  • Page 1 MT160A active PA & Monitor system...

  • Page 2: Dati Tecnici

    Questo apparecchio non contiene parti interne destinate all'inter- vento diretto da parte dell'utilizzatore. Per evitare il rischio di incendio e/o folgorazione, non aprirlo. Per qualsiasi intervento di manutenzione o riparazione, rivolgersi alla Elettronica Montarbo srl e/o a personale altamente qualificato specificamente segnala- to da questa.
  • Page 3 MT160A Presentazione MT160A non è solamente un monitor amplificato controllato da processore; è un sistema integrato ad alte prestazioni. Progetto e costruzione soddisfano uno standard qualitativo sconosciuto ai prodotti di questa categoria, con risultati di affidabilità, versatilità e prestazioni musicali ai massimi livelli.
  • Page 4 MT160A Descrizione -40 dB PEAK 0 dB LINE -10 dB MIXED LINE OUT MT 160 A Montarbo Montarbo PROCESSOR CONTROLLED POWERED MONITOR C A U T I O N : TO PREVENT ELECTRICAL SHOCK, DO NOT REMOVE COVERS. POUR PREVENIR RISQUE DE CHOC...
  • Page 5 “0 dB” quando la MT160A viene collegata ad un mixer, diretta- Uscita Linea miscelata. Consente di dare segna- mente o attraverso il crossover elettronico di un subwoofer le ad un altro MT160A, ad un mixer o ad un regi- (vedi pagine 18 e 19). stratore.
  • Page 6 MT160A Controllo 'EQ' Il filtro EQ ha una curva studiata apposta per questo comando. Ovviamente ciascuno, partendo da queste aumentare la proiezione del suono. regolazioni base, può utilizzare tutte le posizioni Gli esempi illustrati di seguito potranno esservi intermedie secondo le proprie preferenze.
  • Page 7 • Abbiate cura dei cavi di collegamento, avvolgeteli evitando nodi e torsioni. Utilizzare cavi sbilanciati Jack . Collegare l’uscita ( MIXED LINE OUT ) della prima MT160A • Non forzate i connettori ed i comandi. ad un ingresso linea (LINE 1o LINE 2) della seconda, l’uscita della seconda ad un ingresso linea della terza...

  • Page 8: Table Of Contents

    To prevent fire and/or electrical shock, never open it. For maintenance and repairs interventions always refer to the official Montarbo Distributor in your State or to qualified personnel specifically authorised by the Distributor. - While preparing the device for operation, always make sure that the supporting surface'shape and load rating will safely match the product's size and weight.

  • Page 9: Introduction

    A line output is also The built-in amplifier is a class AB provided to feed another MT160A, MosFet unit designed to deliver a tape recorder, or a mixer. both high power (80 W continuous , 150 W peak ) and sonic accuracy.

  • Page 10: Description

    MT160A Description -40 dB PEAK 0 dB LINE -10 dB MIXED LINE OUT MT 160 A Montarbo Montarbo PROCESSOR CONTROLLED POWERED MONITOR C A U T I O N : TO PREVENT ELECTRICAL SHOCK, DO NOT REMOVE COVERS. POUR PREVENIR RISQUE DE CHOC...

  • Page 11: Control And Connection Panel

    Level control for the two line inputs. Mixed line-level output. It can feed another Set it to the “0 dB” position when the MT160A is connected to a mixer output directly or through the electronic crossover of MT160A, your personal DAT recorder, a camcorder, an active subwoofer (see pages 18 e 19).
  • Page 12 MT160A EQ control The EQ filter has a calibrated curve that improves examples, you may set the EQ control in any other intermediate position according to your the projection of sound. The examples below will requirements. be of help to understand the EQ control function.

  • Page 13: Important

    • Make sure the mains power switch is off ('0') before Connect the first MT160’s output (MIXED LINE OUT) starting any connection. to a line input (LINE 1 or LINE 2) of the second MT160A, the second’s output to a line inout of the third, and so on.

  • Page 14: Appendix

    MT160A APPENDIX Technical Specifications Dati tecnici Response curve Curva di risposta Block diagram Schema a blocchi Connections & Applications 17 - 23 Collegamenti e Applicazioni Spare parts Parti di ricambio APPENDIX...

  • Page 15: Technical Specifications

    MT160A Technical Specifications • Mixer: 1 microphone input 2 line inputs 1 EQ filter at 1.2 kHz 1 line level unbalanced output Micro: -40 dB Input sensitivity Line: -10 dB Micro: 2 KΩ Input impedance Line: 22 KΩ Class AB MosFet output stage •...

  • Page 16: Block Diagram

    MT160A Response curve Block diagram APPENDIX...
  • Page 17 MT160A Connections Microphone input EFFECTS INDEX 0 - ECHO FAST 4 - PING PONG 8 - HALL REVERB C - PITCH CHANGE XD 13 1 - ECHO SLOW 2 - ALONE SMALL 5 - REVERSE REVEB 6 - EARLY REFECTION...
  • Page 18 MT160A Applications • mini PA-system for sound reinforcement Example (as independent system) instruments, microphones MT160A (directly to mic and line inputs) LINE INPUT LINE INPUT OUTPUTS MIC INPUT LINE INPUT LINE INPUT OUTPUTS Example mixer MT160A LINE INPUT LINE INPUT...
  • Page 19 MT160A Applications • mini PA-system for sound reinforcement Example mixer one 112SA two MT160A LINE INPUT LINE INPUT 112SA OUTPUTS 112SA INPUTS MIXER OUTPUTS EFFECTS INDEX 0 - ECHO FAST 4 - PING PONG 8 - HALL REVERB C - PITCH CHANGE...
  • Page 20 112SA MT160A & SUB... In the applications requiring an extention of the low frequency range, MT160A combines perfectly with the self-powered subwoofer 112SA with built-in stereo electronic crossover. Nelle situazioni di utilizzo che richiedono un rinforzo della gamma grave il complemento ideale è il subwoofer autoampli- ficato 112SA (con crossover elettronico stereo incorporato).
  • Page 21 MT160A Applications • stage monitor • keyboards monitor • home recording • lectures, conferences MIC INPUT LINE INPUT OUTPUT APPENDIX...
  • Page 22 MT160A Applications • press conferences LINE INPUT LINE INPUT LINE INPUT LINE INPUT OUTPUT OUTPUT MIXER OUTPUTS Set Line controls to ‘0dB’ EFFECTS INDEX 0 - ECHO FAST 4 - PING PONG 8 - HALL REVERB C - PITCH CHANGE...
  • Page 23 MT160A Applications • multimedia • and many other, in the most different places ..restaurants ..gymnasiums ..pubs ..hotels ..museums APPENDIX...
  • Page 24 MT160A Spare parts ;;;;; yyyyy A088100 ;;;;; yyyyy Threaded studs D520MB1 Amplifier A300150 chassis 6” loudspeaker (022 8Ω) PC MTBF Mosfet support D000MB1 PC MTAY B01MBX3 preamplifier Perforated steel grid. ;;;;; yyyyy D000MB3 PC MTAW Jacks D000MB5 PC MTATR5 ;;;;;...
