® AG, registered in US and other Countries. Fire15LP | Owner’s manual...
  • Page 12 4 - After connecting the wires to the insert, lead it through the body and screw down the body with the bushing. setscrews Mating connector is a Neutrik speakON model NL4-FC. ® ® ® housing speakon connector Owner’s manual | Fire15LP...
  • Page 13 PAY SPECIAL ATTENTION TO THE PARALLEL IMPEDANCE: If two 8-Ω systems are parallel connected, the resulting load impedance for the amplifier will be 4 Ω, a value that is within the allowed range for all amplifiers and amplified mixers manufactured by Montarbo ® and by most other manufacturers.
  • Page 14 Owner’s manual | Fire15LP...
  • Page 15: Appendix

    APPENDIX __________________________________________ Dati tecnici Technical Specifications __________________________________________ Curva di risposta Response curve __________________________________________ Esempi di collegamento 17 - 18 Connection examples __________________________________________ Parti di ricambio Spare parts __________________________________________ Fire15LP | Appendix...
  • Page 16: Dati Tecnici | Technical Specifications

    Birch plywood, 15/10 steel protection grille with foam. FITTINGS Carrying handle, speaker-stand adapter, 7 x 10MA hanging points DIMENSIONS W 440 x H 780 x D 440 mm WEIGHT 23,8 kg Curva di risposta | Response curve Appendix | Fire15LP...
  • Page 17: Esempi Di Collegamento | Connection Examples

    Esempi di collegamento | Connection examples Out R 2x FIRE15LP Out L 2x FIRE15LP Montarbo MCR16FXP mixer ® Fire15LP | Appendix...
  • Page 18 Esempi di collegamento | Connection examples Line D 2x Fire15LP Line C 2x Fire15LP Line B 2x Fire15LP Line A 2x Fire15LP Line B from mixer Line A from mixer BALANCED OUTPUTS BALANCED INPUTS A C L O O P O U T...
  • Page 19: Parti Di Ricambio | Spare Parts

    Adattatore per asta 1.4" compression driver Cross-over filter Speaker stand adaptor A300198 D515LP0 Tromba 80° X 60° Pannello connessioni 80° X 60° Horn Connections panel D21F15A A300086 Altoparlante 15" Griglia in acciaio perforato 15" loudspeaker Steel grille Fire15LP | Appendix...
  • Page 20 Information on Disposal for Professional Users In the European Union | If the product is used for business purposes and you want to discard it: please contact your Montarbo ® dealer who will inform you about the take-back of the product. You might be charged for the costs arising from take-back and recycling.
